- Page 1 P-Combiner-HV-3/6-V2 Instruction Manual Information Version: 1.0 5PMPA08-00253...
-
Page 3: Table Of Contents
3 input terminals and 1 output terminal with 50A current. “-6” is for the type having 6 input terminals and 1 output terminal with 100A current. Please follow the instructions carefully during the installation process. Any confusion, please contact Pylontech for advice and clarification. Contents Safety ........................1 Symbol ................................ -
Page 4: Safety
1. Safety Read all safety instructions carefully prior to any work and observe them when working on the system. Incorrect operation may cause: Injury or death to the operator or a third party Damage to the system hardware and other properties belonging to the ... - Page 5 Warning: electric shock. Warning: flammable materials. Read the manual before installing and operating the product. Grounding. Recycle label. The certificate label for EMC/CE. Label for Waste Electrical and Electronic Equipment (WEEE) Directive (2012/19/EU) Label for RoHS Directive (2011/65/EU (L174/88, June 8,2011) and 2015/863/EU).
-
Page 6: Eu Declaration Of Conformity
Pylon Technologies Co., Ltd. confirms herewith that the products described in this document are in compliance with the fundamental requirements and other relevant provisions of the above mentioned directives. The entire EU Declaration of Conformity can be found at en.pylontech.com.cn. 1.3 Safety Precautions Caution It is important and necessary to read the instruction manual carefully before installation or use. -
Page 7: In Using
4) In case of fire, dry powder fire extinguisher or CO2 fire extinguisher is allowed. DO NOT use water before cutting all power off. 5) DO NOT open, repair or disassemble the battery except staffs from Pylontech or authorized by Pylontech. We do not undertake any consequences or related responsibility caused by violation of safety operation or violation of design, production and equipment safety standards. -
Page 8: Product Introduction
2. Product Introduction 2.1 Overview of P-Combiner-HV-3/6-V2 A. P-Combiner-HV-3-V2 (Unit: mm) - Page 9 B. P-Combiner-HV-6-V2 (Unit: mm)
-
Page 10: Specifications Of P-Combiner-Hv-3/6-V2
2.2 Specifications of P-Combiner-HV-3/6-V2 P-Combiner-HV-3- P-Combiner-HV- Basic Parameters 6-V2 Nominal Voltage (VDC) 1000 Number of input terminal (pair) Input terminal type (+) H4SMM8DM (Amphenol) Input terminal type (-) H4SFM8DM (Amphenol) Nominal input current per terminal Number of output terminal (pair) Output terminal type Cable connection (O-ring) M24 x 1.5 Nominal/Maximum output current... -
Page 11: Introduction Of Equipment Interface
2.3 Introduction of Equipment Interface A. P-Combiner-HV-3-V2 Power terminal P-Combiner-HV-6-V2 Interface... - Page 12 Attach the grounding cable to the grounding point before connecting power cables. The grounding resistance should be smaller than 0.1Ω. 5) Power terminal output Connect to inverter. P-Combiner-HV-3-V2, 6 AWG cable for maximum 50A current. P-Combiner-HV-6-V2, 4AWG cable for maximum 100 A current.
-
Page 13: Safe Handling Of Lithium Batteries Guide
3. Safe handling of lithium batteries guide 3.1 Tools Socket Wrench Screw Driver (M8 outer hexagon Wire Cutter expansion bolt (PH2) M6 hexagon bolt) 3.2 Safety Gear It is recommended to wear the following safety gear when dealing with the battery. -
Page 14: Installation And Operation
4. Installation and Operation 4.1 Package List Item Description HV-3-V2 HV-6-V2 P-Combiner box Power connector H4SFC8DM Power connector H4SMC8DM Expansion bolt Power cable 4AWG x 2m, SC25-8, orange Power cable 4AWG x 2m, SC25-8, black Grounding cable 10AWG x 1m Power terminal protection cover 3 sets 6 sets... - Page 15 (2) Install the wall mounting bracket on the wall by fastening the 4 expansion bolts into the wall as shown. Torque: 12-13 N.m Tool: Socket Wrench Fastener: expansion bolt, 4 pcs ,M8 x 60 (3) Aligning the two holes with the pins on the mounting bracket, hang the box onto the bracket.
-
Page 16: Cable Connection
Battery NOTE: The above illustration of battery amount is for reference ONLY. For P-Combiner-HV-3-V2, there can be maximum 3 batteries connected to one combiner box. For P-Combiner-HV-6-V2, there can be maximum 6 batteries connected to one combiner box. -
Page 17: Remarks
5. Remarks For recycle and disposal, follow the local disposal rules. DO NOT dispose directly. - Page 20 Pylon Technologies Co., Ltd. No.300, Miaoqiao Road, Kangqiao Town Pudong New Area, Shanghai 201315, China T+86-21-51317699 | +86-21-51317698 service@pylontech.com.cn www.pylontech.com.cn...
