Summary of Contents for Trufrost IC-35BWA
- Page 1 USER MANUAL Ice Machines: IC-35BWA IC-50A IC-50BWA...
-
Page 2: Table Of Contents
Contents Ice Machine Introduction Receiving and Inspection Structure and Interface Name Foot Mounting Installation of water supply Daily Cautions Electrical Safety Precautions Adjust Ice Thickness Fault Code Working procedure Maintenance... -
Page 3: Ice Machine Introduction
Ice Machine Introduction 1. Adoptted advanced technology and accompanied with strict and comprehensive quality inspection to ensure excellent product performance. 2. Compressor,the core part of the ice machine is made of world famous products, and our reasonable refrigeration system will make the ice macgine more reliable and lower energy consumption. -
Page 4: Structure And Interface Name
Structure and Interface Name Door of Ice Bin Decorating Plate Wcrking Status Indicator Supporting Feet Nodel Label Drain Pipeline Ice making water inlet （Black） （white） Power Filter... -
Page 5: Foot Mounting
Foot mounting 1. Screw the foot to the bottom of the ice machine. 2. Each leg must be screwed to the bottom and fastened to avoid bending. 3. Place the ice maker in a firm and level position. 4. Adjust the height of the foot to level the ice machine. 5. -
Page 6: Installation Of Water Supply
Installation of water supply 1. Ice machine must use room-temperature drinkable water. 2. Water pressure must be controlled between 0.15 MPa and 0.3 MPa. 3. Inlet hose with 3/4” internal thread (20mm) and 1/2” internal thread (15mm) joints at both ends,which has a stone guire seal washer so that there is no need to wrap raw tape. -
Page 7: Daily Cautions
Daily Cautions 1. When transporting and moving, the ice machine must not tilt more than 45 degrees. 2. Using independent source of water and checking regularly to prevent low water pressure, fluctuations or filter clogging. 3.Do not store any sundries in the ice bin. do not freeze any food in the ice bin, and keep the ice shovel clean. -
Page 8: Adjust Ice Thickness
Adjust Ice Thickness Ice thickness Setup: Press the + or - botton for 3 seconds, the digital tube display C1 at the first two place, the last two start flashing and enter the ice thickness setting state. At this point, every time you press the + (or -) button, the number displayed on the digital tube increases(or decreases) by 1, that means the thickness of the ice... -
Page 9: Fault Code
Fault Code Code Treatment Fault phenomenon Cause 1.Ice plate is not reset or false position; Ice plate or Ice full switch fault Check related parts 2.Ice full switch is abnormal; 1.Check the condensation 1.High ambient temperature; cooling system; 2.The cooling effect of the condensing 2.Whether there is leakage in the refrigeration system;... -
Page 10: Working Procedure
Working procedure The steps of an ice machine are divided into there parts: 1.Automatic cleaning Automatic cleaning after power on (Once,2 minutes) Each time when the ice machine is switched on, it performs a 2-minute automatic cleaning procedure, to rinse the floaters out of the ice trays and tank. In 2 minutes, the water tank is continuously filled and the pump is running. -
Page 11: Maintenance
Maintenance Please carry out the maintenance according to the requirements of this manual, so as to improve the reliability and service life of the ice machine. And avoid increasing the energy consumption coefficient of ice production while maintaining sanitation. 1.Clean the area around the ice machine regularly, to keep the blinds of the ice machine which are used for ventilation from clogging. - Page 12 Marketed globally by: TRUFROST COOLING PRIVATE LIMITED 1215, 12th Floor, Tower B, Emaar Digital Greens, Golf Course Extn. Road, Sector 61, Gurugram – 122102 (India) T. +91-7303166766 info@trufrost.com www.trufrost.com...
