Page 1 DI-808HV D-Link Broadband VPN Router Manual Building Networks for People 10/11/04...
Page 2: Table Of Contents
Contents Package Contents ................3 Introduction....................4 Getting Started ..................10 Using the Configuration Menu.............. 11 Networking Basics ................72 Reset to Factory Default Settings ............98 Technical Specifications ..............99 Frequently Asked Questions ..............100 Contacting Technical Support ............149 Warranty ....................150 Registration ..................153...
Page 3: Contents Of Package
Quick Installation Guide Note: Using a power supply with a different voltage rating than the one included with the DI-808HV will cause damage and void the warranty for this product. If any of the above items are missing, please contact your reseller.
Page 4: Introduction
Introduction The D-Link DI-808HV is a 8-port Broadband Router with Virtual Private Network (VPN) functionality. It provides a complete solution for Internet and office resource sharing, and secure access to remote corporate networks. It is an ideal way to extend the number and reach of computers connected to your network.
Page 5 Unwanted packets from outside intruders can be blocked to protect your network DHCP server supported All of the networked computers can retrieve TCP/IP settings automatically from the DI-808HV Web-based configuration Configurable through any networked computer’s web browser using Netscape or Internet Explorer...
Page 6: Introduction To Broadband Router Technology
You can define the attributes, for instance opening special ports to allow packets to come through, to support special applications requiring multiple connections, such as Internet gaming, video conferencing, and Internet telephony. The DI-808HV can sense the application type and open a multi- port tunnel for it. DMZ Host supported Allows a networked computer to be fully exposed to the Internet;...
Page 7: Introduction To Local Area Networking
Introduction to Firewalls A firewall is a device that sits between your computer and the Internet that prevents unauthorized access to or from your network. A firewall can be a computer using firewall software or a special piece of hardware built specifically to act as a firewall. In most circumstances, a firewall is used to prevent unauthorized Internet users from accessing private networks or corporate LANs and Intranets.
Page 8: Introduction To Virtual Private Networking
Introduction to Virtual Private Networking Virtual Private Networking (VPN) uses a publicly wired network (the Internet) to se- curely connect two different networks through a secure “data tunnel.” For example, an employee can access a corporate network from home using VPN, allowing the em- ployee to access files, databases, and other networked resources.
Page 9 LEDS stands for Light-Emitting Diode. The DI-808HV has the following LEDs as described below: LED Activity A steady light indicates a connection to a Power power sourcea power source Flashes once per second to indicate an M1 LED active system...
Page 10: Getting Started
Consult with your Cable or DSL provider for proper installation of the modem. Connect the Cable or DSL modem to the DI-808HV wireless broadband router (see the Quick Installation Guide included with the DI-808HV.) If you are connecting a desktop computer to your network and you need an Ethernet connection, you can install the D-Link DFE-530TX+ Ethernet adapter into an available PCI slot.
Page 11: Using The Configuration Menu
Type in the IP Address of http://192.168.0.1 the DI-808HV (http://192.168.0.1) Note: If you have changed the default IP Address assigned to the DI-808HV, make sure to enter the correct IP Address. The factory default User name is admin and the default Password is blank (empty).
Page 12 Using the Configuration Menu Setup Wizard Once you have logged in, the Home screen will appear. Click Run Wizard The welcome screen outlines the steps to complete the setup wizard. Click Next to continue. Click Next...
Page 13 Using the Configuration Menu Setup Wizard > Set Password Click Next Old Password- This information is masked. New Password- Type in the new password for the admin account. Type in the new password again to confirm. Click Next to Reconfirm- continue with the Setup Wizard.
Page 14 Select the appropriate time zone for your location- Select the proper time zone. Selections can be made by clicking on the drop down list. Click Next to continue. Click Next Setup Wizard > Auto Detecting WAN Please wait a moment while the DI-808HV auto detects your WAN.
Page 15 Using the Configuration Menu Setup Wizard > Connection Type (WAN) Select Your Internet Connection- You will be prompted to select the type of internet connection for your router. Choose the appropriate selection and click Next to continue. Click Next If you are unsure of which setting to select, please contact your Internet Service Provider.
Page 16 (MAC) address. Note that some computer and peripherals may already include built-in network adapter. Clone MAC By clicking on Clone MAC Address, the DI-808HV will auto- matically copy the MAC address of the network adapter in your Address computer. You can also manually type in the MAC address.
Page 17 Enter the IP address infor- mation originally provided to you by your ISP. You will need to complete all the required fields. The subnet for the DI-808HV is preconfigured to 255.255.255.0. WAN Subnet Mask Configurations can be made, but are not recommended. This feature is for advanced users.
Page 18 Using the Configuration Menu Setup Wizard > PPPoE Click Next If your ISP uses PPPoE (Point-to-Point Protocol over Ethernet), and this option is se- lected, then this screen will appear: (Used mainly for DSL Internet service.) PPPoE Account Enter in the username provided to you by your ISP. PPPoE Password Enter in the password provided to you by your ISP.
Page 19 Using the Configuration Menu Setup Wizard > Dial-up Network Click Next Configure this section only if you have an analog dial-up account. Otherwise click Next to skip. Dial-up Enter the telephone number to connect to your ISP. Telephone This information is provided by your ISP. The Dial-up Account is Dial-up Account also known as username.
Page 20 Using the Configuration Menu Setup Wizard > Others Click Next Select the connection type to connect to your ISP. Choose the appropriate selection and click Next to continue. PPTP This is a WAN connection used in Europe. BigPond Cable This is a WAN connection used in Australia.
Page 21 Enter the IP address information originally provided to you by your ISP. You will need to complete all the required fields. The subnet for the DI-808HV is preconfigured to 255.255.255.0. My Subnet Mask Configurations can be made, but are not recommended. This feature is for advanced users.
Page 22 Using the Configuration Menu Setup Wizard > Others > BigPond Cable Click Next If your ISP uses BigPond Cable (Point-to-Point Protocol over Ethernet), and this option is selected, then this screen will appear: (Used for Internet service in Australia.) Account Enter in the username provided to you by your ISP.
Page 23 Using the Configuration Menu Setup Wizard Click Restart Back Click on the Back button to go back to previous page. Restart Click on the Restart button to finalize the settings made. Click on the Exit button to end the Setup Wizard without saving Exit any changes.
Page 24 Using the Configuration Menu Home > WAN Choose WAN Type WAN stands for Wide Area Network. In this case, WAN represents the mode in which you connect to the Internet. If you are uncertain, please ask your ISP which of the following represents your connection mode to the Internet: Dynamic Obtain an IP address from your ISP automatically (mainly for...
Page 25 Using the Configuration Menu Home > WAN > Dynamic IP Address Most cable modem users will select this option to obtain an IP Address automatically from their ISP (Internet Service Provider). This is optional, but may be required by some ISPs. The host Host Name name is the device name of the Router.
Page 26 Using the Configuration Menu Home > WAN > Static IP Address If you use a Static IP Address, you will input information here that your ISP has provided to you. IP Address Input the IP Address provided by your ISP Input the Subnet Mask provided by your ISP Subnet Mask ISP Gateway...
Page 27 Using the Configuration Menu Home > WAN > PPPoE Most DSL users will select this option to obtain an IP address automatically from their ISP through the use of PPPoE. User Name Your PPPoE username provided by your ISP Your PPPoE password is provided by your ISP Password Service Name (Optional) Check with your ISP for more information if they...
Page 28 ISP and your analog dial-up modem. (Initializa- tion string) - optional. Maximum Idle Time Enter a maximum idle time during which Internet connection is maintained during inactivity. To disable this feature, en- able Auto-reconnect. Baud Rate The communication speed between the DI-808HV and your modem.
Page 29 Using the Configuration Menu Home > WAN > PPTP Point-to-Point Tunneling Protocol (PPTP) is a WAN connection used in Europe and Russia. My IP Address Enter the IP Address My Subnet Mask Enter the Subnet Mask Server IP Address Enter the Server IP Address PPTP Account Enter the PPTP account name PPTP Password...
Page 30 Using the Configuration Menu Home > WAN > BigPond Cable Dynamic IP Address for BigPond is a WAN connection used in Australia. User Name Enter in the username for the BigPond account Enter the password for the BigPond account Password (Optional) enter the Login Server name if required Login Server IP Renew IP forever...
Page 31 Using the Configuration Menu Home > LAN LAN (Local Area Network). This is considered your internal network. These are the IP settings of the LAN interface for the DI- 808HV. These settings may be referred to as Private settings. You may change the LAN IP address if needed.
Page 32 Using the Configuration Menu Home >DHCP DHCP stands for Dynamic Host Control Protocol. The DI-808HV has a built-in DHCP server. The DHCP Server will automatically assign an IP address to the computers on the LAN/private network. Be sure to set your computers to be DHCP clients by setting their TCP/IP settings to “Obtain an IP Address Automatically.”...
Page 33 Using the Configuration Menu Home >VPN Settings VPN Settings are settings that are used to create virtual private tunnels to remote VPN gateways. The tunnel technology supports data confidentiality, data origin, authentication, and data integrity of network information by utilizing encapsulation protocols, encryption algorithms, and hashing algorithms.
Page 34 Using the Configuration Menu Home >VPN Settings > Tunnel > Method>IKE Tunnel Name Current tunnel name. Enabling this mode will accelerate establishing tunnel, but Aggressive Mode the device will have less security. The subnet of the VPN gateway’s local network. It can be a Local Subnet host, a partial subnet or a whole subnet.
Page 35 Using the Configuration Menu Home >VPN Settings > Tunnel > Method > IKE > Select IKE Proposal IKE Proposal index A list of selected proposal indexes from the IKE proposal pool listed below. Proposal Name This is the name used to classify the IKE proposal. DH Group There are three groups that can be selected: group 1 (MODP768), group 2 (MODP1024), and group 5...
Page 36 Using the Configuration Menu Home >VPN Settings > Tunnel > Method > IKE > Select IKE Proposal Continued... Enter in the life time value. Life Time Life Time Unit There are two units that can be selected: second and KB. The identifier of IKE proposal can be chosen for adding Proposal ID corresponding proposal to the dedicated tunnel.
Page 37 Using the Configuration Menu Home >VPN Settings > Tunnel > Method > IKE > Select IPSEC Proposal A list of selected proposal indexes from the IPSec proposal IPSec Proposal pool listed below. index This is the name used to classify the IPSec Proposal Proposal Name There are three groups that can be selected: group 1 DH Group...
Page 38 Using the Configuration Menu Home >VPN Settings > Tunnel > Method > IKE > Select IPSEC Proposal Continued... Enter in a life time value. Life Time Life Time Unit There are two units that can be selected: second and KB. The identifier of IPSec proposal can be chosen for adding the Proposal ID proposal to the dedicated tunnel.
Page 39 Using the Configuration Menu Home >VPN Settings > Tunnel > Manual Tunnel Name Current tunnel name. Enabling this mode will accelerate establishing tunnel, but Aggressive Mode the device will have less security. The subnet of the VPN gateway’s local network. It can be a Local Subnet host, a partial subnet, or a whole subnet.
Page 40 Using the Configuration Menu Home >VPN Settings > Tunnel > Manual Continued... Encapsulation There are two protocols that can be selected: ESP and AH. Protocol Encryption Algorithm There are two algorithms that can be selected: 3DES and DES. For DES, the encryption key is 8 bytes (16 Char.). For 3DES, Encryption Key the encryption key is 24 bytes (48 Char.).
Page 41 IKE proposals. Tunnel Name Current tunnel name. This feature works with a VPN software client so the DI-808HV Dynamic VPN does not need to know the IP address of the remote clients. Enabling this mode will accelerate establishing the tunnel, Aggressive Mode but the device will have less security.
Page 42 Using the Configuration Menu Home >VPN Settings > Dynamic VPN Tunnel Continued... The first key that supports IKE mechanism of both VPN Preshared Key gateways for negotiating further security keys. The pre- shared key must be the same for both endpoint gateways. Click the button to setup a set of frequent-used IKE IKE Proposal index proposals and select from the set of IKE proposals for the...
Page 43 Using the Configuration Menu Home >VPN Settings > Dynamic VPN Tunnel > Set IKE Proposal IKE Proposal index A list of selected proposal indexes from the IKE proposal pool listed below. Proposal Name It indicates which IKE proposal to be focused. DH Group There are three groups that can be selected: group 1 (MODP768), group 2 (MODP1024), and group 5...
Page 44 Using the Configuration Menu Home >VPN Settings > Dynamic VPN Tunnel > Set IKE Proposal Continued... Enter in the life time value. Life Time Life Time Unit There are two units that can be selected: second and KB. The identifier of IKE proposal can be chosen for adding Proposal ID corresponding proposal to the dedicated tunnel.
Page 45 Using the Configuration Menu Home >VPN Settings > Dynamic VPN Tunnel > Set IPSEC Proposal A list of selected proposal indexes from the IPSec proposal IPSec Proposal pool listed below. index This is the name used to classify the IPSec proposal. Proposal Name There are three groups that can be selected: group 1 DH Group...
Page 46 Using the Configuration Menu Home >VPN Settings > Dynamic VPN Tunnel > Set IPSEC Proposal Continued... Enter in a life time value. Life Time Life Time Unit There are two units that can be selected: second and KB. The identifier of IPSec proposal can be chosen for adding the Proposal ID proposal to the dedicated tunnel.
Page 47 Using the Configuration Menu Home >VPN Settings > L2TP Server Setting Click to enable the L2TP Server function. Enable L2TP Server Virtual IP of L2TP Enter your Virtual IP address to access the L2PT server. Server Select one of the following authentication protocols: PAP, Authentication CHAP, or MSCHAP.
Page 48 Using the Configuration Menu Home >VPN Settings >PPTP Server Setting Enable PPTP Click to enable the PPTP Server function. Server Virtual IP of PPTP Enter your Virtual IP address to access thePPPT server. Server Select one of the following authentication protocols: PAP, Authentication CHAP, or MSCHAP.
Page 49 Using the Configuration Menu Advanced > Virtual Server The DI-808HV can be configured as a virtual server so that remote users accessing Web or FTP services via the public IP address can be automatically redirected to local servers in the LAN (Local Area Network).
Page 50 Internet telephony and others. These applications have difficulty working through NAT (Network Address Translation). Special Applications makes some of these applications work with the DI-808HV. If you need to run applications that require multiple connections, specify the port normally associated with an application in the Trigger Port field, then enter the public ports associated with the trigger port into the Public Ports field.
Page 51 Using the Configuration Menu Advanced > Filter > IP Filter Use IP (Internet Protocol) filters to allow or deny computers access to the Internet based on their IP address. IP Filter Use IP Filters to deny LAN IP addresses access to the internet Enabled or Disabled Click Enabled to apply the filter policy or click Disabled to enter an inactive filter policy (You can reactivate the policy later.)
Page 52 At the bottom of the screen, there is a list of MAC addresses from the DHCP client computers connected to the DI-808HV. To use them, select one from the drop down list. Then click the “Apply” button and the DI-808HV will fill in the appropriate information to the list.
Page 53 Using the Configuration Menu Advanced > Filter > URL Blocking Use URL Blocking to deny LAN computers from accessing specific web sites by its URL. A URL is a specially formatted text string that defines a location on the Internet. If any part of the URL contains the blocked word, the site will not be accessible and the web page will not display.
Page 54 Using the Configuration Menu Advanced > Filter > Domain Blocking Use Domain Blocking to allow or deny computers access to specific Internet domains whether it is through www, ftp, snmp, etc. Disabled Domain Blocking Select this option if you do not want to use Domain Blocking. Allow users to access all domains except “Blocked Domains”...
Page 55 (You can reactivate the policy later). Name Enter the name of the Firewall Rule. Action Select Allow or Deny to allow or deny traffic to pass through the DI-808HV. Source Choose between a LAN or WAN source. An asterisk signifies the selection of both sources.
Page 56 Using the Configuration Menu Advanced > Firewall Continued IP Address Enter in the IP address range of the computers that you want the policy to apply to. If it is only a single computer that you want the policy applied to, then enter the IP address of that computer in the Start Source IP and leave the End Source IP blank.
Page 57 SNMP (Simple Network Management Protocol) is a widely used network monitoring and control protocol that reports activity on each network device to the administrator of the network. SNMP can be used to monitor traffic and statistics of the DI-808HV. The DI- 808HV supports SNMP v1 or v2c...
Page 58 DDNS (Dynamic Domain Name System) keeps dynamic IP addresses (e.g., IP addresses assigned by a DHCP capable router or server) linked to a domain name. Users who have a Dynamic DNS account may use this feature on the DI-808HV. DDNS When an IP address is automatically assigned by a DHCP server, DDNS automatically updates the DNS server.
Page 59 Using the Configuration Menu Advanced > Routing Dynamic Routing Dynamic Routing Settings allow the VPN Router to route IP packets to another network automatically. The RIP protocol is applied, and broadcasts the routing information to other routers on the network regularly. By default, it is set to disable.
Page 60 If you have a computer that cannot run Internet applications properly from behind the DI-808HV, then you can allow that computer to have unrestricted Internet access. Enter the IP address of that computer as a DMZ (Demilitarized Zone) host with unrestricted Internet access.
Page 61 Internet IP addresses to access the DI-808HV. The port number used to access the DI-808HV. Port E.g., http://x.x.x.x:8080, where x.x.x.x. is the WAN IP address of the DI-808HV and 8080 is the port used for the Web Manage- ment interface.
Page 62 Set the time here by entering it manually or use NTP (Network Time Protocol). NTP is the standard protocol on the Internet that synchronizes the time settings accurately for the DI-808HV. Select to enable NTP and synchronize the time settings on...
Page 63 The current system settings can be saved as a file onto the local hard drive. The saved file or any other saved setting file created by the DI-808HV can be uploaded into the unit. To reload a system settings file, click on Browse to search the local hard drive for the file to be used.
Page 64 Using the Configuration Menu Tools > Firmware You can upgrade the firmware by using this tool. First, check the D-Link support site for firmware updates at http://support.dlink.com. Make sure that the firmware you want to use is saved on the local hard drive of your computer. Click on Browse to search the local hard drive for the firmware that you downloaded from the D-Link website to be used for the update.
Page 65 Click Enable to block the WAN ping. Computers on the Internet Block WAN Ping will not get a reply back from the DI-808HV when it is being “ping”ed. This may help to increase security. When this feature is enabled, the router will record the packet...
Page 66 UPnP is short for Universal Plug and Play which is a networking architecture that provides compatibility among networking equip- ment, software, and peripherals. The DI-808HV is a UPnP enabled router and will only work with other UPnP devices/softwares. If you do not want to use the UPnP Functionality, it can be disabled by selecting “Disabled”.
Page 67 Using the Configuration Menu Status > Device Info This screen displays information about the DI-808HV Click to refresh IP addresses sent from the DHCP server. DHCP Renew Click to release IP addreses sent from the DHCP server. DHCP Release...
Page 68 Using the Configuration Menu Status > Log This screen displays activities occurring on the DI-808HV. First Page Click First Page to go to the first page of the log. Last Page Click Last Page to go to the last page of the log.
Page 69 Using the Configuration Menu Status > Log > Log Settings The DI-808HV can be set up to send the log files to a specific E-Mail Alert email address. SMTP Server IP Enter in the IP address of the mail server.
Page 70 Using the Configuration Menu Status > Stats In Stats section, traffic statistics are displayed. This will update the page. Refresh This will reset the packet counter to zero. Reset Displays Received / Transmitted packets from the WAN port. WAN- Displays Received / Transmitted packets from the LAN port.
Page 71 Using the Configuration Menu Help This screen displays the complete Help menu. For help at anytime, click the Help tab in the Configuration menu.
Page 72: Networking Basics
Networking Basics Using the Network Setup Wizard in Windows XP In this section you will learn how to establish a network at home or work, using Microsoft Windows XP. Note: Please refer to websites such as http://www.homenethelp.com http://www.microsoft.com/windows2000 for information about networking computers using Windows 2000, ME or 98.
Page 73 Networking Basics Please follow all the instructions in this window: Click Next In the following window, select the best description of your computer. If your computer connects to the Internet through a gateway/router, select the second option as shown. Click Next...
Page 74 Networking Basics Enter a Computer description and a Computer name (optional.) Click Next Enter a Workgroup name. All computers on your network should have the same Workgroup name. Click Next...
Page 75 Networking Basics Please wait while the Network Setup Wizard applies the changes. When the changes are complete, click Next. Please wait while the Network Setup Wizard configures the computer. This may take a few minutes.
Page 76 Networking Basics In the window below, select the option that fits your needs. In this example, Create a Network Setup Disk has been selected. You will run this disk on each of the computers on your network. Click Next. Insert a disk into the Floppy Disk Drive, in this case drive A.
Page 77 Networking Basics Please read the information under Here’s how in the screen below. After you complete the Network Setup Wizard you will use the Network Setup Disk to run the Network Setup Wizard on each of the computers on your network. To continue click Next.
Page 78 Networking Basics Please read the information on this screen, then click Finish to complete the Network Setup Wizard. The new settings will take effect when you restart the computer. Click Yes to restart the computer. You have completed configuring this computer. Next, you will need to run the Network Setup Disk on all the other computers on your network.
Page 79 Networking Basics Naming your Computer To name your computer, please follow these directions: In Windows XP: Click Start (in the lower left corner of the screen) Right-click on My Computer Select Properties and click Select the Computer Name Tab in the System Properties window.
Page 80: Checking The Ip Address In Windows Xp
Networking Basics Naming your Computer In this window, enter the Computer name Select Workgroup and enter the name of the Workgroup All computers on your network must have the same Workgroup name. Click OK Checking the IP Address in Windows XP The wireless adapter-equipped computers in your network must be in the same IP ad- dress range (see Getting Started in this manual for a definition of IP address range).
Page 81 Networking Basics Checking the IP Address in Windows XP This window will appear. Click the Support tab Click Close Assigning a Static IP Address in Windows XP/2000 Note: Residential gateways/broadband routers will automatically assign IP addresses to the computers on the network, using DHCP (Dynamic Host Configuration Proto- col) technology.
Page 82 Networking Basics Assigning a Static IP Address in Windows XP/2000 Double-click on Network Connections Right-click on Local Area Connections Click on Properties...
Page 83 IP Address: e.g., 192.168.0.2 Subnet Mask: 255.255.255.0 Enter the LAN IP address of the wireless router. (D-Link wireless routers have a LAN IP address of 192.168.0.1) 192 168 Select Use the following DNS server addresses. Enter the LAN IP address of 192 168 the wireless router.
Page 84 Networking Basics Assigning a Static IP Address with Macintosh OSX Go to the Apple Menu and se- lect System Preferences cClick on Network Select Built-in Ethernet in the Show pull-down menu Select Manually in the Con- figure pull-down menu Input the Static IP Address, the Subnet Mask, and the Router IP Address in the ap- propriate fields...
Page 85 Networking Basics Selecting a Dynamic IP Address with Macintosh OSX Go to the Apple Menu and select System Preferences Click on Network Select Built-in Ethernet in the Show pull-down menu Select Using DHCP in the Configure pull-down menu Click Apply Now The IP Address, Subnet mask, and the Router’s IP Address will appear in a few...
Page 86: Adding A Local Printer
Networking Basics Adding and Sharing Printers in Windows XP After you have run the Network Setup Wizard on all the computers in your network (please see the Network Setup Wizard section at the beginning of Networking Basics), you can use the Add Printer Wizard to add or share a printer on your network. Whether you want to add a local printer (a printer connected directly to one computer), share an LPR printer (a printer connected to a print server), or share a network printer (a printer connected to your network through a gateway/router), use the Add...
Page 87 Networking Basics Adding a local printer (a printer connected directly to a computer) A printer that is not shared on the network and is connected directly to one computer is called a local printer. If you do not need to share your printer on a network, follow these directions to add the printer to one computer.
Page 88 Networking Basics Adding a local printer Click Next Select Local printer attached to this computer (Deselect Automati- cally detect and install my Plug and Play printer if it has been selected.) Click Next Select Use the follow- ing port: From the pull-down menu select the correct port for your printer (Most computers use the LPT1: port,...
Page 89 Networking Basics Adding a local printer Select and highlight the correct driver for your printer. Click Next (If the correct driver is not displayed, insert the CD or floppy disk that came with your printer and click Have Disk.) At this screen, you can change the name of the printer (optional).
Page 90 Networking Basics Adding a local printer This screen gives you information about your printer. Click Finish When the test page has printed, Click OK...
Page 91: Sharing A Network Printer
Networking Basics Adding a local printer Go to Start> Printers and Faxes A successful installation will display the printer icon as shown at right. You have successfully added a local printer. Sharing a network printer After you have run the Network Setup Wizard on all the computers on your network, you can run the Add Printer Wizard on all the computers on your network.
Page 92 Networking Basics Sharing a network printer Click on Add a printer Click Next Select Network Printer Click Next...
Page 93 Networking Basics Sharing a network printer Select Browse for a printer Click Next Select the printer you would like to share Click Next Click Finish...
Page 94 Networking Basics Sharing a network printer To check for proper installation: Go to Start > Printers and Faxes The printer icon will appear at right, indicating proper installation. You have completed adding the printer. To share this printer on your network: Remember the printer name Run the Add Printer...
Page 95 Networking Basics Sharing an LPR printer To share an LPR printer (using a print server,) you will need a Print Server such as the DP-101P+. Please make sure that you have run the Network Setup Wizard on all the computers on your network. To share an LPR printer, please follow these directions: Go to Start >...
Page 96 Networking Basics Sharing an LPR printer This screen will show you information about your printer. Click Finish Select the printer you are adding from the list of Printers. Insert the printer driver disk that came with your printer. Click Have Disk If the printer driver is already installed, do the following: Select Keep existing...
Page 97 Networking Basics Sharing an LPR printer You can rename your printer if you choose. It is optional. Please remember the name of your printer. You will need this information when you use the Add Printer Wizard on the other computers on your network.
Page 98 After you have tried other methods for troubleshooting your network, you may choose to Reset the DI-808HV to the factory default settings. To hard-reset the D-Link DI-808HV to the Factory Default Settings, please do the following: Locate the Reset button on the back of the DI-808HV.
Page 99: Technical Specifications
Technical Specifications Standards IEEE 802.3 10BASET-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.3x Flow Control ANSI/IEEE 802.3 NWay auto-negotiation VPN Pass Through Function PPTP L2TP IPSec Device Management Web-Based – Internet Explorer 6x or later; Netscape Navigator 6x or later;...
Page 100: Frequently Asked Questions
Frequently Asked Questions Why can´t I access the Web-based configuration? When entering the IP Address of the DI-808HV (192.168.0.1), you are not connecting to the Internet or have to be connected to the Internet. The device has the utility built- in to a ROM chip in the device itself.
Page 101 Frequently Asked Questions (continued) Why can´t I access the Web-based configuration? (continued) What type of cable should I be using? (continued) What´s the difference between a crossover cable and a straight-through cable? The wiring in crossover and straight-through cables are different. The two types of cable have different purposes for different LAN configurations.
Page 102 Frequently Asked Questions (continued) Why can´t I access the Web-based configuration? (continued) Step 2 Disable any Internet security software running on the computer. Software firewalls like Zone Alarm, Black Ice, Sygate, Norton Personal Firewall, etc. might block access to the configuration pages. Check the help files included with your firewall software for more information on disabling or configuring it.
Page 103 Step 4 Check your IP address. Your computer must have an IP address in the same range of the device you are attempting to configure. Most D-Link devices use the 192.168.0.X range. How can I find my IP Address in Windows 95, 98, or Step 1 Click on Start, then click on Run.
Page 104 Step 4 (continued) Check your IP address. Your computer must have an IP Address in the same range of the device you are attempting to configure. Most D-Link devices use the 192.168.0.X range. How can I find my IP Address in Windows 2000/XP? Step 1 Click on Start and select Run.
Page 105 Step 4 (continued) Check your IP address. Your computer must have an IP address in the same range of the device you are attempting to configure. Most D-Link devices use the 192.168.0.X range. Make sure you take note of your computer´s Default Gateway IP Address. The Default Gateway is the IP Address of the D-Link Router.
Page 106 Frequently Asked Questions (continued) Why can´t I access the Web-based configuration? (continued) How can I assign a Static IP Address in Windows 2000? (continued) Click Use the following IP Address and enter an IP Address that is on the same subnet as the LAN IP address on your router.
Page 107 Step 5 Access the Web management. Open your Web browser and enter the IP Address of your D-Link device in the address bar. This should open the log-in page for the web management. Follow instructions to log in and complete the configuration.
Page 108 Frequently Asked Questions (continued) How can I setup my DI-808HV to work with a cable modem connection? Dynamic Cable connection (i.e. Cox, Adelphia, Rogers, Roadrunner, Charter, and Comcast). Note: Please configure the router with the computer that was last connected directly to the cable modem.
Page 109: Static Cable Connection
Frequently Asked Questions (continued) How can I setup my DI-808HV to work with a cable modem connection? (continued) Step 3 Power cycle the cable modem and router: First turn the cable modem off. Then turn the router off Leave them off for 2 minutes.** Next turn the cable modem on.
Page 110 Frequently Asked Questions (continued) How can I setup my DI-808HV to work with Earthlink DSL or any PPPoE connection? Make sure you disable or uninstall any PPPoE software such as WinPoet or Enternet 300 from your computer or you will not be able to connect to the Internet.
Page 111 Step 9 Turn off your DSL modem for 2-3 minutes. Turn back on. Once the modem has established a link to your ISP, plug the power back into the D-Link Router. Wait about 30 seconds and log back into the router.
Page 112 Frequently Asked Questions (continued) I have two DI-808HV Routers, how can I set them up to work with each other? Step 1 Log into the web based configuration of the router by typing in the IP address of the router (default: 192.168.0.1) in your web browser.
Page 113 Frequently Asked Questions (continued) I have two DI-808HV Routers, how can I set them up to work with each other?(continued) Step 4 In the Local Subnet and Local Netmask fields enter the network identifier for the local DI-808HV´s LAN and the corresponding subnet mask.
Page 114 Frequently Asked Questions (continued) I have two DI-808HV Routers, how can I set them up to work with each other? (continued) Step 8 The device will restart. Click on the Continue button. Step 9 Click on Select IKE Proposal. Step 10...
Page 115 Frequently Asked Questions (continued) I have two DI-808HV Routers, how can I set them up to work with each other?(continued) Step 11 Select DES or 3DES as the Encryption Algorithm. Step 12 Select SHA-1 or MD5 as the Authentication Algorithm.
Page 116 Frequently Asked Questions (continued) I have two DI-808HV Routers, how can I set them up to work with each other? (continued) Step 14 Select 1 out of the Proposal ID dropdown menu and click Add To, which will add the proposal that was just configured to the IKE Proposal Index.
Page 117 Frequently Asked Questions (continued) I have two DI-808HV Routers, how can I set them up to work with each other?(continued) Step 17 Enter a name for proposal ID number 1 and select Group 1, 2, 5, or None from the DH Group dropdown menu.
Page 118 Frequently Asked Questions (continued) I have two DI-808HV Routers, how can I set them up to work with each other? (continued) Step 20 Select SHA-1, MD5, or None as the Authentication Algorithm. Step 21 Enter a Lifetime value and then either select Sec.
Page 119 IKE Proposal and the IPSec Proposal. Also make sure that Step 4 is configured to reflect the LAN settings for what is now the Local DI-808HV and that Steps 5 & 6 are configured to reflect the Subnet and WAN IP of what is now...
Page 120 Frequently Asked Questions (continued) How can I set up my DI-808HV to work with a DI-804V or DI-804HV Router? (continued) Step 3 In the space provided, enter the Tunnel Name for ID number 1, select IKE, and then click More.
Page 121 Frequently Asked Questions (continued) How can I set up my DI-808HV to work with a DI-804V or DI-804HV Router? (continued) Step 6 The device will restart. Click on the Continue button. Step 7 In the Remote Gateway field enter the WAN IP address of the remote...
Page 122 Frequently Asked Questions (continued) How can I set up my DI-808HV to work with a DI-804V or DI-804HV Router? (continued) Step 12 Select 1 out of the Proposal ID dropdown menu and click Add To, which will add the proposal that was just configured to the IKE Proposal Index.
Page 123 Frequently Asked Questions (continued) How can I set up my DI-808HV to work with a DI-804V or DI-804HV Router? (continued) Step 17 Select 3DES as the Encryption Algorithm and MD5 as the Authentication Algorithm. Click Apply. Step 18 Enter a Lifetime value of 3600 and then select Sec.
Page 124 Frequently Asked Questions (continued) How can I set up my DI-808HV to work with a DI-804V or DI-804HV Router? (continued) Next you need to configure the DI-804V or DI-804HV Router. Step 1 Access the router’s web configuration by entering the router’s IP address in your web browser.
Page 125 Frequently Asked Questions (continued) How can I set up my DI-808HV to work with a DI-804V or DI-804HV Router? (continued) Step 10 Verify the Encryption Protocol is set to 3DES and enter in your Preshared Key. Note: The Preshared Key needs to be identical to the one configured on the DI-808HV.
Page 126 Step 5 When the VPN has been established the Status will be Active. How can I set up my DI-808HV to work with a DFL-300 Firewall? You need to first configure your DI-808HV router. Step 1 Log into the web based configuration of the router by typing in the IP address of the router (default: 192.168.0.1) in your web browser.
Page 127 Frequently Asked Questions (continued) How can I set up my DI-808HV to work with a DFL-300 Firewall? (continued) Step 3 In the space provided, enter the Tunnel Name for ID number 1, select IKE, and then click More. Step 4...
Page 128 Frequently Asked Questions (continued) How can I set up my DI-808HV to work with a DFL-300 Firewall? (continued) Step 6 In the Remote Gateway field enter the WAN IP address of the remote DFL-300 and in the Preshared Key field,...
Page 129 Frequently Asked Questions (continued) How can I set up my DI-808HV to work with a DFL-300 Firewall? (continued) Step 11 Select 1 out of the Proposal ID dropdown menu and click Add To, which will add the proposal that was just configured to the IKE Proposal Index.
Page 130 Frequently Asked Questions (continued) How can I set up my DI-808HV to work with a DFL-300 Firewall? (continued) Step 17 Select 1 out of the Proposal ID dropdown menu and click Add To, which will add the proposal that was just configured to the IPSec Proposal Index.
Page 131 Frequently Asked Questions (continued) How can I set up my DI-808HV to work with a DFL-300 Firewall? (continued) Step 4 Click on Policy and verify that you have an Outgoing policy configured. If not, click on New Entry, accept the default values, and click OK.
Page 132 Frequently Asked Questions (continued) How can I set up my DI-808HV to work with a DFL-300 Firewall? (continued) After you have configured both the router and firewall, you need to establish a connection. Step 1 Open a command prompt and...
Page 133 Frequently Asked Questions (continued) How do I open ports on my DI-808HV? To allow traffic from the internet to enter your local network, you will need to open up ports or the router will block the request. Step 1 Open your Web browser and enter the IP Address of your D-Link router (192.168.0.1).
Page 134 DMZ hosts security, the Web pages might be corrupted but no other company information would be exposed. D-Link, a leading maker of routers, is one company that sells products designed for setting up...
Page 135 Frequently Asked Questions (continued) How do I configure the DMZ Host? (continued) Step 2 Log into the web based configuration DI-624 DI-624 DI-624 DI-624 DI-624 of the router by typing in the IP Address of the router (default:192.168.0.1) in your web browser.
Page 136 Frequently Asked Questions (continued) How do I open a range of ports on my DI-808HV using Firewall rules? Step 1 Access the router’s web configuration by entering the router’s IP Address in your web browser. The default IP Address is 192.168.0.1. Login using your password.
Page 137 192.168.0.7 How do I use PC Anywhere with my DI-808HV? You will need to open 3 ports in the Virtual Server section of your D-Link router. Step 1 Open your web browser and enter the IP Address of the router (192.168.0.1).
Page 138 Frequently Asked Questions (continued) How do I use PC Anywhere with my DI-808HV? (continued) Step 6 Create a second entry as shown here: pcanywhere2 Step 7 Click Apply and then click Continue. Step 8 Create a third and final entry as shown here:...
Page 139 Frequently Asked Questions (continued) How can I use eDonkey behind my DI-808HV? You must open ports on your router to allow incoming traffic while using eDonkey. eDonkey uses three ports (4 if using CLI): 4661 (TCP) To connect with a server 4662 (TCP) To connect with other clients 4665 (UDP) To communicate with servers other than the one you are connected to.
Page 140 Frequently Asked Questions (continued) How do I set up my DI-808HV for SOCOM on my Playstation 2? To allow you to play SOCOM and hear audio, you must download the latest firmware for the router (if needed), enable Game Mode, and open port 6869 to the IP Address of your Playstation.
Page 141 Frequently Asked Questions (continued) How can I use Gamespy behind my DI-808HV? Step 1 Open your web browser and enter the IP Address of the router (192.168.0.1). Enter admin for the username and your password (blank by default). Step 2 Click on the Advanced tab and then click Virtual Server on the left side.
Page 142 Frequently Asked Questions (continued) How do I configure my DI-808HV for KaZaA and Grokster? The following is for KaZaA, Grokster, and others using the FastTrack P2P file sharing system. In most cases, you do not have to configure anything on the router or on the Kazaa software.
Page 143 Frequently Asked Questions (continued) How do I configure my DI-808HV to play Warcraft 3? To hose a Warcraft 3 game, you must open ports on your router to allow incoming traffic. To play a game, you do not have to configure your router.
Page 144 To read more on this visit http://www.HomenetHelp.com How do I set up my DI-808HV to use iChat? -for Macintosh users- You must open ports on your router to allow incoming traffic while using iChat. iChat uses the following ports: 5060 (UDP), 5190 (TCP), and File Sharing 16384-...
Page 145 Frequently Asked Questions (continued) How do I set up my DI-808HV to use iChat? -for Macintosh users- (continued) Step 3 Create a new firewall rule: Click Enabled. Enter a name (ichat1). Click Allow. Next to Source, select ichat1 WAN under interface.
Page 146 Frequently Asked Questions (continued) How do I set up my DI-808HV to use iChat? -for Macintosh users- (continued) For File Sharing: Step 1 Click on Advanced and then Virtual Server. Step 2 Check Enabled to activate entry. ichat3 Step 3...
Page 147 Frequently Asked Questions (continued) How do I send or receive a file via iChat when the Mac OSX firewall is active? -for Macintosh users- Mac OS X 10.2 and later The following information is from the online Macintosh AppleCare knowledge base: “iChat cannot send or receive a file when the Mac OS X firewall is active in its default state.
Page 148 Simply put, it is a method of connecting multiple computers to the Internet (or any other IP network) using one IP Address. D-Link´s broadband routers (ie: DI-808HV) support NAT. With proper configuration, multiple users can access the Internet using a single account via the NAT device.
Page 149: Contacting Technical Support
Contacting Technical Support You can find the most recent software and user documentation on the D-Link website. D-Link provides free technical support for customers within the United States for the duration of the warranty period on this product. U.S. customers can contact D-Link technical support through our web site, or by phone.
Page 150: Warranty
D-Link’s sole obligation shall be to repair or replace the defective Hardware during the Warranty Period at no charge to the original owner or to refund at D-Link’s sole discretion. Such repair or replacement will be rendered by D-Link at an Authorized D-Link Service Office. The replacement Hardware need not be new or have an identical make, model or part.
Page 151 D-Link may reject or return any product that is not packaged and shipped in strict compliance with the foregoing requirements, or for which an RMA number is not visible from the outside of the package. The product owner agrees to pay D-Link’s reasonable handling and return shipping charges for any product...
Page 152 Product may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from D-Link Corporation/D-Link Systems, Inc., as stipulated by the United States Copyright © Act of 1976. Contents are subject to change without prior notice. Copyright 2003 by D-Link Corporation/D-Link Systems, Inc.
Page 153: Registration
Registration Register online your D-Link product at http://support.dlink.com/register/...

D-Link DI-808HV Manual

Quick Links

Related Manuals for D-Link DI-808HV

Summary of Contents for D-Link DI-808HV

Table of Contents
