Summary of Contents for Proton S70
-
Page 2: Table Of Contents
Contents Quick Guide Quick Guide About this Manual Intelligent Key Intelligent Entry System Front Seats Rear Seats Seat Belt Starting the Vehicle Warning and Indicator Lights Front A/C Control System (Type I - Automatic) Front A/C Control System (Type II) In-vehicle Power Supply... -
Page 3: About This Manual
Quick Guide Quick Guide About this Manual Prompt Message This manual provides relevant information Notes to Users of all models. Due to the variety of Manual Instructions configurations, the descriptions in this manual may differ from the actual one of •... -
Page 4: Intelligent Key
Quick Guide Quick Guide Intelligent Key Intelligent Key Battery Replace the intelligent key battery when Intelligent Key Buttons its detection distance gets shorter than normal or this vehicle cannot recognize intelligent key due to low battery power. Pull out the mechanical key. Insert the mechanical key into the opening as shown below. -
Page 5: Intelligent Entry System
Quick Guide Quick Guide Intelligent Entry System Central Unlock / Lock Button Unlock/Lock button at driver’s door handle Unlock button - unlock all doors Lock button - lock all doors Keyless Locking Door Handle • Turn OFF ignition switch. • Close all doors and trunk lid. -
Page 6: Trunk Lid
Quick Guide Quick Guide turned OFF. • Multimedia display setting: disable Driver Door Only. Collision unlocking: severe front impact Opening the Trunk Lid Using Intelligent Key Trunk Lid Opening the Trunk Lid from Inside of the Vehicle • Turn OFF ignition switch •... -
Page 7: Front Seats
Quick Guide Quick Guide Front Seats Manual Adjustment of Driver’s Seat* Headrest Adjustment Adjustment lever of seatback angle • Press and hold the adjustment button Adjustment lever of seat height under the front seat headrest. Forward and backward adjustment • Lift up or press down the headrest to lever of seat the required height, and then release... -
Page 8: Rear Seats
Quick Guide Quick Guide Rear Seats • Fully fold the seatback on the corresponding side. Headrest Adjustment* Unfolding Rear Seatback • Flip back the backrest and push hard backwards until the corresponding seat is locked. Seat Belt Three-point Seat Belt Pick up the latch plate and pull the seat belt across your body. -
Page 9: Starting The Vehicle
Quick Guide Quick Guide Starting the Vehicle Ignition Switch Intelligent Key Detection Make sure the intelligent key is inside the vehicle or place it at the the front end of the centre console as shown in picture. Type I Close all doors. Make sure that the gear is in Neutral (N) or Park (P) position. -
Page 10: Warning And Indicator Lights
Quick Guide Quick Guide Warning and Indicator Lights Introduction of Warning and Indicator Lights Icon Name Description Color Left turn signal indicator Left turn signal is on Green Right turn signal indicator Right turn signal is on Green Low beam lamp indicator Low beam lamp is on Green Low beam lamp failure... - Page 11 Quick Guide Quick Guide Icon Name Description Color AUTO HOLD function is Green enabled AUTO HOLD (AVH) status indicator AUTO HOLD function has a failure The airbag system has a Airbag failure warning lamp failure Seat belt not fastened or has Seat belt warning failure Engine emission failure...
- Page 12 Quick Guide Quick Guide Icon Name Description Color TPMS has failures with Tyre pressure monitoring abnormal tyre pressure or Yellow system (TPMS) warning* TPMS has not been self- learned ACC is enabled but not White activated Adaptive cruise control (ACC) status indicator* ACC is activated Green...
- Page 13 If there is any fault causing warning lamps stay illuminate on or suddenly lit on during driving, pay attention to it and contact an authorised PROTON service outlet for maintenance as soon as possible. Otherwise, severe casualty or property loss may occur.
-
Page 14: Front A/C Control System (Type I - Automatic)
Quick Guide Quick Guide Front A/C Control System (Type I - Automatic) A/C Control Panel on Instrument Panel A/C Control Panel on Multimedia Display Screen Rear windshield button A/C MAX button Front windshield button Air ventilation mode selection button Air circulation switch button A/C button* AUTO button* A/C setting button... -
Page 15: Front A/C Control System (Type Ii)
Quick Guide Quick Guide Front A/C Control System (Type II) A/C Control Panel on Instrument Panel A/C Control Panel on Multimedia Display Screen Rear windshield button A/C MAX button Front windshield button Air ventilation mode selection button Air circulation switch button A/C button* AUTO button* A/C setting button... -
Page 16: In-Vehicle Power Supply
Quick Guide Quick Guide In-vehicle Power Supply Wireless Charging* The wireless charging board is at the lower Front Charging Slots center console’s storage compartment area (front end of the centre console). Put the mobile phone at correct location as shown in picture for wireless charging. USB multimedia slot Type-C charging slot 12V power socket... - Page 17 PROTON warrants that it will either repair or replace, as it deems appropriate, free of charge, any part of your Proton vehicle covered by this warranty that is deemed defective in material or workmanship under normal use, for a period within 60 months unlimited mileage from the date of the vehicle’s first registration (Malaysia only);...
- Page 18 NOV 2023...
