The way PC-based instrumentation should be
DI-2160
Event, State, and Count Data Logger
User's Manual
Manual Revision A
Copyright © 2023 by DATAQ Instruments, Inc. The Information contained herein is the exclusive property of DATAQ Instruments,
Inc., except as otherwise indicated and shall not be reproduced, transmitted, transcribed, stored in a retrieval system, or translated
into any human or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise without expressed written authorization from the company. The distribution of this material outside the company may occur
only as authorized by the company in writing.
DATAQ Instruments' hardware and software products are not designed to be used in the diagnosis and treatment of humans, nor
are they to be used as critical components in any life-support systems whose failure to perform can reasonably be expected to
cause significant injury to humans.
241 Springside Drive
Akron, Ohio 44333 U.S.A.
Telephone: 330-668-1444
Fax: 330-666-5434
Designed and manufactured in the
United States of America

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DI-2160 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dataq Instruments DI-2160

Summary of Contents for Dataq Instruments DI-2160

  • Page 1 DATAQ Instruments' hardware and software products are not designed to be used in the diagnosis and treatment of humans, nor are they to be used as critical components in any life-support systems whose failure to perform can reasonably be expected to cause significant injury to humans.
  • Page 2 ±5 to ±170V peak AC or DC source directly . A USB interface is provided to allow the DI-2160 to be easily configured for specific measurements. The unit can be powered using the provided USB/AC power adaptor and the recording is protected by SuperCap.

  • Page 3: Warranty And Service Policy

    Service Policy 1. All products returned to DATAQ Instruments for service, regardless of warranty status, must be on a freight-prepaid basis. 2. DATAQ Instruments will strive to achieve a 5-day turnaround on any repair or replacement of any defective product.

  • Page 4: Signal Inputs

    Programmable State, Event, AC Counter, or High Speed Counter functions available per channel Signal Inputs The DI-2160 features eight high impedance (1MΩ) voltage channels (±5 to ±170 V DC or peak AC) located on a single eight-position screw terminal block and clearly labeled for easy connection and operation.

  • Page 5: Operation

    DI-2160 Event, State, and Count Data Logger Operation Event, State, Count (alternating current (AC) counter or high-speed (HS) counter Programmable functions: Counter Operation Reset condition: Programmable interval timeout Maximum count: 1 second interval: 4000 1 hour interval: 400,000,000 Maximum frequency: 4 KHz Minimum >250 μs...

  • Page 6: Controls, Indicators And Connections

    DI-2160 Event, State, and Count Data Logger Controls, Indicators, and Connections Interface: USB 2.0 (mini-B style connector) Storage: Removable USB drive Push button Stop/Start recording to USB drive control: Indicators (LED): Active, USB, Recording One 16-position terminal strip Input Connections:...

  • Page 7: Dimensional Drawing

    DI-2160 Event, State, and Count Data Logger Dimensional Drawing...

  • Page 8: Unpacking The Device

    DI-160 Event, State, and Count Data Logger Unpacking the Device The following items are included with each DI-2160 Event, State, and Count Data Logger. Verify that you have the following: Your DI-2160 Instrument Mini-B USB cable for device setup AC Power Adapter to record data in the field (the USB cable connects to the AC power...

  • Page 9: Connecting Input Signals

    DI-2160 Event, State, and Count Data Logger Connecting Input Signals All input signal connections are made to the 16-port screw terminal. Each terminal is labeled directly on the top of the instrument case. Use the following diagram to connect channel 1.
  • Page 10 DI-2160 Event, State, and Count Data Logger To connect signals to the DI-2160: 1.Insert the stripped end of a signal lead into the desired terminal directly under the screw. 2.Tighten the pressure flap by rotating the screw clockwise with a small screwdriver. Make sure that the pressure flap tightens only against the signal wire and not the wire insulation.

  • Page 11: Applying Power

    DI-2160 Event, State, and Count Data Logger Applying Power 1. Connect the Mini-B USB connection to the DI-2160 Unit. 2. Connect the other end of the USB cable to your PC for configuration or the provided AC power supply for stand-alone operation.
  • Page 12 DI-2160 Event, State, and Count Data Logger Indicator and Control The DI-2160 Data Logger has 1 color indicator and 1 push-button control (for start/stop recording to USB drive). Status LED The Status LED flashes different color patterns to indicate logger's status. Please see the overlay for...
  • Page 13 DI-2160 Event, State, and Count Data Logger USB Drive Use any USB drive formated in FAT32, up to 32 GB in size, to record your data. Remove the USB drive and insert into computers to access the data files. You can open the file in any spreadsheet program that...

  • Page 14: Software Installation

    DI-2160 Event, State, and Count Data Logger Software The DI-2160 Event Recorder setup software is included with the purchase of your DI-2160 Event, State, and Count Data Logger. Configure channels, sync the clock to your PC, and set the sample interval with the WinDaq Dashboard.
  • Page 15 DI-2160 Event, State, and Count Data Logger Main Screen of WinDaq Dashboard Plug the DI-2160 into a PC and run WinDaq Dashboard. Once open, the main window will display DI-2160 in its list box.
  • Page 16 (State, Event, HS Counter or AC Counter), and optionally assign a label (Channel Annotation) for the channel. DI-2160's real-time clock can be synced to UTC or local clock DI-2160 can be configured to start logging upon powering up, or scheduled to start and stop at certain time.

  • Page 17: Channel Mode

    DI-2160 Event, State, and Count Data Logger Channel Mode The channel mode can be configured for State, Event, HS Counter, or AC Counter. STATE means the channel is configured for the State Mode. EVENT means the channel is configured for the Event Mode.
  • Page 18 DI-2160 Event, State, and Count Data Logger Channel Annotation (Label) User-defined (up to 6 characters) channel annotation is optional...

  • Page 19: Time Setting

    DI-2160 Event, State, and Count Data Logger Time Setting The user-specified time setting is displayed in the upper left-hand portion of the main window just under "Function." Local or UTC (Coordinated Universal Time) date and time stamps can be displayed and stored to data files.

  • Page 20: Time And Date Stamp

    DI-2160 Event, State, and Count Data Logger Time and Date Stamp The time and date stamp of each data sample is displayed in the left-most column in the main window. Date/Time is shown in either UTC or Local (setting can be changed in the Channel Settings dialog).
  • Page 21 DI-2160 Event, State, and Count Data Logger Spreadsheet Data Display Sampled data is shown in the following format in spreadsheet.
  • Page 22 DI-2160 Event, State, and Count Data Logger Change the Sample Interval Select a new sample interval from the drop-down box. Select from the following: 1 Sec., 2 Sec., 5 Sec., 10 Sec., 15 Sec., 30 Sec.; 1 Min., 2 Min., 3 Min., 4 Min., 5 Min., 10 Min., 15 Min., 30 Min.; 1 Hr., 2 Hr., 4 Hr., 6 Hr., 8 Hr., 12 Hr., 24 Hr.

  • Page 23: Configure The Device

    DI-2160 Event, State, and Count Data Logger Select a radio button to set the channel function. Configure each channel as either a State, Event, High Speed Counter, or Counter. Only 3 total channels may be counter channels (AC or HS) while channels 4 and 8 cannot be configured as counter channels.
  • Page 24 DI-2160 Event, State, and Count Data Logger Choosing Channel Configuration Mode Use the following chart to determine which mode to select for which channel: DI-2160 Channel Configuration Mode Applied Signal if you want to know... Type Description Range Threshold When...
  • Page 25 DI-2160 Event, State, and Count Data Logger...
  • Page 26 Note: When sampling an AC line waveform, should the value of the applied waveform be approximately lower than the trigger threshold when the sample interval times out, the DI-2160 will erroneously indicate that power was removed for the entire sample interval. To overcome this problem use the Event Mode to...

  • Page 27: Event Mode

    DI-2160 Event, State, and Count Data Logger Event Mode Use the Event mode to record when an event occurs. An Event is a single occurrence within a sample interval. Even though multiple events may occur within a sample interval, only one will be recorded. Only leading edge transitions are reported.
  • Page 28 DI-2160 Event, State, and Count Data Logger High Speed Counter Mode Use the High Speed Counter Mode to find the sum of the number of events occurring within a sample interval. For example, a machine produces an average of 80 parts per minute over 420 total minutes of operating time (7 hours).
  • Page 29 DI-2160 Event, State, and Count Data Logger AC Counter Mode Use the AC Counter Mode to count AC power on/off within a sample interval. This mode is optimized to ignore 50/60 Hz power line transitions and to change state only when power is removed or applied. For example, a 120 VAC pump turned on 5 times during a sample interval of 30 minutes.
  • Page 30 DI-2160 Event, State, and Count Data Logger AC vs HS Counter Modes The decision to apply the DI-2160’s HS (high-speed) or AC (alternating current) counter mode depends upon what information is desired from the measurement. The high-speed counter mode is used when you need to total each pulse that occurs within a sample interval.
  • Page 31 DI-2160 Event, State, and Count Data Logger Reported Data Access recorded data by removing the USB drive from the DI-2160 and inserting it into USB port of the computer. The .csv output file is formatted to allow easy analysis of your recorded data. The first rows contain general information including the file name, device name, and sample interval.

  • Page 32: Technical Support

    DI-2160 Event, State, and Count Data Logger Technical Support Post all technical support issues through our support ticket system. Our support team monitors the ticket system Monday through Friday 9-5 Eastern Time. DATAQ Instruments, Inc. 241 Springside Drive Akron, OH 44333...
