1:10 Scale Radio Controlled Electric
Powered 4WD Buggy
Length
......................................................................................................410mm
Width
......................................................................................................250mm
Height
......................................................................................................140mm
All manuals and user guides at all-guides.com
TR04 Pro

Advertisement

loading
Need help?

Need help?

Do you have a question about the TRO0 Pro and is the answer not in the manual?

Questions and answers

Related Manuals for TeamC TRO0 Pro

Summary of Contents for TeamC TRO0 Pro

  • Page 1 All manuals and user guides at all-guides.com TR04 Pro 1:10 Scale Radio Controlled Electric Powered 4WD Buggy Length …………………………………………………………………………………………410mm Width …………………………………………………………………………………………250mm Height …………………………………………………………………………………………140mm...

  • Page 2: Transmitter Preparation

    All manuals and user guides at all-guides.com Transmitter Preparation Power Switch 27MHzTransmitter Crystal Antenna Transmitter crystal(TX) Receiver crystal(RX) Extend the antenna to the maximum Length for best performance The crystal can be replaced to change frequencies. Note : You must also change receiver crystals! Do not use AM crystals Battery Level Indicator Good Batteries...

  • Page 3: Tools Required

    All manuals and user guides at all-guides.com Transmitter Preparation A new Ni-MH battery must be charged before it is used.Refer to the charger instruction manual for charging. Set up the radio control system as indicated below Motor Battery Electronic Speed Controller Switch Transmitter...
  • Page 4 All manuals and user guides at all-guides.com Upper Arm Mount TR4010 Rear Arm Mount-Rear Below TR4001 Chassis T04002 Front Arm Mount-Rear TR4058 M3x8 Screw TR4058 ………………4 M3x8 TR4003 Diff-gear Box / Motor Mount Rear Gear-box-lower TR4016 Center Gear-box-lower Cut the waste material. TR4050 Motor Mount TR4002...
  • Page 5 All manuals and user guides at all-guides.com Diff TS4039 TS4039 16T gear 16T gear TS4040 3.0 E-ring TS4039 TS4039 TS4039 10T gear 5.1x13x0.2 ………………………4 5.1x13x0.2 TS4040 TS4039 5.1x13x0.2 Washer TS4040 TS4039 Diff shaft T04040 T04040 4.8x1.6 Diff pads …………………4 T04041 4.8x1.6 T04040 4.8x1.6 O-ring T04040...
  • Page 6 All manuals and user guides at all-guides.com TR4059 F/R Gear-Box M3x10 TR4059 M3x8 TR4003 Rear Gear-box-cover TR4059 M3x10 TR4059 M3x8 TR4002 Front Gear-box-cover TR4059 M3x8 Screw ……………4 TR4059 M3x10 Screw ……………8 Slipper set TR4059 T04020 Screw M3x5 Cement Slipper Hub-R T04032 T04021 T04036...
  • Page 7 All manuals and user guides at all-guides.com Center Gear Steering Servo T04005 Servo Mount T02081 TR4059 M3x10 TR4059 M3x8 Screw …………1 T02093 TR4059 M3x10 Screw 3kg Steering Servo …………4 Select the servo horn matching the servo being used. T02093 Ball stud-Short ……………1 T02081 3x7x0.8 Washer T04006...
  • Page 8 All manuals and user guides at all-guides.com Steering Servo TR4058 M3x8 Screw ………………2 TR4058 M3x8 Buffer T04003 TR4049 Servo Saver-left Servo Saver Body T02092 T04003 Servo Saver-Top TR4013 Steering Rack T04038 M3 TR4012 Servo Saver-Bottom T02092 T02092 TR4049 Servo Saver Spring T04038 M3 TR4049 T02092 Ball stud-Long...
  • Page 9 All manuals and user guides at all-guides.com Buffer 4.0mm 17.5mm T04024 T04014 T04014 T04031 TR4058 M3x8 Screw TR4049 ………………2 T04031 4x7x2.5 Ball bearing …………………4 T04014 4.8mm Ball End-Long ……2 T04024 3x40 Turnbuckle …………1 TR4058 M3x8 Upper Deck-Front / Front Upper Suspension Arm Mount TR4059 M3x10 TR4020 TR4059 M3x8...
  • Page 10 All manuals and user guides at all-guides.com Front Shock Tower TR4005 Front Shock Tower TR4059 M3x22 TR4055 TR4059 M3x8 TR4059 M3x12 TR4055 M3 Nut TR4059 M3x8 Screw TR4059 M3x12 Screw TR4059 M3x22 Screw ……2 …………2 ……2 ……2 Upper Deck-Rear / Rear Upper Suspension Arm Mount TR4059 M3x10 Screw TR4059 …………3...
  • Page 11 All manuals and user guides at all-guides.com Rear Shock Tower TR4005 Rear Shock Tower TR4059 M3x22 TR4059 M3x10 TR4055 M3 T04012 TR4055 M3 Nut Wing Brack …………………2 TR4059 M3x10 Screw …………4 TR4059 M3x22 Screw …………2 Rear Shock Tower TR4059 M3x8 TR4059 M3x12 TR4059 M3x8 Screw...
  • Page 12 All manuals and user guides at all-guides.com Spur Gear Cover TR4059 M3x12 TR4016 Center Gear-box-cover TR4059 M3x12 Screw …………4 Front Hub Carrier TR4011 1.6x11 Spring Pin TR4007 TR4007 Front Hub Carriers Front Hub Carriers 10 Degree-Right 10 Degree-Left ……………2 T02092 T04028 Front bearing collar TR4008 TR4008...
  • Page 13 All manuals and user guides at all-guides.com Front Hub Carrier < L > TR4059 M2.5x4 Screw …………………2 TR4046 2.5x30 Arm Pin T04007 ………………2 Front Lower Arm < R > TR4059 M2.5x4 TR4046 Front Suspension Arm T04002 Front Arm Mount-F T04002 Brace bushing ……………2 TR4059 M3x10 Screw ……………2...
  • Page 14 All manuals and user guides at all-guides.com Front upper Rod-L Turnbuckle 23.5mm 4.0mm 3x45 Turnbuckle Front upper Rod-R T04024 3x45 T04014 23.5mm 1:1 x1 T04014 4.8mm Ball End-Long 3x45 Turnbuckle Steering Rod ……12 T04024 3x40 18.5mm T04024 3x40 Turnbuckle 3x40 Turnbuckle …………4 Rear upper Rod T04024 3x45 Turnbuckle...
  • Page 15 All manuals and user guides at all-guides.com Rear Hub Carrier < L > TR4011 2.5x6x1 Washer …………………4 T04008 Rear Lower Arm-L TR4059 M2.5x4 Screw TR4011 2.5x6x1 …………………2 TR4046 2.5x30 Arm Pin ………………2 < R > TR4059 M2.5x4 TR4046 Rear Suspension Arm TR4010 Rear Arm Mount-R TR4058 M3x10 Screw...
  • Page 16 All manuals and user guides at all-guides.com Rear Turnbuckle Shock Absorber Front-Short Rear-Short T02064(T02065) 2.3 E-ring T02094 T02095 Put a little oil ……………………8 Put a little oil T02097 T02097 T02096 Shock Piston T02097(2.8x1.9) T02097(2.8x1.9) ……………4 T02097(3.1x1) T02097(3.1x1) T02064 T02065 T02097(2.8x1.9) T02097(2.8x1.9) T02097 / TR4063 2.8x1.9 O-ring T02094...
  • Page 17 All manuals and user guides at all-guides.com Shock Absorber T02073 for Front(Short) T02031 for Rear(Long) T02094 & T02095 Front-Short Rear-Short Front-Short Shock Absorber for adjusting the spring tension T02094 & T02095 Compress the spring and install TR4052 Front Shock Spring T02031 Below Spring mount T02094&T02095 12x1 O-ring...
  • Page 18 All manuals and user guides at all-guides.com Front Shock Absorber T04015 Shock cap ball-Short T02084 TR4059 M3x12 T04015 Shock cap ball-Short TR4059 M3x12 Screw T02084 M3 Nylon Nut ………2 ………2 ……2 Rear Shock Absorber T04015 Shock cap ball-Long T02084 M3 TR4059 M3x12 T04015 Shock cap ball-Long …………2...
  • Page 19 All manuals and user guides at all-guides.com Battery Column TR4019 Battery Holder-R TR4058 M3x10 Screw TR4019 Battery Holder-L ……………4 TR4058 M3x10 Motor Motor TR4050 Motor Cam TR4059 M3x8 H481 M3x3 H481 M3x3 Screw ……………………1 H481 21T Pinion Gear TR4059 M3x8 Screw ……………2 Must be purchased separately...
  • Page 20 All manuals and user guides at all-guides.com Motor TR4059 M3x14 TR4059 M3x10 TR4059 M3x8 Screw ……………1 TR4059 M3x10 Screw TR4050 ……………1 Motor Clamp TR4059 M3x14 Screw ………1 TR4059 M3x8 H380 T04013 T04013 M2.5x13 Tighten the screws with one sheet of paper inserted between both gears.
  • Page 21 All manuals and user guides at all-guides.com Battery T02086 Small clip ……………4 T02086 Battery TR4019 Battery Holder Wheel < Front > < Rear > TR4035 Rear-tyre TR4034 Front-tyre < F / R > TR4035 Rear sponge After fitting wheels to tyres, TR4034 apply instant glue as shown Front sponge...
  • Page 22 All manuals and user guides at all-guides.com Wheel T02084 M4 Flanged Nylon Nut T02084 M4 ……………4 Wing TR4058 TR4858 M3x10 Screw T04012 T04016 Wing ……………2 T04012 Wing washer ……………2 T04012 Wing angle shim-3° T04012 ……………2 Wing angle shim-3° Assemble both Left and Right...
  • Page 23 All manuals and user guides at all-guides.com Body TR4067 Body-Lexan Body TR4067 Mask sticker Mask the windows from the inside. Paint the body shell from the inside using spray colors.
  • Page 24 All manuals and user guides at all-guides.com Body-Velcro Tape TR4053 Velcro Tape TR4053 Velcro Tape Body T02086 T02086 Small clip ……………1...
  • Page 25 All manuals and user guides at all-guides.com...
  • Page 26 All manuals and user guides at all-guides.com Parts list for TR04 Pro off-road buggy - 1 TR4066 TR4067 T02156 T04040 4.8x1.6 O-ring M3x8 Screw 2pcs 1pcs 1pcs 10x12x0.2 Washer 4.8x1.6 O-ring 63mm center rear CVD M2.5x6 Screw Diff Pads Body-Lexan Diff Housing 1pcs 4pcs...
  • Page 27 All manuals and user guides at all-guides.com Parts list for TR04 Pro off-road buggy - 2 T04032 T04029 T04030 2x9.8 Pin 6pcs O-ring 3.1x1 O-ring T04034 Washer 12x1 2.8x1.9 3.1x1 O-ring O-ring Washer 12x1 O-ring 2.8x1.9 O-ring 2.8x1.9 O-ring 3x48.5 Arm Pin Rear Shock Absorber Front Shock Absorber 2pcs...
  • Page 28 All manuals and user guides at all-guides.com Parts list for TR04 Pro off-road buggy - 3 TR4057 TR4055 TR4056 TR4058 TR4063 2.0 E-ring M3x8 Screw 8pcs 8pcs 2.3 E-ring 2.8x1.9 O-ring 10x12x0.2 Washer 8pcs M3x10 Screw 2pcs 8pcs 8pcs TR4059 H380 M3x12 Screw M3x6 Screw...
  • Page 29 All manuals and user guides at all-guides.com Parts list for TR04 Pro off-road buggy - 4 TU0423 TU0415 TU0416 TU0418 TU0422 2pcs Front 1pcs 8pcs Front 1pcs 4pcs Rear Washer 1pcs Rear 1pcs 4pcs Rear Arm Mount-Ball Front Arm Mount Rear Arm Mount Rear Hub Carriers Motor Mount...
  • Page 30 All manuals and user guides at all-guides.com TR04 Pro Driver Track / City Event Date SETUP SHEET for the TeamC TR04 Pro Conditions Smooth Bumpy Low traction Med traction High traction Sandy Soft dirt Grass Hard soil Clay Dusty Other...
  • Page 31 All manuals and user guides at all-guides.com...
