Summary of Contents for The Galley Dresser 7
- Page 1 Installation Guide...
-
Page 2: Table Of Contents
Dresser 7 . . . . . . . . . . . . . . . . . . . -
Page 3: Commitment To Quality
. The kitchen is the hub of the home, and now, The Galley Ideal Workstation is the hub of the kitchen . Not just a kitchen sink, it is fast becoming the most important appliance in the kitchen and is literally changing the way people plan for and use their kitchens . -
Page 4: Dresser 7
Dresser 7 Front Exterior Elevation View Standard Side Elevation View 6” Finished Sides Interior Plan Views Custom Side Elevation View Fully Finished Sides Upper Lower Note: The Galley Tap(s) sold separately... -
Page 5: Dresser 6
Dresser 6 Front Exterior Elevation View Standard Side Elevation View 6” Finished Sides Interior Plan Views Custom Side Elevation View Fully Finished Sides Upper Lower Note: The Galley Tap(s) sold separately... -
Page 6: Dresser 5
Dresser 5 Front Exterior Elevation View Standard Side Elevation View 6” Finished Sides Interior Plan Views Custom Side Elevation View Fully Finished Sides Upper Lower Note: The Galley Tap(s) sold separately... -
Page 7: Dresser 4
Dresser 4 Front Exterior Elevation View Standard Side Elevation View 6” Finished Sides Interior Plan Views Custom Side Elevation View Fully Finished Sides Upper Lower Note: The Galley Tap(s) sold separately... -
Page 8: Delivery
Delivery Delivery White Glove Service is standard for The Galley Dresser . This includes uncrating, setting The Dresser within 3 feet of its final placement, and removal of all packaging materials . The client may have elected to forego White Glove Service and opted for standard curbside delivery with special approval . -
Page 9: Before You Begin
Before You Begin IMPORTANT Inspect The Galley Basin and Tap for any damage prior to installation . Please refer to all local plumbing and building codes prior to installation . The Galley Workstation • Please note: Unlike typical undermount kitchen sink installations, The Galley Workstation is installed in The Dresser prior to the counter being templated . -
Page 10: Delivery Contents
Delivery Contents Dressers 7, 6, 5 Dresser 4 Dresser Dresser Workstation Basin Workstation Basin Dresser Culinary Kit Dresser Culinary Kit • One 18” Upper Deck Section • One 12” Upper Deck Section ® ® • One Dual Tier Drying Rack •... -
Page 11: Pre-Installation
Pre-Installation Cabinet Preparation Important Notes: • Protect The Dresser and the cabinetry . • Use only licensed and/or certified contractors to install Galley products . Prior to installing The Dresser, confirm the space has been prepared according to the specifications . Ensure the installation site is clean and that there are no obstacles that can damage the Dresser prior to or during installation . -
Page 12: Installation
. Workstation Basin Installation Carefully place The Galley Workstation Basin into The Dresser by resting the flanges on the support frame . All four flanges should rest on the support frame . Ensure the drain is positioned either left or right according to the location of the plumbing shroud . Keep the braces in place inside the Workstation until after the countertop has been installed . -
Page 13: Countertop Installation
Countertop Installation Use the white template tray affixed to The Galley Basin flanges as your guide for the front to back, and left to right cutout . Refer to the Workstation specifications on pages 12-13 for your overall cutout dimensions or refer to the drawing on the template tray . -
Page 14: Countertop
Installation Plumbing or Tap Placements Drill holes for the Tap(s) and any additional plumbing fixtures or Tap Accessories being used . Tap placements for all Dresser sizes shown on pages 12-13 . Refer to Tap and Tap Accessories Installation Guides located within each product box . -
Page 15: Countertop Cutout & Tap Placements
O.D. 81 1/2” (2070 mm) C.O. 80 1/2” (2045 mm) 25 1/4” 30” 25 1/4” (641 mm) (762 mm) (641 mm) Dresser 7 Right Hand Drain (DRS-7-RH) 8” (203 mm) I.D. 80” (2032 mm) O.D. 69 1/2” (1765 mm) C.O. 68 1/2”... - Page 16 O.D. 81 1/2” (2070 mm) C.O. 80 1/2” (2045 mm) 25 1/4” 30” 25 1/4” (641 mm) (762 mm) (641 mm) Dresser 7 Left Hand Drain (DRS-7-LH) 8” (203 mm) I.D. 80” (2032 mm) O.D. 69 1/2” (1765 mm) C.O. 68 1/2”...
-
Page 17: Final Steps
Final Steps Plumbing & Mechanical Complete plumbing and electrical connections inside The Dresser and any additional appliances that may be installed in The Dresser . 2 . Test for any leaks and clean the work area using industry best practices . 3 . -
Page 18: Limited Lifetime Warranty
Rather, they are indicative of normal wear and tear and reflect the essence of the finish. Due to the nature of The Galley custom hardware products and finishes, select finishes will wear over time and may already have begun the process before reaching your home. - Page 19 . All decisions regarding the existence of manufacturing defects affecting this warranty shall be made by The Galley LLC and shall be final and binding on the parties . A dated receipt as proof of purchase is required to obtain benefits from this warranty .
