- Page 1 Version 1.3 UVe-LUX Operators Manual MAGNAFLUX FARADAY ROAD DORCAN SWINDON SN3 5HE ENGLAND TEL: +44 (0)1793 524566 FAX: +44 (0)1793 490459 EMAIL: sales.eu@magnaflux.com...
-
Page 2: Revision History
Removed “Detachable light sensor probe“ from specifications list Updated meter image and added port warning message Updated figure 5 Updated figures 6, 7 and 8 Updated figures 9, 10 and 11 Added “3.8 Set Cal Period” description MAGNAFLUX Magnaflux UVe-LUX Evolution Operators Manual Version 1.3 (08.03.2019).docx... -
Page 3: Table Of Contents
Measurement Display......................4 Main Menu .......................... 5 About Screen ....................... 5 Brightness ........................6 Power Off Time ......................6 Time/Date ........................6 Set Units ........................7 Set Cal Period ......................7 MAGNAFLUX Magnaflux UVe-LUX Evolution Operators Manual Version 1.3 (08.03.2019).docx... -
Page 4: Introduction
Introduction The UVe-LUX is a compact, lightweight and robust meter specifically designed for the non-destructive testing environment. The meter is a dual white-light (WL) and ultra-violet (UV) meter designed to give simultaneous readings of both WL and UV. The meter has the following specification: ... -
Page 5: Meter Housing
Pressing this button while the unit is off will switch the UVe-LUX on Holding down this button while the unit is on will switch the UVe-LUX off Accept button: Pressing this button in measurement mode will enter menu mode ... -
Page 6: The Batteries
To move left for selection within submenus The Batteries The UVe-LUX is powered by two AA type industrial, rechargeable batteries (Panasonic is recommended) The batteries are accessible by unscrewing the screw holding the battery housing cover on the rear of the meter housing. -
Page 7: Display
UV reading- this is the current reading for the UV sensor (this reading is rounded). UV max – this is the maximum value the meter has observed for UV (this reading is absolute). This reading is reset when the cancel button is pressed. MAGNAFLUX Magnaflux UVe-LUX Evolution Operators Manual Version 1.3 (08.03.2019).docx... -
Page 8: Main Menu
The about screen (also the splash screen) displays the software number, meter serial number and the light probe serial number. This screen also indicates the period of time left before recalibration is required. Figure 8 About Screen MAGNAFLUX Magnaflux UVe-LUX Evolution Operators Manual Version 1.3 (08.03.2019).docx... -
Page 9: Brightness
Use the left and right arrow buttons to move between Figure 11 Set Units digits then use the accept button to complete. The time and date menu option will lead the operator through both time and date settings. MAGNAFLUX Magnaflux UVe-LUX Evolution Operators Manual Version 1.3 (08.03.2019).docx... -
Page 10: Set Units
A calibration period of either 6 or 12 months can be set here. This calibration period will be applied from the last calibration date that has been set on the meter. Figure 13 Set Cal Period MAGNAFLUX Magnaflux UVe-LUX Evolution Operators Manual Version 1.3 (08.03.2019).docx...
