Installation, Maintenance, and Upgrade
•
•
•
•
•
Power the Unit via the AC Power Supply
Safety Warnings
Warning
To power the unit via an AC power connection:
Step 1
Connect the AC plug to the AC appliance coupler.
Step 2
Plug the power cord into a suitable power outlet.
The power LED will light, indicating that the Module is powered.
Power the Unit via DC Power Cable
Safety Warnings
Power the Unit via the AC Power Supply, on page 1
Power the Unit via DC Power Cable, on page 1
Power the Unit via DC Terminal Block Adapter, on page 3
Connect to the Network, on page 4
Remove and Replace the Fan Tray, on page 4
Take note of the following warnings:
The AC appliance couple is used as a disconnect. The AC plug must be connected to a properly grounded
AC outlet.
Take note of the following warning:
Installation, Maintenance, and Upgrade
1
Advertisement
Related Manuals for Cisco SKY-MOD10G-H-DD
Summary of Contents for Cisco SKY-MOD10G-H-DD
- Page 1 Installation, Maintenance, and Upgrade • Power the Unit via the AC Power Supply, on page 1 • Power the Unit via DC Power Cable, on page 1 • Power the Unit via DC Terminal Block Adapter, on page 3 • Connect to the Network, on page 4 •...
- Page 2 Installation, Maintenance, and Upgrade Power the Unit via DC Power Cable Warning Each input should be protected by a 4.0 A to 5.0 A externally-mounted fast-acting fuse or equivalent. There should be one fuse per power feed. Disconnect all power sources before servicing. Removing fuses can be used as a disconnect method.
- Page 3 Installation, Maintenance, and Upgrade Power the Unit via DC Terminal Block Adapter Power the Unit via DC Terminal Block Adapter Safety Warnings Take note of the following warning: Warning Each input should be protected by a 4.0 A to 5.0 A externally-mounted fast-acting fuse or equivalent. There should be one fuse per power feed.
-
Page 4: Connect To The Network
This procedure describes the method to replace the fan tray. It is recommended that you complete the procedure within five minutes of removing the fan tray to prevent overheating of the unit. Note This procedure only applies to the following PIDs: • SKY-MOD10G-H-DD • SKY-MOD10G-H-A Note The fan replacement kit SKY-FANKIT-MOD10G= must be ordered separately. -
Page 5: Replace The Fan Tray
Installation, Maintenance, and Upgrade Replace the Fan Tray • This equipment is sensitive to electrostatic discharge (ESD). When handling, ensure to wear a properly-functioning heel grounder and/or an anti-static wrist strap or another personal-grounding device. • Incorrect handling may void warranty. Take note of the following warnings: Warning Statement 1073 No User-Serviceable Parts... - Page 6 Installation, Maintenance, and Upgrade Replace the Fan Tray Figure 3: Fan Tray Replacement Items To replace the fan tray: Step 1 With the Module 10G front facing you, use a screwdriver to loosen the screws to the right and left of the fan tray. Installation, Maintenance, and Upgrade...
- Page 7 Installation, Maintenance, and Upgrade Replace the Fan Tray Figure 4: Loosen the Screws Step 2 Slide the fan tray towards you to remove it. You do not need to keep this piece; place it in the appropriate electronic recycling. Step 3 Take the new replacement fan tray and slide it into the Module 10G.
- Page 8 Installation, Maintenance, and Upgrade Replace the Fan Tray Figure 5: Slide the Replacement Fan Tray into the Module 10G Step 4 Tighten the right and left screws to secure the replacement fan tray to the Module 10G. Installation, Maintenance, and Upgrade...
