- Page 1 ECLIPSE Electric Installation Fires ECLIPSE 600 - CS UTF28 ECLIPSE 900 - CS UTF35 Installation and Operation Instructions...
-
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT INFORMATION ..........2 UNPACKING ................ 3 ..............4 LOCATION OF FIRE PRODUCT INFORMATION ..........5 ........5 PRODUCT TECHNICAL INFORMATION ............5 PRODUCT DIMENSIONS ..........5 MANUFACTURERS INFORMATION INSTALLATION ..............6 ........... 7 PLACING THE LOGS AND EMBERS OPERATING THE FIRE ............ -
Page 3: Important Information
Important information: Please read the instructions carefully BEFORE installation. § Keep the front of the appliance at least 3 FEET AWAY from combustible materials. These include but are not limited to: articles of clothing, curtains, cushions, furniture, other soft furnishings and papers. §... -
Page 4: Unpacking
Unpacking: Congratulations on your new electric fire. In order to unpack your product without causing any damage to yourself of the product, please take care and follow the instructions. 1. Place the box on a flat surface. Make sure you have enough space. -
Page 5: Location Of Fire
Location of fire The fire is designed to be installed within and existing chimney or within a false wall, it is Important to make sure that the chimney is capped and dry, void of damp. This appliance has multiple electrical components that must be kept away from water and damp or moist conditions. -
Page 6: Product Information
Product information: Product technical information Supplier name Henley Stoves Model number CS UTF28 CS UTF35 Voltage 220V – 240V AC50HZ Fuse 13Amp Nominal heat output 1.6KW Minimum heat output 0.8KW Maximum heat output 1.6KW... -
Page 7: Installation
Installation: Please read the instructions carefully BEFORE installation. The installation MUST be carried out by a qualified person. Connect the appliance to a single-phase AC supply of the voltage specified on the ratings plate. In the instance that the fire is connected directly to the mains electricity supply, a fused switched spur with a 13 amp fuse must be fitted. -
Page 8: Placing The Logs And Embers
Placing the logs and embers: The accessory box which is packed inside the fire contains the mixed black and white nuggets that create the fire bed. These should be placed on the base of the fire in a random manner. The logs are then placed in a position of your choice on top of these. -
Page 9: Operating The Fire
Operating the fire: Manual control: MODE HEATER FLAME STANDBY POWER SWITCH This appliance can be operated manually using the controls situated on the top right hand side of the fire screen. ON/OFF POWER SWITCH- This switch is used to turn the mains supply to the appliance on or off. -
Page 10: Remote Control
MODE- Shuffle through a selection of pre-programmed effects. Remote control: Remove the battery / control panel cover by sliding completely down and insert 2 x AAA batteries ensuring the batteries are fitted correctly. Refit the cover by sliding back up to the original position. Please ensure old batteries are disposed of responsibly by contacting your local authority about recycling schemes. - Page 11 Will change colour of flame, ash bed, and ember separately. SENDING ADAPTIVE FLAME BATTERY HEATING ROOM ADAPTIVE TEMPERATURE TEMPERATURE STANDBY CLOCK ON/OFF BRIGHTNESS SETTING HEAT ADAPTIVE MODE FLAME COLOUR TEMPERATURE SCALE ASH BED COLOUR TEMPERATURE UP EMBER COLOUR TEMPERATURE DOWN CLOCK UP CLOCK SETTING CLOCK DOWN...
-
Page 12: Adaptive Control
buttons set to the current day e.g. Monday - 1, Tuesday - 2, Wednesday - 3 etc. Press to confirm the required day. 2. The hour setting will now be blinking, adjust using to the desired hour and confirm using 3. -
Page 13: Wi-Fi / Smart Control
Wi-Fi / Smart control: Preparation In order to prepare please check that your mobile phone is connected to your Wi-Fi router. Plug your fire in to the wall. Switch the fire on at the wall socket. DO NOT use the STANDBY button to turn on, use the power switch. You should see an orange dot appear on the screen. - Page 14 3. Add your device • Please touch the ‘Add device’ button or the ‘Add’ symbol to add your device. 4. Scan the QR code • Touch the ‘SCAN’ symbol. • Scan the below QR code.
- Page 15 5. Connecting to your Wi-Fi • Select your Wi-Fi network and input the password of your Wi-Fi network. 6. Establishing a connection • Give a long press to the standby button for around 3 seconds. WITCH • You should see a red light next to the orange dot in the middle of the fire screen.
- Page 16 7. Adding your device • Wait whilst the app adds the device. Please keep the phone close to the device whilst the device is syncing. • If it fails to sync Repeat steps 4,5 and 6 8. Your device has been added successfully. •...
-
Page 17: Using The App
Using the App 1. To turn the fire on press the standby button at the bottom of the screen 2. To set timers press the clock button at the bottom left of the screen. Along the top of the screen there are 5 tabs ‘Heat, Flame, Ember, Logs and Mode’... -
Page 18: Maintenance
Maintenance: You MUST remove the plug from the socket outlet and allow the heater to cool completely before cleaning or maintenance. Maintenance should only be carried out by a qualified person. Cleaning: A soft dry cloth, such as microfiber cloths, can be used to remove dust and for general day to day care. -
Page 19: Environment
obstructed. If your fire is connected to a chimney, the chimney must be blocked off as the drafts can affect the appliance. If the problem continues, keep the product unplugged from the power socket and contact your supplier. WARNING! § The heater should NEVER be submerged in water. §... -
Page 20: Warranty
Warranty: In the unlikely event that the appliance should prove to be defective due to faulty design, materials or workmanship within 24 months of purchase, the product will be repaired free of charge, In accordance with the following conditions: It is the consumers’ responsibility to prove that the unit is under warranty, e.g.
