Specification
Model
1/3" SONY 1.3Megapixel CMOS Sensor
Pick up Element
Effective Picture Elements
1305(H) X1049(V)
(H×V)
Resolution
720P
Minimum Illumination
0.01 Lux/F1.2
S/N Ratio
More than 50dB
Scanning System
2:1 interface
Synchronous System
Internal, Negative sync.
Auto Electronic Shutter
NTSC: 1/60s~1/100,000s, PAL: 1/50s~1/100,000s
Gama Characteristic
0.45
IR Distance
30 Meters (with￠5x 36 PCS Infrared LED )
Video Output
1Vpp, 75Ω
Auto Gain Control
Auto
Power/Current
DC12V(+/-10%)/450mA
Lens
2.8-12mm Manual Zoom Lens
Dimension (mm)
￠131x 93(H)
Weight (g)
800
Storage Temperature
-30~+60℃ RH95% MAX
Operating Temperature
-10~+50℃ RH95% MAX
Packing List
No
Name
1.
Vandalproof
IR Dome Color Camera
2.
User Guide
IS-138IRDC
Franchiser：
Model
Number
1
1
IS-138IRDC
Color Camera
Vandalproof IR Dome Color Camera
Notes:
Before providing power for the
camera, please read this User Guide in
detail!
Do not attempt to disassemble the camera.
If the camera can not work, please contact
local franchiser or our company.
