ZanySignals Shiny Manual

Hide thumbs

Advertisement

Table of Contents

Shiny
Repeater
Your Shimmering Noises.
Repite lo que te gusta.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Shiny and is the answer not in the manual?

Questions and answers

Related Manuals for ZanySignals Shiny

Summary of Contents for ZanySignals Shiny

  • Page 1 Shiny Repeater Your Shimmering Noises. Repite lo que te gusta.
  • Page 2 Your Shimmering Noises. Sound design with various types of noises. The Shiny o ers vast possibilities for crafting various types of cymbals and sounds that share similarities in their high-frequency spectrum. Our engineering laboratory is unique in the world, stay tuned!
  • Page 3 Index Shiny Description. Module installation. Page 1. Page 10 and 11. Module features. Electrical specifications and recommendations. Page 2. Page 11, 12 and 13. Functions, inputs, and outputs. Warranty. Page 2, 3, 4, 5, 6, 7 and 8. Page 13 and 14.
  • Page 5 3. Functions, Inputs and Outputs. ZanySignals' design prioritizes ease of interpretation and use, allowing for quick and straightforward integration into your workflow. As a result, it's more ergonomic in its knobs, ensuring anyone feels comfortable when interacting with each module.
  • Page 6 Next, a brief explanation of the segmentation of this module's parameters will be provided. The primary functions are assigned to the large black knobs. Secondary and tertiary functions are represented by the small black and blue knobs, respectively. Switches are implemented to toggle or hold a function. Function 1 Function 2...
  • Page 7 The E-switches are designed to allow for three possible functions. Function 1 Function 3 Function 2 Signal inputs are provided through 1/8" jacks, which are clearly distinguished from the outputs as they have a simple boundary, unfilled outline. Inputs Signal outputs are provided via 1/8" jacks, which in this case feature a fully highlighted or filled silkscreen.
  • Page 8 Shiny features. Envelope Knobs: Attack: This knob controls the Attack (A), which is the first parameter of the envelope. This parameter indicates an immediate rise upon the activation of the input signal and governs the slope's level. Release: This knob manages the Release (R) parameter of the envelope.
  • Page 9 Broad: Controls the duration of the Noise. In its maximum position, it allows the Noise to pass through completely, ideal for transitioning between layers. Filter Knob. CutO : Allows defining the filter's cuto frequency. Being a 100% analog module, turning the knob's position will propor- tionally increase the cuto frequency in both LP/HP modes.
  • Page 10 Manual Gate (A o B): This button allows manual activation for channel A or B, giving activation time equal to the time the button is pressed. Selección del Noise: Switches that select the noise for the two channels. The N1/N2 switch selects two di erent types of noises for channel A, while the N3/N4 switch selects two other types of noises for channel B.

  • Page 11: Operation

    B, with the filtering process applied.. 4. Operation. The Shiny is a dual cymbal synthesizer featuring two channels (A and B). To activate them, input a Gate signal into the input of each channel (Gate A/B) at di erent activation times. Verify their operation or activation by observing the LED indicator for each channel.
  • Page 12 Release Broad Broad The Shiny features an LP/HP filter to obtain one of the two filtered channels through the Shiny output. First, select which channel will pass through the filter using the A/B Switch (7), then choose the filter type with the LP/HP Switch (8). Finally,...

  • Page 13: Module Installation

    The Shiny is a module that requires a ±12V power supply, meaning a 10-pin (2x5 pins) connector. Connect the Ribbon cable to the 10-pin female connector on the module's circuit board.

  • Page 14: Electrical And Mechanical Specifications

    -12V -12V STRIPE STRIPE Install the Shiny into the Eurorack case rails and secure it using the 4 mounting screws of 3mm fine thread. Turn on your Eurorack case and verify its proper functioning. 6. Electrical and Mechanical Specifications. Power Supply: +12V, -12V.
  • Page 15 Note Always be aware of the output and input levels of each signal to prevent damage to this or any other module. Given the large audio levels of Eurorack, you should connect to modules specifically designed to accept these levels. Never connect an output to an input that accepts a lower voltage level.

  • Page 16: Warranty

    During the warranty period (1 year for this module), the defective product will be repaired or replaced at ZanySignals' discretion. It is necessary to return the product to ZanySignals' facilities, with the consumer covering the shipping costs. This allows us to review and inspect the module's defects and proceed with the repair.
  • Page 17 ZanySignals is not responsible for any damage or harm to external devices from other brands or to individuals handling this product. Follow the recommended usage and do not operate the powered module unless it is correctly connected to the Eurorack case.
  • Page 18 LowBlow, which then feeds into channel two of the StereoPlus. Lastly, the 1/8 output from the AltDoor is routed to the Gate B input of the Shiny, where its signal is taken from output B and fed into the third input of the StereoPlus, resulting in the L and...
  • Page 19 Consulte el manual en línea para obtener información Consulte el manual en línea para obtener información detallada de este y otros productos. detallada de este y otros productos. www.zanysignals.com www.zanysignals.com Designed and created by ZanySignals. Sonorus spaces to expand the mind. Sonorus spaces to expand the mind.
  • Page 20 Made in Colombia ¡Pues pues! Sonorus spaces to expand the mind.
