Specification
Model
Pick up Element
1/3"CMOS
Effective Picture Elements
976(H) X 496(V）
(H×V)
Horizontal Resolution
800TV Line
Minimum Illumination
0.01Lux/F1.2
S/N Ratio
More than 48dB
Scanning System
2:1 interface
Synchronous System
Internal, Negative sync.
Auto Electronic Shutter
NTSC: 1/60s~1/100,000s, PAL: 1/50s~1/100,000s
Gama Characteristic
Video Output
1Vpp, 75Ω
Auto Gain Control
Power/Current
DC12V(+/-10%)/150mA
Lens
3.7 Taper Pinhole Lens
Dimension (mm)
70(W)X40(H)X119(D)
Weight (g)
Storage Temperature
-30~+60℃ RH95% MAX
Operating Temperature
-10~+50℃ RH95% MAX
Packing List
No
Name
1.
PIR Spy Color Camera
2.
User Guide
IS-1099LPRC
0.45
Auto
350
Franchiser：
Model
Number
1
1
IS-1099LPRC Color Camera
PIR Spy Color Camera
Notes:
Before providing power for the
camera, please read this User Guide in
detail!
Do not attempt to disassemble the camera.
If the camera can not work, please contact
local franchiser or our company.
