TeamC GT8L Manual

1:8 scale gp 4wd touring car
Hide thumbs

Advertisement

Quick Links

Download this manual
1:8 Scale GP 4WD TOURING CAR
Dimensions
Length
......................................................................................................630mm
Width
......................................................................................................320mm
Height
......................................................................................................160mm
All manuals and user guides at all-guides.com
GT8L

Advertisement

loading
Need help?

Need help?

Do you have a question about the GT8L and is the answer not in the manual?

Questions and answers

Related Manuals for TeamC GT8L

Summary of Contents for TeamC GT8L

  • Page 1 All manuals and user guides at all-guides.com GT8L 1:8 Scale GP 4WD TOURING CAR Dimensions Length …………………………………………………………………………………………630mm Width …………………………………………………………………………………………320mm Height …………………………………………………………………………………………160mm...

  • Page 2: Transmitter Preparation

    All manuals and user guides at all-guides.com Transmitter Preparation 27MHzTransmitter Crystal Power Switch Antenna Transmitter crystal(TX) Receiver crystal(RX) Extend the antenna to the maximum Length for best performance The crystal can be replaced to change frequencies. Note : You must also change receiver crystals! Do not use AM crystals Battery Level Indicator Good Batteries...

  • Page 3: Tools Required

    All manuals and user guides at all-guides.com Transmitter Preparation Set up the radio control system as indicated below. Servo Receiver Transmitter Battery Switch Start Install batteries.(Transmitter) Extend the antenna.(Transmitter) Connect the battery Extend the antenna.(Reveiver) Center the trims. Switch on.(Transmitter) Switch on.(Reveiver) Make sure the servos are in command.
  • Page 4 All manuals and user guides at all-guides.com Servo Saver Turnbuckle Approx.27mm TG8019 3x45 Turnbuckle …………1 T08666 M3 T08759 …………2 TG8019 T08620 3x45 Turnbuckle T08760 ……………………2 T08760 …………………1 T08674 M3x14 Screw T08759 ………1 T08674 M3x14 Buffer T08674 M3x14 T08650 Approx.8mm T08650 T08666 M3 T08762 Servo Saver-Top...
  • Page 5 All manuals and user guides at all-guides.com Servo Saver Post/Side Plate TG8003 Side Plate-Right T08840 Chassis T08650 Servo Saver Post TG8003 Side Plate-Left T08674 M3x8 T08674 M3x8 T08674 M3x8 Screw …………7 T08674 M4x10 Screw …………2 T08674 Screw M4x10 Cement T08674 Buffer Screw M4x10...
  • Page 6 All manuals and user guides at all-guides.com Front/Rear Differential T08636 M3x12 T08633 20T Diff Gear T08633 T08633 20T Diff Gear 2.5x11.5 Pin T08633 T08633 4.1x12x0.2 10T Diff Gear T08633 T08633 T08669 6.1x11x0.2 2.5x11.5 Pin Diff Shaft T08600 T08669 6.1x11x0.2 Differential Pads T08600 5.8x1.9 T08636 5.8x1.9 10000# for Front...
  • Page 7 All manuals and user guides at all-guides.com Front Swaybar T08756 T08756 T08760 T08756 M3x3 T08674 M2.5x8 Screw ………………3 T08601/T08756 M3x3 Screw ……………………4 T08756 6.8 Ball stud …………………2 T08601 T08755 6.8 Ball stud Swaybar Mount ………………………2 T08760 6.8 Ball End T08647 T08674 M2.5x8 ………………2 Front Swaybar...
  • Page 8 All manuals and user guides at all-guides.com Front Hub Carrie T08675 M4x10 T08607 Front Hub Carrier Bushing T08675 M4x10 Screw ……………2 T08673 M4x16 T08607 Front Hub Carrier Bushing ………4 T08607 Front Lower Arm T08673 M4x16 Screw ……4 T08673 M4x16 Front Suspension T08645 4x73 Arm Pin ……2 T08674 M3x35 Screw...
  • Page 9 All manuals and user guides at all-guides.com Front Shock Tower T08862 Screw M3.5x28 Cement T08622 Ball stud T08842 T08674 M3x12 Front Shock Tower T08674 M3x12 Screw T08622 Shock cap ball T08862 M3.5x28 Screw ……4 ……2 ………2 Front Upper Turnbuckle Front Upper-Left 1:1 x1 Approx.32mm T08757...
  • Page 10 All manuals and user guides at all-guides.com Steering Turnbuckle T08754 Steering-Left 1:1 x1 6.8 Ball stud Approx.32.5mm T08753 T08760 6.8 Ball stud Steering-Right 1:1 x1 6.8 Ball End-Steering Approx.32.5mm T08776 4x53 Turnbuckle T08760 6.8 Ball End-Steering T08776 4x53 Turnbuckle T08760 6.8 Ball End-Steering T08753 6.8 Ball stud T08754 6.8 Ball stud ………2...
  • Page 11 All manuals and user guides at all-guides.com T08674 M4x10 Front Suspension T08674 M3x18 T08674 M3x18 T08666 M4 Nylon Nut ………………1 T08674 M3x18 Screw T08666 M4 ……2 T08674 M4x10 Screw …………3 T08674 T08674 M4x14 Screw M4x14 T08829 Front Bumper Plate-Lower ………4 T08674 T08674 M4x14 M4x10...
  • Page 12 All manuals and user guides at all-guides.com 2 Speed Changer Gently tweaked the screw of M4 until it came to the steel surface T08855 8x12x3.5 Ball Bearing Screw head should not be out of the surface. ……………2 Tighten M3 screw to collar till the screw stops, and unscrew 3 rounds, T08664 8x16x5 Ball Bearing then please set up according to the track condition.
  • Page 13 All manuals and user guides at all-guides.com Brake/Throttle T08602 M3x8 T08653 M3x3 T08602 Screw M3x30 Cement T08825 Center Diff Upper Plate T08653 Brake Rod T08677 5x8x2.5 Ball bearing ………………2 T08677 5x8x2.5 T08653 M3x3 Screw T08653 …………………2 Brake Shaft T08602 M3x8 Screw ……………4 T08602 M3x30 Screw ……………4...
  • Page 14 All manuals and user guides at all-guides.com 2 Speed Changer Set T08674 M4x12 Screw ………4 T08674 M4x12 Rear Differential Case T08849 128mm Center Rear CVD T08849 Screw M5x4 Cement T08663 T08601 Differential Case 6x13x5 T08663 6x13x5 Ball Bearing T08304 ………2 13.1x15.9x0.2 T08663 T08304 13.1x15.9x0.2 Washer...
  • Page 15 All manuals and user guides at all-guides.com T08756 Rear Swaybar T08755 Screw M3x3 Cement T08756 T08760 T08601/T08756 M3x3 Screw ……………………4 T08601 M2.5x8 Screw ………………3 T08756 6.8 Ball stud-Swaybar T08601 Swaybar Mount …………………2 T08601 M2.5x8 T08647 T08755 6.8 Ball stud-Swaybar Rear Swaybar T08601 ………………………2 M3x3...
  • Page 16 All manuals and user guides at all-guides.com Rear Suspension T08674 M3x35 T08613 Rear Arm Mount-R T08613 T08608 +1 Degree Bushing-Right T08646 4x77 T08613 T08666 M4 Nylon Nut +1 Degree Bushing-Left ………………2 T08673 M3x16 Screw ……2 T08674 M3x12 Screw T08674 M3x12 T08613 0 Degree Bushing …………2...
  • Page 17 All manuals and user guides at all-guides.com Rear Upper Turnbuckle Rear Upper-Left 1:1 x1 T08760 7.8 Ball End-Rear Upper T08760 T08758 7.8 Ball End-Rear Upper 7.8 Ball stud 1:1 x1 T08778 5x40 Turnbuckle T08757 7.8 Ball stud T08778 5x40 Turnbuckle T08758 7.8 Ball stud T08757 7.8 Ball stud T08760 7.8 Ball End-Rear Upper...
  • Page 18 All manuals and user guides at all-guides.com Rear Suspension T08666 M3 T08666 M3 Nylon Nut ……………1 T08674 M3x10 Screw ………1 T08674 M3x12 Screw ……1 T08674 M4x14 Screw T08674 M3x10 …4 T08674 M4x14 T08674 M3x12 Shock T08627 2.75mm Plastic Washer T08844/T08625 …………………4 Shock Bottom cover T08845 M2.5...
  • Page 19 All manuals and user guides at all-guides.com Shock T08844/T08625 18.5x1.5 O-Ring ……………4 T08844/T08625 Shock Top cover Front-Short T08628 Front Shock Spring-Short Rear-Long T08622 Rear Shock Spring-Long Diaphragm Front-Short Rear-Long Front-Short T08844/T08625 18.5x1.5 Rear-Long T08622 Spring Mount T08844/T08625 Spring Adjuster Front Shock T08622 Plastic Bushing T08670...
  • Page 20 All manuals and user guides at all-guides.com Rear Shock T08622 Plastic Bushing T08670 T08666 M3.5 Nylon Nut 3.5x9x1 …………………2 T08666 M3.5 T08622 Plastic Bushing ………………………2 T08670 3.5x9x1 Washer …………………2 T08673 M3x18 Screw ……2 T08673 M3x18 Front Bumper T08673 M3x8 T08829 Front Bumper Plate-Upper T08830 Front Bumper Sponge...
  • Page 21 All manuals and user guides at all-guides.com Rear Bumper Plate T08666 M4 T08832 Rear Bumper Plate T08674 M4x12 Screw …………4 T08666 M4 Nylon Nut T08674 M4x12 ………………2 Body Mount T08833 M2.5x14 Screw …………4 T08863 M2.5x15 Screw …………4 T08833 T08833 Body Washer Body Washer T08833 T08833...
  • Page 22 All manuals and user guides at all-guides.com Front Body Mount T08673 M3x12 T08673 M3x12 Screw …………2 Rear Body Mount T08673 M3x12 T08673 M3x12 Screw …………2...
  • Page 23 All manuals and user guides at all-guides.com Radio Plate T08673 M3x8 Screw T08614 ……………4 T08673 M3x8 Receiver Box T08841 Radio Plate T08614 Battery Box Servo T08793 M3x15 T08793 M3x15 Screw T02081 3x7x0.8 …………8 T08793 M3x15 T02081 3x7x0.8 Washer T02081 3x7x0.8 Servo ……………………8 T08793 M3x15...
  • Page 24 All manuals and user guides at all-guides.com T08674 M3x8 Servo / Battery / Receiver T08673 M3x8 511123 Antenna Pipe T08673 M3x5 Screw Use the screws included T08673 M3x10 with switch. ………………3 T08614 T08673 M3x8 Screw Switch Mount T08614 Receiver Cover ……………3 T08102 Switch Cover...
  • Page 25 All manuals and user guides at all-guides.com Fueltank TG8008 M3x12 TG8008 M3x12 Screw TG8008 3x7x0.8 …………2 TG8008 3x7x0.8 Washer TG8008 ……………………2 TG8008 M3x12 TG8008 3x7x0.8 TG8008 TG8008 TG8008 TG8008 Fueltank T08674 M3x10 T08674 M3x10 Screw …………2...
  • Page 26 All manuals and user guides at all-guides.com T08676 M3x12 Engine 81005 Engine T08306 M3x10 86000 5.1x8x0.2 T08657 T08850 5x10x4 Clutch Shoe T08850 5x11x4 86000 5.1x8x0.2 T08658 Screw Washer T08851 Clutch Gear 16T T08852 Clutch Gear 20T T08850 T08784 Clutch Cover Engine Nut T08657 T08782...
  • Page 27 All manuals and user guides at all-guides.com Air Filter/Tunedpipe Tunedpipe Spring Seal Enclose T08621 Tunedpipe Set Engine T08859 Exhaust Hanger Wire T08859 M4x4 T08859 Pipe Mount TG8024 M4x8 T08673 M4x10 TG8024 M4x8 Screw T08673 M4x10 Screw T08675 M4x4 Screw ……4 …………1 ……1 Must be purchased separately...
  • Page 28 All manuals and user guides at all-guides.com Oil Pipe T08671 Oil Pipe Tyre T08838 Tyre T08838 Right Sponge T08838 T08837 Tyre T08838 Sponge T08837 Left Assemble as many times as specified...
  • Page 29 All manuals and user guides at all-guides.com Tyre Left Right Tyre T08649 17mm Hex Nut ……4 T08648 17mm Hex Nut Assemble as many times as specified Assemble both Left and Right...
  • Page 30 All manuals and user guides at all-guides.com Body T08839 Body-Lexan Car Light / Wing T08839 Car Light T08839 Wing...
  • Page 31 All manuals and user guides at all-guides.com Body T08839 Mask sticker Mask sticker the windows from the inside. Body Paint the body shell from the inside using spray colors.
  • Page 32 All manuals and user guides at all-guides.com Car Light / Wing Paint the car light and wing from the inside using spray colors. Car Light Car Light Wing Mount T08839 M3x6 T08839 M3x6 T08839 T08839 Wing Adjust Wing Adjust T08839 Wing Mount Right T08839 M3x6 Screw...
  • Page 33 All manuals and user guides at all-guides.com Wing T08839 M3x6 T08839 M3x6 Screw ………………8 T08839 M3x6 Body T08660 Mid Clip ……4 T08660 Mid Clip T08660 Mid Clip...
  • Page 34 All manuals and user guides at all-guides.com...
  • Page 35 All manuals and user guides at all-guides.com Parts list for GT8L 1/8 GP 4WD Touring Car-1 T08823 T08824 T08825 T08826 T08827 1pcs 1pcs 1pcs Arm Mount Front-R Center Diff Upper Plate 46T Gear Clutch Shoe 42T Gear 1pcs 1 set...
  • Page 36 All manuals and user guides at all-guides.com Parts list for GT8L 1/8 GP 4WD Touring Car-2 T08853 T08854 T08855 T08856 T08857 M5x4 Screw 8x12x3.5 Ball Bearing 2 Speed Clutch Spring 2pcs 2pcs 2pcs 4.0 Ball 2pcs 2 Speed Clutch Shaft...
  • Page 37 All manuals and user guides at all-guides.com Parts list for GT8L 1/8 GP 4WD Touring Car-3 T08636 T08645 T08634 T08640 T08639 4pcs M3x12 Screw M4x4 Screw M4x4 Screw 2pcs 2pcs O-ring 1pcs 4x73 Arm Shaft 1pcs Front/Rear Diff Connecting Cup...
  • Page 38 All manuals and user guides at all-guides.com Parts list for GT8L 1/8 GP 4WD Touring Car-4 T08674 M2.5x8 Screw M3x12 Screw M4x10 Screw M3x16 Screw M3x8 Screw M3x14 Screw M3x18 Screw M4x12 Screw M3x10 Screw M3x15 Screw M3x35 Screw M4x14 Screw...
  • Page 39 All manuals and user guides at all-guides.com Parts list for GT8L 1/8 GP 4WD Touring Car-5 T08773 T08774 T08776 T08777 T08778 5x8.5 Shaft 5x8.5 Shaft 2pcs 2pcs 2.5x12.8 Pin 2.5x12.8 Pin 2pcs 2pcs 5x58 Turnbuckle 4x53 Turnbuckle 5x40 Turnbuckle 2pcs...
  • Page 40 All manuals and user guides at all-guides.com Parts list for GT8L 1/8 GP 4WD Touring Car-6 TU0836 TU0842 TU0845 TU0847 TU0846 1pcs 2pcs 2pcs 1pcs 5x40 Titan Turnbuckle 4x52 Titan Turnbuckle Piston 1.2x6-Black Piston 1.4x6-White Piston 1.4x6-White 2pcs 2pcs Chassis Stiffener F/R...
  • Page 41 All manuals and user guides at all-guides.com GT8L Driver Track / City Event Date SETUP SHEET for the TeamC GT8L Track Condition Smooth Bumpy Low traction Med traction High traction Sandy Soft dirt Grass Hard soil Clay Dusty Other Front Suspension Front Shocks Shock Mounting&Camber link...
