USE AND CARE GUIDE
6.0 CUBIC FOOT WHEELBARROW
Questions, problems, missing parts?
Before returning to the store, call
Husky Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday
9 a.m. - 6 p.m., EST, Saturday
1-888-HD-HUSKY
HUSKYTOOLS.COM
We appreciate the trust and confidence you have placed in Husky through the purchase of this wheelbarrow. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
THANK YOU
Thank you for choosing Husky!
Item #1006 459 456
Model #HWB3016
Advertisement
Table of Contents
Related Manuals for Husky HWB3016
Summary of Contents for Husky HWB3016
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Husky through the purchase of this wheelbarrow. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
-
Page 2: Table Of Contents
WARNING: Do not over-inflate tire (max = 30 PSI). IMPORTANT: Please read and understand this entire manual before beginning assembly or use of this product. Warranty 1-YEAR WARRANTY WHAT IS COVERED 1-year warranty against manufacturing defects. Contact the Customer Service Team at 1-888-HD-HUSKY or visit www.HUSKYTOOLS.com. -
Page 3: Pre-Installation
Description Quantity 130 mm long M8 Bolts 80 mm long M8 Bolts 60 mm long M8 Bolts 50 mm long M8 Bolts 20 mm long M8 Bolts Flat Washers Locking Washers M8 Nuts HUSKYTOOLS.COM Please contact 1-888-HD-HUSKY for further assistance. -
Page 4: Package Contents
Pre-Installation (continued) PACKAGE CONTENTS Part Description Quantity Tray Handles Wheel Risers / Wedges Tray Braces Leg Brace Legs Axle Right Axle Bracket Left Axle Bracket Front Wheel Guard Hardware Bag... -
Page 5: Assembly
□ Drop two 80 mm bolts (BB) down through the shallower portion of the tray (A), the thinner portion of the wedge/ riser (D) and the holes nearest the rounded gripping end of the handles (B). HUSKYTOOLS.COM Please contact 1-888-HD-HUSKY for further assistance. - Page 6 Assembly (continued) Assembling the Leg Brace NOTE: Bolt heads go on one side. Flat washers, lock GG HH washers, and nuts go on the other - in that order. IMPORTANT: All hardware should be installed only finger tight until wheelbarrow is completely assembled. □...
- Page 7 □ Attach and secure the tray braces (E) to the tray (A) using two 20 mm bolts (EE) and the matching flat washers (FF), lock washers (GG) and nuts (HH). HUSKYTOOLS.COM Please contact 1-888-HD-HUSKY for further assistance.
- Page 8 Assembly (continued) Attaching the Right Axle Bracket NOTE: Do not tighten yet. □ Loosely attach and secure the right axle bracket (I) to the handle (B) and tray brace (E) using two 60 mm bolts (CC). The tray brace attaches to the front bolt hole on top of the handle.
- Page 9 Bolts go in from the top and are secured below the bracket with flat washers (FF), lock washers (GG) and nuts (HH). Tightening the Hardware □ Fully tighten all hardware prior to use. HUSKYTOOLS.COM Please contact 1-888-HD-HUSKY for further assistance.
- Page 10 Questions, problems, missing parts? Before returning to the store, call Husky Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday 1-888-HD-HUSKY HUSKYTOOLS.COM Retain this manual for future use.
