- Page 1 Orbita Hotel Lock E3092A Installation and User Manual...
- Page 2 CONTENTS 1: Introduction Thank you for purchasing Orbita Hotel Door Lock E3092A. The 1: Introduction product is made of grade 304 stainless steel with a PVC card reader cover, with strong resistance to impact, corrosion and 1-1: Product Dimensions abrasion. The door lock PCB is waterproof with stable and reliable quality.
- Page 3 1-4: Application Operating Voltage DC 6V (4 AA dry batteries) E3092A Lock can be used in hotels, hospitals, schools and apartments, Operating Power Quiescent current: < 30 μA; dynamic current: < 200 mA which comes with Orbita management system to save time and costs.
-
Page 4: Installation
2: Installation Please refer to the number below for the installation sequence Door Lock Accessories Cylinder Striking Front panel Rear panel Lock body Side trim Striking plate plate box Lock body Side trim Striking plate Rear panel fixing screws fixing screws fixing screws screws Installation Steps... - Page 5 2. Drill holes using the cardboard cutout provided 6: Install the side trim panel 7: Install the strike plate and side plate and lock it with screws Striking plate Striking plate box (Door plank) (Cardboard cutout) Door frame 3: Install the lock body and put 4: Fasten the front and rear 8: After the installation, open the key cover on the front panel.
- Page 6 (Note: The card needs to be encoded by the compatible Solution: If the card has been suspended, it cannot be used. Please management software and card encoder before use. Please refer to the “Orbita Hotel Lock System Management Software User Manual” for details.
