Section 1 - Product Overview
LAN Ports (1-4)
Connect Ethernet devices such as
computers, switches, and hubs.
D-Link DIR-655 User Manual

Hardware Overview

Connections

USB
Connect a USB 1.1 or 2.0 flash
drive to configure the wireless
settings using WCN.
Internet Port
The auto MDI/MDIX Internet port is
the connection for the Ethernet cable
to the cable or DSL modem.
Reset
Pressing the Reset button restores the router to
its original factory default settings.
Power Receptor
Receptor for the supplied power
adapter.
