This manual must be given to the homeowner. Please read the warranty
and return the warranty card to initiate coverage.
We Strongly Recommend The Use Of A Carbon Monoxide Detector When Using Any
It is the responsibility of the person or company installing this boiler to verify before the
installation that the boiler certifications shown on this page meet or exceed all local, state and
regulatory requirements for installation and use of this boiler. Failure to do so voids all claims
and warranties.
March 2010
OWNERS MANUAL
MODEL
OB1000 & OB2000
IS CERTIFIED TO:
Unit Serial #__________________________
Burner Serial # ________________________
Purchased From________________________
Company Address ______________________
_____________________________________
_____________________________________
Name of Installer_______________________
Installer Telephone # ___________________
Date Installed__________________________
IMPORTANT
Product That Consumes Fossil Fuels.
CSA B140.7.1
CSA B212 (EEV)
Aussi disponible en Français
