Dataq Instruments DI-4108M User Manual

8-channel high speed data acquisition systems with programmable gain, expandability with channelstretch, and stand-alone capability
Hide thumbs

Advertisement

Quick Links

Download this manual
Copyright © 2024 by DATAQ Instruments, Inc. The Information contained herein is the exclusive property of
DATAQ Instruments, Inc., except as otherwise indicated and shall not be reproduced, transmitted, transcribed, stored
in a retrieval system, or translated into any human or computer language, in any form or by any means, electronic,
mechanical, magnetic, optical, chemical, manual, or otherwise without expressed written authorization from the com-
pany. The distribution of this material outside the company may occur only as authorized by the company in writing.
DATAQ Instruments' hardware and software products are not designed to be used in the diagnosis and treatment of
humans, nor are they to be used as critical components in any life-support systems whose failure to perform can rea-
sonably be expected to cause significant injury to humans.
DATAQ, the DATAQ logo, and W
DI-4108M and DI-4208M
8-Channel High Speed Data Acquisition Systems with Programmable Gain,
Expandability with ChannelStretch™, and Stand-alone Capability
D
are registered trademarks of DATAQ Instruments, Inc. All rights reserved.
IN
AQ
DATAQ Instruments, Inc.
241 Springside Drive
Akron, Ohio 44333 U.S.A.
Telephone: 330-668-1444
Fax: 330-666-5434
Designed and manufactured in the
United States of America
T h e w a y P C - b a s e d i n s t r u m e n t a t i o n s h o u l d b e
User's Manual
Manual Revision G

Advertisement

loading
Need help?

Need help?

Do you have a question about the DI-4108M and is the answer not in the manual?

Questions and answers

Related Manuals for Dataq Instruments DI-4108M

Summary of Contents for Dataq Instruments DI-4108M

  • Page 1 The distribution of this material outside the company may occur only as authorized by the company in writing. DATAQ Instruments' hardware and software products are not designed to be used in the diagnosis and treatment of humans, nor are they to be used as critical components in any life-support systems whose failure to perform can rea- sonably be expected to cause significant injury to humans.

  • Page 3: Warranty And Service Policy

    DATAQ Instruments, Inc. warrants that this hardware will be free from defects in materials and workmanship under normal use and service for a period of 1 year from the date of shipment. DATAQ Instruments' obligations under this warranty shall not arise until the defective material is shipped freight prepaid to DATAQ Instruments. The only responsibility of DATAQ Instruments under this warranty is to repair or replace, at its discretion and on a free of charge basis, the defective material.

  • Page 5: Table Of Contents

    DI-4108M and DI-4208M Hardware Manual Table of Contents Warranty and Service Policy ........................ iii 1. Introduction ............................1 Features .............................. 1 Analog Inputs ............................ 1 Digital I/O ............................2 Software ............................. 2 WinDaq® Recording and Playback Software ................2 Help ............................. 2 2.

  • Page 7: Introduction

    4208 USB and Ethernet data acquisition systems.These systems are identical excluding gain ranges. Features Both the DI-4108M and DI-4208M data acquisition instruments are portable data recording modules that communi- cate through your computer's USB and/or Ethernet port with stand-alone capability. Features include: •...

  • Page 8: Digital I/O

    DI-4108M and DI-4208M Hardware Manual Digital I/O The DI-4208 contains seven digital ports, which may be used as a general-purpose digital input or for a specific func- tion as designated on the device. Digital port D0 may be used for WinDaq Events; Digital port D1 may be used for WinDaq remote Start/Stop;...

  • Page 9: Specifications

    DI-4108M and DI-4208M Hardware Manual 2. Specifications Analog Inputs Number of Channels: Channel Configuration: Differential Measurement range per channel: DI-4108: Programmable ±200, ±500 mV, ±1, ±2, ±5, ±10 V DI-4208: Programmable ±2, ±5, ±10, ±20, ±50, ±100 V Input impedance: DI-4108: 100 k...

  • Page 10: Ethernet Interface

    DI-4108M and DI-4208M Hardware Manual Input high voltage threshold: 2.4 V Input low voltage threshold: 0.8 V Terminal count: 65,535 Maximum rate frequency: 50 KHz with one enabled channel 20 KHz with 2-4 enabled channels 10 KHz with 5-7 enabled channels Minimum rate frequency: 0.5 Hz...

  • Page 11: Physical Characteristics

    DI-4108M and DI-4208M Hardware Manual Synchronization Conditions: Syncs with any combination of DI-4730, DI-4108, DI-4208, and DI- 4718B USB instruments. All synced instruments must operate at the same sample rate per channel, regardless of channel number, type, or range. All instruments must be connected to the same USB controller. The use of USB hubs are recommended to meet this requirement.

  • Page 13: Installation

    A USB flash drive with WinDaq software. Can also be used for stand-alone data logging. If an item is missing or damaged, call DATAQ Instruments at 330-668-1444. We will guide you through the appropri- ate steps for replacing missing or damaged items. Save the original packing material in the unlikely event that your unit must, for any reason, be sent back to DATAQ Instruments.

  • Page 14: Connect The Instrument To Your Computer

    DI-4108M and DI-4208M Hardware Manual Software installation is complete - you will now see a “Successful Installation” box - click OK to exit W Installation. You can now plug the device(s) into your PC. Click on the appropriate program group (specified above — default is Start >...

  • Page 15: Controls, Indicators, And Connections

    4. Controls, Indicators, and Connections Button Status Drive Ethernet Mini-B USB Connection Use the supplied USB cable to connect and power the instrument through your computer’s USB port or power supply Screw Terminals All input signal connections are made to the 16-port screw terminals. Each terminal is labeled on the instrument case. CAUTION Never touch exposed screw terminal connector pins or screws.

  • Page 16: Di-4108 Signal Connections

    DI-41/208M Signal Connections Refer to the following for screw terminal port identification. VOUT 2000418 Ch#: Analog channels 1-8 D#: Digital port (0-6). Can also be used for specific W functions (+25 Vmax). D0 Event — W Remote Event Marker (or general-purpose) D1 Record —...

  • Page 17: Analog Inputs

    Eight differential analog inputs measure ±200, ±500 mV, ±1, ±2, ±5, ±10 Volts on the DI-4108or ±2, ±5, ±10, ±20, ±50, ±100 Volts for the DI-4208 (CH1 to CH8, programmable per channel) . Designed to withstand 120 Vrms for DI- 4208M and 100V for DI-4108M. 4.7K...

  • Page 18: Low-Pass Filter

    Scroll through all enabled channels with the Next and Previous buttons. Low-pass Filter Each analog channel employs a low-pass filter with automatic corner frequency selection. The filter is a CIC (cas- caded integrator comb) type that uses as many as 512 samples per channel to calculate in real time as data is acquired. Filter response is optimized when sampling frequency is set to ten times the highest frequency of interest.

  • Page 19: Digital Ports

    Digital Ports The DI-4108 and DI-4208 contain 7 general-purpose digital ports. Each digital port can be configured as a digital input or used as a switch to control an external load (up to 25 V and 100 mA). Many of the ports also provide specific func- tionality in W or a third-party program.

  • Page 20: Windaq Remote Events (D0 Event)

    Equivalent Digital I/O Circuit: 3.3V 4.7K Dig In 4.7K Control Remote Events (D0 Event) To use a switch closure or TTL signal to record W Event Markers, connect signal leads to the appropriate Remote Control Event terminals . Once the switch closure or TTL signal is connected, activate Remote Events through W Acquisition Software.

  • Page 21: Windaq Remote Storage (D1 Record)

    An example event marker in a W data file is shown below. *Please Note: Event Markers do not display in the real-time W acquisition software - they only display in the playback software (WWB). Remote Storage (D1 Record) To use a switch closure or TTL signal to begin recording data remotely, connect signal leads to the appropriate Remote Control Record terminals.
  • Page 22 the designated Rate channel. Click on the Channel 10 channel box to enable/disable Rates. The Channel 10 channel box will display an “R” when enabled. Connect any TTL pulse stream (25 VDC max) to the D2 Rate channel on the DI-4108 or DI-4208. Select Channel 10 in the channel display, then select Edit >...

  • Page 23: Windaq Counter (D3 Count)

    rifices half of the instrument's resolution at 200 gallons per minute, and a range of 50 Hz allows measurements to only 50 gallons per minute full scale. Check the "Cycles/min" box to display and select frequencies reported in cycles per minute instead of cycles per sec- ond (the measurement interval remains the same).
  • Page 24 Acquisition menu to open the Channel Selection grid. Channel 11 is the designated Count channel. Click on the Channel 11 channel box to enable/disable Counts. The Channel 11 channel box will display a “C” when enabled. The counter channel accumulates counts over time whether recording or in standby mode as soon as the Counter channel is enabled.

  • Page 25: General Purpose Digital Inputs

    General Purpose Digital Inputs Enable Channel 9 for general-purpose digital input functions. Click on Edit > Channels in the W Acquisition menu to open the Channel Selection grid. Channel 9 is the designated Digital Input channel. Click on the Channel 9 channel box to enable/disable the digital inputs.

  • Page 26: General Purpose Digital Outputs

    General Purpose Digital Outputs Take care when configuring the load to be switched to ensure that the digital port is not damaged: 4-20mA Current Loop Measurements Use the following diagram for 4-20mA current loop measurement connections.
  • Page 27 The shunt resistor should be placed on the low side of the circuit as shown below: Current Loop Loop Power Transmitter 4-20mA Supply Shunt Resistor To DI-4108 or DI-4208 Analog Input Channel Set the engineering units as desired and define upper/lower levels in W as 1V = 4mA for the low value and 5V = 20mA for the high value.

  • Page 28: Mode Led Indicator

    Mode LED Indicator Indicates what mode the instrument is currently in. Use the chart on the top of the instrument for quick reference. Use the table provided below for a more detailed description of each available state as well as a description of some states not displayed on the label.

  • Page 29: Control Button Operations

    Error The device is unable to perform any operations. Cycle power or use the control button to resolve the error. Solid Red Button Pushed The LED turns white to indicate the control button is engaged. Solid White Idle The device is connected to and communicating with your PC through the USB port in CDC mode.

  • Page 30: Save Ethernet And Stand-Alone Configuration To Thumb Drive

    The Mode LED will flash white then indicate Idle in either LibUSB or CDC mode: • CDC mode: Blinking Yellow • LibUSB mode: Blinking Green Save Ethernet and Stand-alone configuration to Thumb Drive Save Ethernet settings and/or stand-alone configuration settings using the Control Button. Ethernet and Stand-alone configurations can also be saved to the thumb drive via the Dashboard (preferred method).
  • Page 31 data recording in that group. Select all the devices under a ChannelStretch group and click on the Start WinDaq but- ton. Stand-alone data logging is not available using ChannelStretch.

  • Page 32: Channelstretch

    Use the Configure menu to access the Stand alone setup window. Select and configure all channels available on your device, select a sampling interval, and setup recording Trigger conditions. The Stand alone configuration also allows you to Save/Load configurations via the File menu. Use the help file provided in WinDaq Dashboard to learn more.

  • Page 33: Connection

    Connection All USB devices must be on the same USB controller (or hub)* in order to synchronize data acquisition. All Ethernet devices must be on the same subnet as the PC that is recording the data (preferably the same Ethernet switch). ChannelStretch™...

  • Page 34: Channel Selection

    Channel Selection Devices are listed in the Channel Selection grid in alpha-numeric order of the serial numbers of the device. Devices must be connected to the USB hub before starting WinDaq.

  • Page 37: Unlock Windaq

    DI-4108M and DI-4208M Hardware Manual 5. Unlock WinDaq The DI-4108M and DI-4208M will record up to eight channels using WinDaq/Lite software and a single channel to the USB thumb drive. An unlock code is required to use ChannelStretch™ to synchronize multiple instruments (unlock code required for each unit to be synchronized).
  • Page 38 DI-4108M and DI-4208M Hardware Manual Click on the Yes button to enter your code. Click on the No button to go to Stand-alone configuration for a single channel. Enter the Key in the appropriate dialog boxes. Click OK. Unlock WinDaq...

  • Page 39: Dimensional Drawing

    DI-4108M and DI-4208M Hardware Manual 6. Dimensional Drawing SIDE VIEW 4/40 MOUNTING HOLE (4 PLACES ) 1.125" 0.750" 0.120" 0.230" 1.000" 4.000" 5.000" 5.230" FRONT VIEW 1.485" 4.140" Dimensional Drawing...
