- Page 1 860-020V01BU ASSEMBLY INSTRUCTIONS...
- Page 2 SAFETY INFORMATION assemble or install the product. 2.Assemble the item on a soft, non-abrasive surface such as carpeting to avoid damage. Estimated Assembly Time: 120 minutes Recommended maximum sitting weight for the sofa set Before beginning assembly of product, make sure all parts are present. Compare parts with parts list.If any part is missing or damaged, do not attempt to assemble the product and contact us immediately...
- Page 3 PACKAGE CONTENTS PART DESCRIPTION QUANTITY Plastic Plastic Plastic shackle asher Qty. 10 Qty. Qty. Qty. Qty. Qty. Qty. Extra 1 Extra 1 Extra 1 Extra 2 Extra 1 Extra 6 Ruler - Use this ruler to help correctly identify the screws. 95 100 105 110 115 120 125 130 135 140...
- Page 4 ASSEMBLY INSTRUCTIONS FRAME ASSEMBLY Align two holes of the back frame (A). Insert an M6 x 35 L bolt (AA) through M6 washer (CC), with the seat frame (B). Do not tighten completely. Repeat Hardware Used M6 x 35 L Bolt M6 Washer Align all four holes of the side frame (C).
- Page 5 ASSEMBLY INSTRUCTIONS FRAME ASSEMBLY Align two upper holes of the back frame ( D). Insert an M6 x 35 L bolt (AA) through M6 washer (CC) with the seat frame (E ). Then align the side holes of the back frame ( D) insert an M6 x 5 L ( ) through M6 washer (CC).
- Page 6 FRAME ASSEMBLY Attached the products by plastic shackles. Hardware Used Plastic shackle X 10 Attach four the " L " plastic foot (FF) to the lower corner of the table (G) by using M6 x 25L bolt (ZZ) and Knob (DD).
- Page 7 ITEM NO. CTN NO. INCLUDING 2 Pilow + 3 seat cushion + 2 back cushion + 1 Table + 1 Glass + 1 Back frame of Armless chair + Hardware + Plastic foot 4 seat frame of Armless chair + 1 seat cushion+ 2 back cushion + 8 side frame 860- of Armless chair + 3 back frame of...
