- Page 1 OPERATIONAL DESCRIPTION/ USER MANUAL KeyFob Model:RHT433...
- Page 2 Model: RHT433 & RHT315 (Japan only) 1. System Overview The RHT433 is a transmitter designed to provide remote keyless entry, passive entry, passive engine start, and immobilization functionality to the FCA platform, it is part of a larger system provided to FCA by Continental which allows the customer to: •...
-
Page 3: Technical Description
2 up to 3.3V Power supply: 3V dc battery cell Manufacturer : Continental Automotive GmbH Siemensstr. 12, 93055 Regensburg, Germany 3. BLOCK DIAGRAM The block diagram below shows the main electronic units of the RHT433/(Japan: RHT315) Fobik: Crystal Frequency: 27,6MHz... - Page 4 Model: RHT433 & RHT315 (Japan only) 4. Warnings For safe use, read the instructions carefully! Battery: CAUTION! Risk of explosion, if the battery is replaced by an incorrect type. Only use battery type CR2450 (3 V) Batteries must be inserted into the Keyfob with correct polarity (+ and -).
- Page 5 Model: RHT433 & RHT315 (Japan only) Note: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. -Taiwan 取得審驗證明之低功率射頻器材，非經核准，公司、商號或使 用者均不得擅自變更頻率 、加大功率或變更原設計之特性及功能。 低功 率射 頻器材之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應 立 即停用，並改善至無干擾時方得繼續使用。 前述 合法通信，指依電信管理 法規定作業之無線電通信。...
