- Page 1 Orbita Hotel Lock S3078 Installation and User Manual...
-
Page 2: Table Of Contents
CONTENTS 1: Introduction 1: Introduction Thank you for purchasing Orbita Hotel Door Lock S3078. The product is made of grade 304 stainless steel with a PVC card reader cover, with strong 1-1: Product Dimensions resistance to impact, corrosion and abrasion. -
Page 3: 1-2: Technical Specifications
Grade 304 stainless steel Operating Voltage DC 6V (4 AA dry batteries) S3078 Lock can be used in hotels, hospitals, schools and apartments, Operating Power Quiescent current: < 30 μA; dynamic current: < 200 mA which comes with Orbita management system to save time and costs. -
Page 4: 2: Installation P4
2: Installation Door Lock Accessories Please refer to the number below for the installation sequence Cylinder Lock body Front panel Rear panel Side trim Striking Striking plate box plate Lock body Rear panel Battery box Short Side trim Long square axis fixing screws panel screws fixing screws... - Page 5 2. Drill holes using the cardboard cutout provided 6: Align the hole position on the door 7：Install the strike plate and panel and install the front sensing mask, side plate insert the battery box on the rear panel and lock it with a long rod screw, install the battery, buckle the rear cover and lock it with a screw.
-
Page 6: Operation Guide
Solution: A double-locked door can only be opened by the correct guest card and a software and card encoder before use. master card. Please refer to the “Orbita Hotel Lock System Management Software User Manual” for details. Problem: Seven red blinks and seven beeps indicate that the lock has been restricted for opening by a restriction card.
