USER
MANUAL
Ice Machines: IC-35BW Premia
IC-55BW Premia
IC-55BW Premia XL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Butler IC-35BW Premia and is the answer not in the manual?

Questions and answers

Summary of Contents for Trufrost Butler IC-35BW Premia

  • Page 1 USER MANUAL Ice Machines: IC-35BW Premia IC-55BW Premia IC-55BW Premia XL...
  • Page 2: Receiving And Inspection

    User Manual Ice Machine Introduction Adopted advanced technology accompanied with strict comprehensive quality inspection to ensure excellent product performance. Compressor, the core part of the ice machine is made of world famous products, and our reasonable refrigeration system will make the ice macgine more reliable and lower energy consumption.
  • Page 3 User Manual Structure and Interface Name...
  • Page 4: Foot Mounting

    User Manual Foot Mounting 1. Screw the foot to the bottom of the ice machine. 2. Each leg must be screwed to the bottom and fastened to avoid bending. 3. Place the ice maker in a firm and level position. 4.
  • Page 5: Installation Drawing

    User Manual Installation of water supply 1. Ice machine must use room-temperature drinkable water. 2. Water pressure must be controlled between 0.15 MPa and 0.3 MPa. 3. Inlet hose with 3/4” internal thread (20mm) and 1/2” internal thread (15mm) joints at both ends, which has a stone guire seal washer so that there is no need to wrap raw tape.
  • Page 6: Electrical Safety Precautions

    User Manual Daily Cautions 1. When transporting and moving, the ice machine must not tilt more than 45 degrees. 2. Using independent source of water and checking regularly to prevent low water pressure, fluctuations or filter clogging. 3. Do not store any sundries in the ice bin. do not freeze any food in the ice bin, and keep the ice shovel clean.
  • Page 7: Fault Code

    User Manual Adjust Ice Thickness Ice thickness Setup Press the  + or  - button for 3 seconds, the digital tube display C1 at the first two place, the last two start flashing and enter the ice thickness setting ...
  • Page 8 User Manual 4.Whether the outlet hole of 4.Water shortage; water sprayer is blocked; 1.Heating valve fault; 1.Check the heating valve circuit; 2.Condensation temperature 2.Check ice thickness Ice falling timeout is too low; detector; 3.Ice set too thin; 3.Check inlet system; 4.Too little water in the tank;...
  • Page 9: Working Procedure

    User Manual Working procedure The steps of an ice machine are divided into there parts: Automatic cleaning Automatic cleaning after power on (Once,2 minutes) Each time when the ice machine is switched on, it performs a 2-minute automatic cleaning procedure, to rinse the floaters out of the ice trays and tank.
  • Page 10: Maintenance

    User Manual Maintenance Please carry out the maintenance according to the requirements of this manual, so as to improve the reliability and service life of the ice machine. And avoid increasing the energy consumption coefficient of ice production while maintaining sanitation. 1.
  • Page 11 User Manual...
  • Page 12 User Manual TRUFROST AND BUTLER PRIVATE LIMITED 1215, Tower B, Emaar Digital Greens, Golf Course Extn. Road, Sector 61, Gurugram – 122011, Haryana, India T. +91-7303166766 info@trufrost.com www.trufrost.com...

This manual is also suitable for:

Butler ic-55bw premiaButler ic-55bw premia xl
