  • Page 2: Contact Information

    Contact Information If you need to contact ASRock or want to know more about ASRock, you’re welcome to visit ASRock’s website at http://www.asrock.com; or you may contact your dealer for further information. For technical questions, please submit a support request form at https://event.asrock.com/tsd.asp...

  • Page 3: Table Of Contents

    Chapter 1 Introduction Package Contents Specifications Motherboard Layout I/O Panel Block Diagram 802.11be Wi-Fi 7 Module and ASRock WiFi 2.4/5/6 GHz Antenna M.2 Expansion Card Chapter 2 Installation Installing the CPU Installing the CPU Fan and Heatsink Installing Memory Modules (DIMM)
  • Page 4 2.13 Dr. Debug 2.14 M.2 SSD Installation Guide (M2_1) 2.15 M.2 SSD Installation Guide (M2_2, M2_4, M2_5 and M2_6) 2.16 M.2 SSD Installation Guide (M2_3)

  • Page 5: Chapter 1 Introduction

    If you require technical support related to this mother- board, please visit our website for specific information about the model you are using. You may find the latest VGA cards and CPU support list on ASRock’s website as well. ASRock website http://www.asrock.com.

  • Page 6: Specifications

    • Supports DDR5 non-ECC, un-buffered memory up to 9200+(OC)* • Max. capacity of system memory: 256GB • Supports Intel® Extreme Memory Profile (XMP) 3.0x * Please refer to Memory Support List on ASRock's website for more information. (http://www.asrock.com/) CPU: Expansion Slot • 1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode*...
  • Page 7 Z890 Taichi Graphics • Intel® UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated. • Intel® X LPG Graphics Architecture • 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz • 2 x Intel®...
  • Page 8 * Wi-Fi 7 (6GHz band) will be supported by Microsoft® Win- dows® 11. The availability will depend on the different regula- tion status of each country and region. It will be activated (for supported countries) through Windows Update and software updates once available.
  • Page 9 Z890 Taichi Storage CPU: • 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s) mode* • 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode* Chipset: • 1 x Hyper M.2 Socket (M2_3, Key M), supports type 2230/2242/2260/2280 SATA3 6.0 Gb/s &...
  • Page 10 • ErP/EuP ready (ErP/EuP ready power supply is required) • CEC Tier II ready * For detailed product information, please visit our website: http://www.asrock.com Please realize that there is a certain risk involved with overclocking, including adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using third-party overclocking tools.

  • Page 11: Motherboard Layout

    Z890 Taichi 1.3 Motherboard Layout CPU_FAN2 AIO_PUMP ATX12V1 ATX12V2 CPU_FAN1 Power Reset Debug CLRC BIOS Top: 2.5GLAN (RTL8125BG) Top: 5GLAN (RTL8126) CHA_FAN4 PCIE1 WiFi-802.11be Module Intel M2_WIFI1 Z890 SUPER SUPER PCIE2 AUDIO CODEC M2_6 CMOS Battery BIOS PANEL1 CHA_FAN3 CHA_FAN2...
  • Page 12 No. Description ATX 12V Power Connector (ATX12V1) ATX 12V Power Connector (ATX12V2) CPU Fan Connector (CPU_FAN1) 2 x 288-pin DDR5 DIMM Slots (DDR5_A1, DDR5_B1) 2 x 288-pin DDR5 DIMM Slots (DDR5_A2, DDR5_B2) CPU Fan Connector (CPU_FAN2) AIO Pump Fan Connector (AIO_PUMP) Addressable LED Header (ADDR_LED3) Addressable LED Header (ADDR_LED2) Power Button (PWRBTN1)

  • Page 13: I/O Panel

    Z890 Taichi 1.4 I/O Panel No. Description No. Description Antenna Ports USB 3.2 Gen2 Type-A Port BIOS Flashback Button (USB32_6)**** 2.5G LAN RJ-45 Port USB 3.2 Gen1 Type-A Port (Dragon RTL8125BG)* (USB32_3)**** 5G LAN RJ-45 Port USB 3.2 Gen2 Type-A Port...
  • Page 14 *There are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications. ACT/LINK LED SPEED LED LAN Port Activity / Link LED Speed LED Status Description Status Description No Link 10Mbps connection 100Mbps/1Gbps Blinking Data Activity...

  • Page 15: Block Diagram

    Z890 Taichi 1.5 Block Diagram...

  • Page 16: 802.11Be Wi-Fi 7 Module And Asrock Wifi 2.4/5/6 Ghz Antenna

    1.6 802.11be Wi-Fi 7 Module and ASRock WiFi 2.4/5/6 GHz Antenna 802.11be Wi-Fi 7 + BT Module This motherboard comes with an exclusive 802.11 a/b/g/n/ac/ax/axe/be Wi-Fi 7 + BT v5.4 module that offers support for 802.11 a/b/g/n/ac/ax/axe/be Wi-Fi 7 connectivity standards and Bluetooth v5.4.

  • Page 17: Expansion Card

    Z890 Taichi 1.7 M.2 Expansion Card The M.2 Expansion Card supports up to four PCIe NVMe SSDs. It is required to enable PCIE2 Bifurcation in the UEFI setting to set bifurcation to x1x1x1x1 mode. To do so, please press the “F2” key during POST to enter UEFI setup. Go to Advanced\ Chipset Configuration and set “PCIE2 Bifurcation”...

  • Page 18: Chapter 2 Installation

    Chapter 2 Installation This is an ATX form factor motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Pre-installation Precautions Take note of the following precautions before you install motherboard components or change any motherboard settings.
  • Page 19 Z890 Taichi DO NOT remove this Memory OC Shield (patent pending) from the motherboard. Removing this may affect memory overclocking performance and stability. The illustration shown here is for reference only and may not be an exact representation of your mother-...

  • Page 20: Installing The Cpu

    2.1 Installing the CPU 1. Before you insert the 1851-Pin CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket. Do not force to insert the CPU into the socket if above situation is found.
  • Page 21 Z890 Taichi Please save and replace the cover if the processor is removed. The cover must be placed if you wish to return the motherboard for after service.

  • Page 22: Installing The Cpu Fan And Heatsink

    2.2 Installing the CPU Fan and Heatsink...

  • Page 23: Installing Memory Modules (Dimm)

    Z890 Taichi 2.3 Installing Memory Modules (DIMM) This motherboard provides four 288-pin DDR5 (Double Data Rate 5) DIMM slots, and supports Dual Channel Memory Technology. 1. For dual channel configuration, you always need to install identical (the same brand, speed, size and chip-type) DDR5 DIMM pairs.

  • Page 25: Connecting The Front Panel Header

    Z890 Taichi 2.4 Connecting the Front Panel Header Front Panel Wires System Panel Header Power SW (-) RESET SW (+) Power SW (+) RESET SW (-) Power LED (-) HDD LED (-) Power LED (+) HDD LED (+) PANEL1...

  • Page 26: Installing The Motherboard

    2.5 Installing the Motherboard...

  • Page 27: Installing Sata Drives

    Z890 Taichi 2.6 Installing SATA Drives Optical Drive SATA Drive SATA Data Cable...
  • Page 28 SATA Power Connector SATA Data Connector...

  • Page 29: Installing A Graphics Card

    Z890 Taichi 2.7 Installing a Graphics Card CLICK! Skip Step 2 if you install a graphics card into PCIE1 slot. Illustrations here are examples only.
  • Page 30 Removing a Graphics Card from PCIE1 Slot Please follow the steps below to release the PCIe slot latch on PCIE1 and remove the graphics card. 1. Slide the latch to the right to release the graphics card from the PCIe slot. Green indicator shows that the latch is properly released.
  • Page 31 Z890 Taichi Expansion Slots (PCIe Slots) There are 2 PCI Express slots on the motherboard. Before installing an expansion card, please make sure that the power supply is switched off or the power cord is unplugged. Please read the documentation of the expansion card and make necessary hardware settings for the card before you start the installation.

  • Page 32: Connecting Peripheral Devices

    2.8 Connecting Peripheral Devices...

  • Page 33: Connecting The Power Connectors

    Z890 Taichi 2.9 Connecting the Power Connectors...

  • Page 34: Power On

    2.10 Power On...

  • Page 35: Onboard Headers And Connectors

    Z890 Taichi 2.11 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. System Panel Header (9-pin PANEL1) (see p.7, No.
  • Page 36 Power LED and Speaker Header (7-pin SPK_PLED1) (see p.7, No. 27) Please connect the chassis power LED and the chassis speaker to this header. SPK_PLED1 SPEAKER DUMMY DUMMY PLED+ PLED+ PLED-...
  • Page 37 Z890 Taichi Serial ATA3 Connectors Right Angle: (SATA3_0) (see p.7, No. 17)(Upper) (SATA3_1) (see p.7, No. 17)(Lower) (SATA3_2) (see p.7, No. 16)(Upper) (SATA3_3) (see p.7, No. 16)(Lower) These four SATA3 connectors support SATA data cables for internal storage devices with up to 6.0 Gb/s data transfer rate.
  • Page 38 USB 2.0 Headers (9-pin USB_3_4) (see p.7, No. 29) (9-pin USB_5_6) (see p.7, No. 28) There are two headers on this motherboard. Each USB 2.0 header can support two ports. USB_5_6 USB_PWR DUMMY USB_PWR USB_3_4 USB_PWR DUMMY USB_PWR...
  • Page 39 Z890 Taichi USB 3.2 Gen1 Headers Right Angle: (19-pin USB32_9_10) (see p.7, No. 15) Vertical: (19-pin USB32_11_12) (see p.7, No. 14) There are two headers on this motherboard. Each USB 3.2 Gen1 header can support two ports. USB32_11_12 Vbus Vbus...
  • Page 40 Front Panel Type C USB 3.2 Gen2x2 Header (20-pin USB32_TC1) (see p.7, No. 13) There is one Front Panel Type C USB 3.2 Gen2x2 Header on this motherboard. This header is used for connecting a USB 3.2 Gen2x2 module for additional USB 3.2 Gen2x2 ports.
  • Page 41 Z890 Taichi Front Panel Audio Header (9-pin HD_AUDIO1) (see p.7, No. 32) This header is for connecting audio devices to the front audio panel. HD_AUDIO1 PRESENCE# MIC_RET OUT_RET OUT2_L J_SENSE OUT2_R MIC2_R MIC2_L High Definition Audio supports Jack Sensing, but the panel wire on the chassis must sup- port HDA to function correctly.
  • Page 42 Chassis Fan Connectors (4-pin CHA_FAN1) (see p.7, No. 20) (4-pin CHA_FAN2) (see p.7, No. 21) (4-pin CHA_FAN3) (see p.7, No. 22) (4-pin CHA_FAN4) (see p.7, No. 33) This header allows you to connect Case or Radiator fan. If you plan to connect a 3-pin fan, please connect it to Pin 1-3.
  • Page 43 Z890 Taichi CPU Fan Connector (4-pin CPU_FAN1) (see p.7, No. 3) This header allows you to connect CPU fan. If you plan to connect a 3-pin fan, please connect it to Pin 1-3. CPU_FAN1 +12V CPU_F AN_SPEED FAN_SPEED_CONTROL CPU Fan Connector (4-pin CPU_FAN2) (see p.7, No.
  • Page 44 Water Pump Fan Connector (4-pin W_PUMP) (see p.7, No. 19) This header allows you to connect Water Pump or fan. If you plan to connect a 3-pin fan, please connect it to Pin 1-3. W_PUMP FAN_VOLTAGE W_PUMP_FAN_SPEED FAN_SPEED_CONTROL AIO Pump Fan Connector (4-pin AIO_PUMP) (see p.7, No.
  • Page 45 Z890 Taichi ATX Power Connector (24-pin ATXPWR1) (see p.7, No. 12) This motherboard provides a 24-pin ATX power connector. To use a 20-pin ATX power supply, please plug it along Pin 1 and Pin 13. ATXPWR1...
  • Page 46 ATX 12V Power Connectors (8-pin ATX12V1) (see p.7, No. 1) (8-pin ATX12V2) (see p.7, No. 2) This motherboard provides two 8-pin ATX 12V power connectors. To use a 4-pin ATX power supply, please plug it along Pin 1 and Pin 5. *Connecting an ATX 12V 8-pin cable to ATX12V2 is optional.
  • Page 47 Z890 Taichi Thermistor Cable Headers (2-pin T_SENSOR1) (see p.7, No. 23) (2-pin T_SENSOR2) (see p.7, No. 24) (2-pin T_SENSOR3) (see p.7, No. 25) The Thermistor Cable Headers are used to connect thermistor cables to monitor the temperature of the critical components. Plug the thermistor cables that come with the package to these headers, and then attach the sensor ends to the components to detect their temperature.
  • Page 48 SPI TPM Header (13-pin SPI_TPM_J1) (see p.7, No. 26) This connector supports SPI Trusted Platform Module (TPM) system, which can securely store keys, digital certificates, passwords, and data. A TPM system also helps enhance network security, protects digital identities, and ensures platform integrity. SPI_TPM_J1 SPI_DQ3 SPI_PWR...
  • Page 49 Z890 Taichi RGB LED Header (4-pin RGB_LED1) (see p.7, No. 31) This RGB header is used to connect RGB LED extension cable which allow users to choose from various LED lighting effects. Caution: Never install the RGB LED cable in the wrong orientation; otherwise, the cable may be damaged.
  • Page 50 Addressable LED Headers (3-pin ADDR_LED1) (see p.7, No. 30) (3-pin ADDR_LED2) (see p.7, No. 9) (3-pin ADDR_LED3) (see p.7, No. 8) These headers are used to connect Addressable LED extension cables which allow users to choose from various LED lighting effects. Caution: Never install the Addressable LED cable in the wrong orientation;...
  • Page 51 Z890 Taichi 1. Never install the Addressable LED cable in the wrong orientation; otherwise, the cable may be damaged. 2. Before installing or removing your Addressable LED cable, please power off your system and unplug the power cord from the power supply. Failure to do so may cause damages to motherboard components.

  • Page 52: Smart Buttons

    2.12 Smart Buttons The motherboard has four smart switches: Power Button, Reset Button, Clear CMOS Buttons and BIOS Flashback Button, allowing users to quickly turn on/off the system, reset the system, clear the CMOS values or flash the BIOS. Power Button (PWRBTN1) (see p.7, No.
  • Page 53 Z890 Taichi Clear CMOS Button (CLRCMOS1) (see p.9, No. 13) Clear CMOS Button allows users to quickly clear the CMOS values. CLRCMOS1 This function is workable only when you power off your computer and unplug the power supply.
  • Page 54 BIOS Flashback Button (BIOS_FB) (see p.9, No. 1) BIOS Flashback Button allows users to flash the BIOS. BIOS_FB...
  • Page 55 Z890 Taichi ASRock BIOS Flashback feature allows you to update BIOS without powering on the system, even without CPU. Before using the BIOS Flashback function, please suspend BitLocker and any encryption or security relying on the TPM. Make sure that you have already stored and backup-ed the recovery key.
  • Page 56 USB BIOS Flashback port...
  • Page 57 Z890 Taichi 2.13 Dr. Debug Dr. Debug is used to provide code information, which makes troubleshooting even easier. Please see the diagrams below for reading the Dr. Debug codes. Code Description 0x10 PEI_CORE_STARTED 0x11 PEI_CAR_CPU_INIT 0x15 PEI_CAR_NB_INIT 0x19 PEI_CAR_SB_INIT 0x31...
  • Page 58 0x63 DXE_CPU_INIT 0x68 DXE_NB_HB_INIT 0x69 DXE_NB_INIT 0x6A DXE_NB_SMM_INIT 0x70 DXE_SB_INIT 0x71 DXE_SB_SMM_INIT 0x72 DXE_SB_DEVICES_INIT 0x78 DXE_ACPI_INIT 0x79 DXE_CSM_INIT 0x90 DXE_BDS_STARTED 0x91 DXE_BDS_CONNECT_DRIVERS 0x92 DXE_PCI_BUS_BEGIN 0x93 DXE_PCI_BUS_HPC_INIT 0x94 DXE_PCI_BUS_ENUM 0x95 DXE_PCI_BUS_REQUEST_RESOURCES 0x96 DXE_PCI_BUS_ASSIGN_RESOURCES 0x97 DXE_CON_OUT_CONNECT 0x98 DXE_CON_IN_CONNECT...
  • Page 59 Z890 Taichi 0x99 DXE_SIO_INIT 0x9A DXE_USB_BEGIN 0x9B DXE_USB_RESET 0x9C DXE_USB_DETECT 0x9D DXE_USB_ENABLE 0xA0 DXE_IDE_BEGIN 0xA1 DXE_IDE_RESET 0xA2 DXE_IDE_DETECT 0xA3 DXE_IDE_ENABLE 0xA4 DXE_SCSI_BEGIN 0xA5 DXE_SCSI_RESET 0xA6 DXE_SCSI_DETECT 0xA7 DXE_SCSI_ENABLE 0xA8 DXE_SETUP_VERIFYING_PASSWORD 0xA9 DXE_SETUP_START 0xAB DXE_SETUP_INPUT_WAIT 0xAD DXE_READY_TO_BOOT 0xAE DXE_LEGACY_BOOT...
  • Page 60 0xAF DXE_EXIT_BOOT_SERVICES 0xB0 RT_SET_VIRTUAL_ADDRESS_MAP_BEGIN 0xB1 RT_SET_VIRTUAL_ADDRESS_MAP_END 0xB2 DXE_LEGACY_OPROM_INIT 0xB3 DXE_RESET_SYSTEM 0xB4 DXE_USB_HOTPLUG 0xB5 DXE_PCI_BUS_HOTPLUG 0xB6 DXE_NVRAM_CLEANUP 0xB7 DXE_CONFIGURATION_RESET 0xF0 PEI_RECOVERY_AUTO 0xF1 PEI_RECOVERY_USER 0xF2 PEI_RECOVERY_STARTED 0xF3 PEI_RECOVERY_CAPSULE_FOUND 0xF4 PEI_RECOVERY_CAPSULE_LOADED 0xE0 PEI_S3_STARTED 0xE1 PEI_S3_BOOT_SCRIPT 0xE2 PEI_S3_VIDEO_REPOST...
  • Page 61 Z890 Taichi 0xE3 PEI_S3_OS_WAKE 0x50 PEI_MEMORY_INVALID_TYPE 0x53 PEI_MEMORY_NOT_DETECTED 0x55 PEI_MEMORY_NOT_INSTALLED 0x57 PEI_CPU_MISMATCH 0x58 PEI_CPU_SELF_TEST_FAILED 0x59 PEI_CPU_NO_MICROCODE 0x5A PEI_CPU_ERROR 0x5B PEI_RESET_NOT_AVAILABLE 0xD0 DXE_CPU_ERROR 0xD1 DXE_NB_ERROR 0xD2 DXE_SB_ERROR 0xD3 DXE_ARCH_PROTOCOL_NOT_AVAILABLE 0xD4 DXE_PCI_BUS_OUT_OF_RESOURCES 0xD5 DXE_LEGACY_OPROM_NO_SPACE 0xD6 DXE_NO_CON_OUT 0xD7 DXE_NO_CON_IN...
  • Page 62 0xD8 DXE_INVALID_PASSWORD 0xD9 DXE_BOOT_OPTION_LOAD_ERROR 0xDA DXE_BOOT_OPTION_FAILED 0xDB DXE_FLASH_UPDATE_FAILED 0xDC DXE_RESET_NOT_AVAILABLE 0xE8 PEI_MEMORY_S3_RESUME_FAILED 0xE9 PEI_S3_RESUME_PPI_NOT_FOUND 0xEA PEI_S3_BOOT_SCRIPT_ERROR 0xEB PEI_S3_OS_WAKE_ERROR...
  • Page 63 Z890 Taichi 2.14 M.2 SSD Installation Guide (M2_1) The M.2 is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Blazing M.2 Socket (M2_1, Key M) supports type 2280 PCIe Gen5x4 (128 Gb/s) mode.
  • Page 64 Step 3 Push and hold the button on the M.2 heatsink (A). Then lift up the heatsink (B) and move it in the direction shown (C). *Please remove the protective films on the bottom side of the M.2 heatsink before you install a M.2 SSD.
  • Page 65 Z890 Taichi Step 6 Hook the tab of the M.2 heatsink back onto the standoff. Step 7 Press the M.2 heatsink down into place. *Be sure not to press down the button on the M.2 heatsink. Step 8 Complete. For the latest updates of M.2 SSD support list, please visit our website for details: http://...
  • Page 66 2.15 M.2 SSD Installation Guide (M2_2, M2_4, M2_5 and M2_6) The M.2 is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Hyper M.2 Sockets (M2_2, M2_4, M2_5 and M2_6, Key M) support type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode.
  • Page 67 Z890 Taichi Step 3 Push and hold the button on the M.2 heatsink (A). Then lift up the heatsink (B) and move it in the direction shown (C). *Please remove the protective films on the bottom side of the M.2 heatsink before you install a M.2 SSD.
  • Page 68 Step 8 Press the M.2 heatsink down into place. *Be sure not to press down the button on the M.2 heatsink. Step 9 Complete. For the latest updates of M.2 SSD support list, please visit our website for details: http:// www.asrock.com...
  • Page 69 Z890 Taichi 2.16 M.2 SSD Installation Guide (M2_3) The M.2 is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Hyper M.2 Socket (M2_3, Key M) supports type 2230/2242/2260/2280 SATA3 6.0 Gb/s & PCIe Gen4x4 (64 Gb/s) modes.
  • Page 70 Step 3 Push and hold the button on the M.2 heatsink (A). Then lift up the heatsink (B) and move it in the direction shown (C). *Please remove the protective films on the bottom side of the M.2 heatsink before you install a M.2 SSD.
  • Page 71 Z890 Taichi Step 6 Prepare the M.2 screw that comes with the package, and tighten the screw with a screwdriver to secure the M.2 SSD into place. Please do not overtighten the screw as this might NUT2 NUT1 damage the M.2 SSD.
  • Page 72 Step 10 Complete. For the latest updates of M.2 SSD support list, please visit our website for details: http:// www.asrock.com...

  • Page 73: Copyright Notice

    ASRock does not provide warranty of any kind, either expressed or implied, including but not limited to the implied warranties or conditions of merchantability or fitness for a particular purpose. In no event shall ASRock, its directors, officers, employees, or agents be liable for any indirect, special, incidental, or consequential...
  • Page 74 INTEL END USER SOFTWARE LICENSE AGREEMENT IMPORTANT - READ BEFORE COPYING, INSTALLING OR USING. LICENSE. Licensee has a license under Intel’s copyrights to reproduce Intel’s Software only in its unmodified and binary form, (with the accompanying documentation, the “Software”) for Licensee’s personal use only, and not commercial use, in connection with Intel-based products for which the Software has been provided, subject to the following conditions: (a) Licensee may not disclose, distribute or transfer any part of the Software, and You agree...
  • Page 75 U.S. GOVERNMENT RESTRICTED RIGHTS. The Software is a commercial item (as defined in 48 C.F.R. 2.101) consisting of commercial computer software and commercial computer software documentation (as those terms are used in 48 C.F.R. 12.212), consistent with 48 C.F.R. 12.212 and 48 C.F.R 227.7202-1 through 227.7202-4. You will not provide the Software to the U.S.

  • Page 76: Fcc Compliance Statement

    FCC Compliance Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 77 ASRock follows the green design concept to design and manufacture our products, and makes sure that each stage of the product life cycle of ASRock product is in line with global environmental regulations. In addition, ASRock disclose the relevant information based on regulation requirements.
  • Page 78 If you require assistance please call ASRock Tel : +886-2-28965588 ext.123 (Standard International call charges apply)
  • Page 79 European Community Radio Equipment Directive Compliance Statement This device complies with directive 2014/53/EU issued by the Commision of the European Community. This equipment complies with EU radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator &...
  • Page 81 BSMI 限用物質及元素清單 限用物質及其化學符號 單元 鉛 (Pb) 鎘 (Cd) 汞 (Hg) 六價鉻 (Cr ) 多溴聯苯 (PBB) 多溴聯苯醚 (PBDE) 電路板 電子元件 線材 配件 備考 1.〝超出 0.1 wt %〞及〝超出 0.01 wt %〞係指限用物質之百分比含量超出百分比含 量基準值。 備考 2.〝○〞係指該項限用物質之百分比含量未超出百分比含量基準值。 備考 3.〝－〞係指該項限用物質為排除項目。...
  • Page 82 China RoHS 电子信息产品污染控制标示 依据中国发布的「电子信息产品污染控制管理办法」及 SJ/T 11364-2014「电子信息 产品污染控制标示要求」，电子信息产品应进行标示，藉以向消费者揭露产品中含有 的有毒有害物质或元素不致发生外泄或突变从而对环境造成污染或对人身、财产造成 严重损害的期限。依上述规定，您可于本产品之印刷电路板上看见图一之标示。图一 中之数字为产品之环保使用期限。由此可知此主板之环保使用期限为 10 年。 图一 有毒有害物质或元素的名称及含量说明 若您欲了解此产品的有毒有害物质或元素的名称及含量说明，请参照以下表格及说明。 有害物质或元素 部件名称 铅 (Pb) 镉 (Cd) 汞 (Hg) 六价铬 (Cr(VI)) 多溴联苯 (PBB) 多溴二苯醚 (PBDE) 印刷电路板 及电子组件 外部信号连 接头及线材 以上表格依据 SJ/T 11364-2014 的规定编制。 O: 表示该有害物质在该部件所有均质材料中的含量均在 GB/T 26572 规定的限量要求以下。 X: 表示该有害物质至少在该部件的某一均质材料中的含量超出...
