ProMinent DULCOLEVEL Original Operating Instructions
Radar level sensor
Hide thumbs
Also See for DULCOLEVEL:
- Original operating instructions (64 pages) ,
- Operating instructions manual (64 pages) ,
- Original operating instructions (48 pages)
Subscribe to Our Youtube Channel
Related Manuals for ProMinent DULCOLEVEL
Summary of Contents for ProMinent DULCOLEVEL
- Page 1 Original Operating Instructions DULCOLEVEL Radar Level Sensor www.prominentfluid.com.au...
-
Page 2: Table Of Contents
Confi guration ............14 Operation .............15 Intended Use Cleaning & Maintenance ........15 The Radar Level Sensor DULCOLEVEL is intended for Troubleshooting ............16 commercial and industrial measurement of all types of process chemicals and liquids in plastic tanks using radar technology. The measurement is made from the outside vertically to the medium with a maximum permis- sible deviation of +/- 4°. - Page 3 Application-specifi c hazards may occur if used improperly. Follow the instructions in the troubleshooting chapter. If repair is necessary, contact ProMinent service. General Safety instructions The sensor corresponds to the state of the art in com- Notes on Radar Frequencies pliance with the usual regulations and guidelines.
-
Page 4: Scope Of Delivery
(part no. 1130661) Documentation Optional accessories for your sensor can be found in the ProMinent WebShop* or ordered from your local sales person. Screws for the mounting holes are not included in the scope of delivery. Use screws with a diameter ≤ 5 mm or ≤ M5. -
Page 5: Technical Data
Technical Data Maximum angle +/- 4° Measuring range 0.1-15 m Measurement accuracy +/- 5 mm Electrical connection 18-30 VDC 1.8 W 0.1 A Note: Power is supplied via a 100-240 V plug-in power supply unit (24 V supply voltage) or via the PLC (24 V DC voltage SELV) Degree of protection Protection against contact and moisture in accordance with IP 66 (EN 60529) and NEMA-4X/indoor (NEMA 250) if powercable or 0/4-20mA... -
Page 6: Dulconnex Blue App
DULCONNEX Blue App Overview Download the DULCONNEX Blue App to confi gure the sensor via smartphone or tablet. Only for ProMinent devices with Bluetooth ® option. About the App When you open the app, the dash- board appears. At the bottom of the screen you will fi... -
Page 7: Function
Function Overview Nameplate The level sensor DULCOLEVEL is a radar sensor for level measurement of all types of liquids in plastic The nameplate contains the most important data for tanks and IBC storage tanks: identifi cation and use of the sensor. -
Page 8: Application Options
Application Options The sensor can be used in different constellations. You always need the DULCONNEX Blue App for setup, confi guration and operation. Notice: For the wiring diagram see "Electrical Installa- Fieldbus tion" on page 11. 0/4-20 mA 1. Data transfer through pump with 2. -
Page 9: Led Status
LED Status LED Signal Meaning LED fl ashes blue at intervals of 1 s. Sensor is ready to be paired. LED lights blue continuously. Sensor is coupled with pump. LED fl ashes blue 2 times per second. Sensor identifi cation was triggered in the app. Sensor is paired with the app, not with the pump. -
Page 10: Mounting
Mounting Observe the following mounting instructions: Mount Sensor Tilting the sensor can lead to measurement errors. You can mount the sensor with the mounting plate, Always mount the sensor horizontally. straps or your own fi xtures. Secure the sensor against movement. Also ensure Notice: Mount sensor horizontal to tank with a maxi- that the tank is standing securely. -
Page 11: Electrical Installation
Mounting Electrical Installation Application Option 1 and 2 Mount Sensor with Strap You can connect the sensor to your pump via To mount the sensor with a strap, pass the strap through Bluetooth ® to send level information directly to the pump. the alignment brackets provided. -
Page 12: Initial Startup
Electrical Installation Initial Startup Application Option 3 You can connect the sensor directly to the PLC with a 0/4-20 mA connection. The sensor has an active mA output: The mA output actively supplies an output current without a supply voltage being applied from the outside. The mA output is galvanically isolated. - Page 13 Initial Startup Connect Sensor to Pump (Wizard) The sensor is connected to the pump and the pump is displayed in the "Devices" view in the "Connected" tab. Use the wizard in the DULCONNEX Blue App to connect the sensor to the pump. Note: During set-up you will need the last 4 digits of your sensor's and pump's serial numbers.
-
Page 14: Confi Guration
4. Tap on + next to the sensor's name. The sensor will be connected to the app. If the con- For more information on confi guration, also see the videos at www.prominent. nection is successful, a message appears. com. 5. Enter device PIN. -
Page 15: Operation
The sensor must not be opened. In case of malfunction 3. Tap the "Disconnect" button. and damage, contact the ProMinent Service. 4. Confi rm the disconnection process with "OK". If you also want to delete the sensor from the devices list, switch to the "Coupled"... -
Page 16: Troubleshooting
Troubleshooting Troubleshooting In the following table you will fi nd possible errors and information on trouble shooting. If you cannot rectify the fault yourself, contact ProMinent Service. Error Cause Action The connection to the pump cannot The DULCONNEX Blue App is not installed.
