- Page 1 861-051BK 861-051BN C210930 ASSEMBLY INSTRUCTIONS...
-
Page 4: Package Contents
PACKAGE CONTENTS PART DESSCRIPTION QUANTITY Right frame Left frame Back frame Seat frame Front frame Seat cushion Table leg Short Table Top Long Table Top Mid Table Top Top table wood AA-BB-CC Hardware x149 FF-GG... - Page 5 PACKAGE CONTENTS Part List & Hardware Right Frame ( 6 pcs) Left Frame ( 6 pcs) Back Frame ( 6 pcs) Seat Frame ( 6 pcs) Front Frame ( 6 pcs) Table Leg ( 4 pcs) Short Table Top ( 2 pcs) Long Table Top ( 2 pcs) Mid Table Top ( 1 pc) Bolt M6x40 mm ( 30 pcs)
-
Page 6: Frame Assembly
FRAME ASSEMBLY Connect Seat Frame (D) & Front Frame (E) Connect part from STEP 1 & Right Frame (A) with Bolt (BB) & Wisher(FF) with Bolt (AA) & (BB) & Wisher(FF) Hardware Used Hardware Used 2 pcs 2 pcs 2 pcs 1 pc 3 pcs Connect part from STEP 2 &... - Page 7 FRAME ASSEMBLY Connect part from STEP 4 with Bolt (AA) & (BB) Put on Seat Cushion (DD) to complete chair & Wisher(FF) Hardware Used 1 pc 2 pcs 3 pcs Connect 2pcs Short Table Top (G), Long Table Top (H) & Mid Table Top (I) with Bolt (AA) & (CC) Hardware Used 2 pcs 1 pc...
- Page 8 FRAME ASSEMBLY Connect part from STEP 7 & Long Table Top (H) with Bolt (AA) & (CC) & (FF) Hardware Used 2 pcs 1 pc 3 pcs Connect part from STEP 8 & Table Leg (F), tighten Table Leg (F)
- Page 9 FRAME ASSEMBLY Connect part from STEP 9 with Bolt (CC) Hardware Used 8 pcs 8 pcs Put on Wood Table Top (EE) to complete table FINISH...
- Page 10 2 Right frame + 2 Left frame + 2 Back frame + 2 Seat frame + 2 Front frame + 2 Seat cushion + 2 Top table wood 861-051BK 4 Table leg + 2 Short Table Top + 2 Long Table Top + 1 Mid Table Top...
