MAINTENANCE

FRONT GEARCASE

Always check and change the fluid at the intervals outlined in the Periodic
Maintenance Chart section. Refer to the Gearcase Specifications Chart for
recommended lubricants, capacities and torque specifications.
FLUID CHECK
q
The fill plug is located on the bottom right side of the front drive unit. Maintain
recommended fluid volume (listed in the Gearcase Specification Chart).
1. Position the vehicle on a level
surface.
2. Remove the fill plug using an 8
mm Allen wrench.
3. Check the fluid level. The fluid
should be even with the bottom of
the fill plug hole.
4. If necessary, add the
recommended fluid (listed in the
Gearcase Specification Chart).
Do not overfill.
5. Reinstall the fill plug. Torque to specification.
6. Clean any fluid residue from around the fill plug.
116
TORQUE
Fill Plug Torque:
10–14 ft-lbs (14–19 Nm)
