VASTEX V-2000 Assembly, Operating, And Maintenance Instructions

Rotary presses
Hide thumbs Also See for V-2000:
Table of Contents

Advertisement

Quick Links

Download this manual
20____
Year of Manufacture:
Assembly, Operating, and Maintenance Instructions for all
Contents




Printhead/Extension Arm

Component Identification & P/N








Serial Number:
VTX
(Please log your machine's serial number and date of purchase for
future reference.)
V-2000HD
V-2000 rotary presses.
Page#
2
3
4
5-9
9-10
11
12
13
14
15
16-17
18-19
20
/
Date:____
____
Bethlehem, PA 18015 USA
Phone# 610 625-2702 Fax# 610 625-2775
Web Site www.vastex.com
Authorized Representative in Europe:
Certification Experts BV
Nieuwstad 100 1381 CE Weesp,
The Netherlands
Tel : + 31 (0) 294 - 48 33 55
Fax : + 31 (0) 294 - 41 46 87
Vastex E-mail assistance
Purchasing & Product Info:
sales@vastex.com
Electrical Support:
stech@vastex.com
Tech Support, Mechanical Setup, and Operation:
techsupport@vastex.com
/
Doc # 01-08-043F
Original Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V-2000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for VASTEX V-2000

Summary of Contents for VASTEX V-2000

  • Page 1: Table Of Contents

    20____ Year of Manufacture: Doc # 01-08-043F Original Instructions V-2000HD Assembly, Operating, and Maintenance Instructions for all V-2000 rotary presses. Contents Page# Introduction – Please Read Thoroughly  Safety Information  Overall View  Vastex International, Inc. Printer Assembly ...

  • Page 2: Introduction - Please Read Thoroughly

    In the unlikely event that a part of your press breaks, or if your press does not seem to be operating normally and the instructions in this manual do not correct the issue, do not continue using your press. Contact Vastex for assistance in repairing your press.

  • Page 3: Safety Information

    Safety Info Safety Information Read this manual before assembling and operating your press. Intended Use: This equipment is intended for performing manual screen printing of fabric  items, particularly garments. This equipment must not be used in a manner contrary to what is described in this manual. Safety: The operator should read and understand this manual before operating this ...

  • Page 4: Overall View

    V-2000HD Overall View Pg. 4...

  • Page 5: Printer Assembly

    Printer Assembly Note: Report any box damage to the driver 1) Remove straps, top of crate, sides of and note it on the crate, and shrink wrap from around the ticket before signing. press. Remove rotor arms and unpack boxes If hidden damage is under press.
  • Page 6 Printer Assembly Cont. Drop Down Service Pan and Wheels (optional) Printer Leg (3) Bolt, 3/8 x 3/4” lg. (2) Hex Nut 1/2” (1) Drop Down Wheel Bracket-1 (1) Drop Down Wheel Bracket-2 Drop Down Wheel Set Installed (2) Locking Caster Tools Required: (1) 3/4”...
  • Page 7 Printer Assembly Cont. 3) Install your rotor arms. Be sure to put the arms into the correct numbered positions. Each arm is packed with a pallet attached. Install the rotor arm as shown below. Two hooks hold the Rotor Arm in place before hardware is installed. Install (4) gold colored washers and (4) 3/8”...
  • Page 8 Printer Assembly Cont. Extension Arm Swivel Arm 5a) Installing the Print Heads onto the Swivel Arms. One print head has been leveled and #1 to match the swivel and extension arm #1. To install the Print Heads, pull the print head mounting bolts Print Head forward.
  • Page 9 Printer Assembly Cont. Adjusting the remaining Print Heads. Move the screen to remaining print head positions and set the 1/8” off contact to the now leveled pallets. Don’t forget print head #1 was adjusted at the factory. But you may still have to make an adjustment due to variations in screens and possible movement in shipping.
  • Page 10 Vastex V-2000HD Print Head/Extension Arm Pg. 10...

  • Page 11: Micro Registration Adjustment

    Micro Registration Adjustment Instructions Vastex micro-registration is standard with every V-2000 screen printer. It uses three control knobs, two micro clamp levers, and three return springs for movement control. A set of centering sites is used to start at a zero point. A total of 1/2" movement is available in the "X" direction and also in the "Y" direction Rotating the screen can be done by turning one of the "Y"...

  • Page 12: Level & Off Contact Adjustment

    Level & Off Contact Adjustments The Vastex V-2000 comes standard with 6-way level adjustments. A. Tighten both Screen Clamp Knobs to secure the screen in the printhead. B. Loosen the Front Rear Lock Screw before adjusting the pitch. Retighten after adjusting.

  • Page 13: Pallet Assembly

    Pallet Assembly Doc # 01-08-053B 2) Install neck guide as shown, using removed 1) Remove screws from neck guide screws. -Using Flat Blade Screwdriver or -Tighten with Flat Blade Screw driver or 1/4” 1/4” nut driver nut driver 3) Install (4) 3/8-16 x 3” bolts, (8) 3/8” 4) Install Pallet arm, (4) 3/8”...

  • Page 14: Pallet Leveling

    IMPORTANT NOTE: It is best to line up the inside of the screen with the front of the clamp bar any time you install screens in your V-2000 rear clamps. 1) Place your best flat aluminum 1/8 between screen and...

  • Page 15: Detent Wheel

    Detent Wheel Adjustment The Detent Rocker is used to achieve a repeatable position for the pallet under your flash. It can be set to lock the arm very firmly, loosely, or can be disabled altogether to remove the indexing feature. V2HD Printers built before Jan.

  • Page 16: Lubrication / Maintenance

    V-2000 Lubrication and Maintenance Doc # 01-08-045A ** Please follow all Lubrication instructions to prevent premature wear ** Lubricate monthly Supplied Lubricants: Replacement Lubricants can be ordered at Light Machine Oil (SAE 20 or equal) Vastex International Inc. Thread Lubricant (White Lithium Grease) or Anti Seize.
  • Page 17 V-2000 Lubrication and Maintenance Con’t Cleaning Clean your machine on a daily basis or between each job. Particularly removing  lint around moving points and adjustment areas. A clean machine is more likely to be maintained properly than a messy one. Any solvents can be used on the pallet tops for cleaning.

  • Page 18: Warranty

    The defective part or parts will be repaired or replaced at the discretion of Vastex International, Inc. If the equipment in question is less than one (1) year old, it will be shipped to the customer at no charge, with an RGA issued by Vastex for the defective part. The defective part must be shipped back to Vastex freight prepaid within 30 days or the account will be billed.

  • Page 19: Emery Street

    Examples of poor workmanship are welds, bearings, threads, knobs, fasteners, and general machine fatigue. The part must be shipped back to Vastex to be inspected at the shipper’s cost. If it is determined to be defective due to workmanship or normal wear, it will be repaired or replaced and shipped within 2 business days.

  • Page 20: Declaration Of Conformity

    Pg. 20...
