- Page 1 User Manual for TOKEN Fob Document : SVI-QEFGE04 Model : Project Code : Version: Date: Dec. 18. '17 Engineering change order-No.: Design Freeze No.: Number of pages: Filename: Identification No. : CASCO...
- Page 2 Contents list Page System configulation Scope of SMART KEY SYSTEM Short description of the SYSTEM 1.2.1 General Definition of SMART KEY 1.2.2 Wireless Communication System Overview Smart Key Fob button operation Smart Key Fob homologation Editor : DM.Son Document name Project code ECO / DF No.
- Page 3 1. System configulation Scope of SMART KEY SYSTEM The System offers the following features: passive access for two doors, driver side and passenger side as well as trunk/tailgate passive start after interior detection of the SMART KEY FOB (without interior trunk and hat shelf detection) ...
- Page 4 The functions of the SMART KEY system have to be provided in a clearly defined and limited range. For the up-link from the vehicle to the SMART KEY FOB, a magnetic field with a frequency of 125 kHz and ASK modulation is used. Inductive antennas in and at the vehicle radiate the electromagnetic energy.
- Page 5 2. Smart Key Fob button operation Lock Unlock HOLD(Trunk) Panic You can lock, unlock, trunk and hold your vehicle with this remote transmitter. Lock When you push this button, all the doors will be locked. You can not lock any of the doors with this remote transmitter if any door is open or the key is in the fob holder.
- Page 6 3. Smart Key Fob Homologation FCC Compliance Statement. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interferencethat may cause undesired operation.
