  • Page 1 EN User Manual | Washing Machine EW6F4109RA...

  • Page 2: Table Of Contents

    Welcome to Electrolux! Thank you for choosing our appliance. Get usage advice, brochures, trouble shooter, service and repair information: www.electrolux.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................4 3. PRODUCT DESCRIPTION................6 4. TECHNICAL DATA..................7 5.

  • Page 3: General Safety

    the use of the appliance in a safe way and understand the hazards involved. • Children between 3 and 8 years of age and persons with very extensive and complex disabilities shall be kept away from the appliance unless continuously supervised. •...

  • Page 4: Safety Instructions

    • The ventilation opening in the base must not be covered by a carpet, mat, or any floor covering. • The appliance must be connected to the water mains using the new supplied hose sets, or other new hose sets supplied by the Authorised Service Centre.

  • Page 5: Water Connection

    2.4 Use • Always use a correctly installed shockproof socket. • Make sure that the parameters on the WARNING! rating plate are compatible with the Risk of injury, electric shock, fire, burns electrical ratings of the mains power or damage to the appliance. supply.

  • Page 6: Product Description

    These lamps are intended to withstand • Disconnect the appliance from the mains extreme physical conditions in household electrical and water supplies. appliances, such as temperature, • Cut off the mains electrical cable close to vibration, humidity, or are intended to the appliance and dispose of it.

  • Page 7: Technical Data

    The rating plate reports the model name (A) , product number (B), electrical ratings (C) and serial number (D). Mod. xxxxxxxxx Prod.No. 910000000 00 000V ~ 00Hz 0000 W 00000000 4. TECHNICAL DATA Dimension Width/ Height/ Total depth 59,6 cm /84,7 cm /57,6 cm Electrical connection Voltage 230 V...

  • Page 8: Information For Installation

    5. Put the plastic caps, that you find in the CAUTION! user manual bag, in the holes. Do not lay washing machine on its front. 3. Put the appliance back into an upright position. Remove the power supply cable and the drain hose from the hose holders. 5.2 Information for installation Positioning and levelling Adjust the appliance correctly to prevent...
  • Page 9 1. Make a U shape with the drain hose and put it around the plastic hose guide. 45º 45º 20º 20º 2. On the edge of a sink - Fasten the guide to the water tap or to the wall. 2.
  • Page 10 drain hose makes a loop to prevent particles going into the appliance from the sink. 6. Position the hose directly to a built-in drain pipe in the room wall and tighten it with a clamp. The end of the drain hose must always 5.3 Electrical connection be ventilated , i.e.

  • Page 11: Accessories

    6.2 Fixing plate kit If you install the appliance on a plinth that is not an accessory supplied by ELECTROLUX, secure the appliance in the fixing plates. Read carefully the instructions supplied with the accessory.

  • Page 12: Control Panel

    7. CONTROL PANEL 7.1 Special features • The SensiCare System detects the laundry load weight defining the Your new washing machine meets all modern programme duration in 30 seconds. The requirements for an effective treatment of washing programme is tailored to the laundry with low water, energy and detergent laundry load and the type of fabric without consumption and will care for fabrics.
  • Page 13 7.3 Display Door locked indicator. Delay start indicator. The digital indicator can show: • Programme duration (e. g. • Delay time (e. g. • Cycle end ( • Warning code (e.g. • Indication of total operating hours of the appliance. Refer to the 'Operating hours counter' section in the 'Settings' paragraph for more details.

  • Page 14: Dial And Buttons

    8. DIAL AND BUTTONS 8.1 Introduction more water for some washing programmes • Rinse Hold . The related indicator comes on. The options/functions are not available The final spin is not performed. The water with all washing programmes. Check the of the last rinse is not drained out to compatibility between options/functions prevent the fabrics from creasing.

  • Page 15: Time Manager

    8.9 Time Manager With this option you can reduce the These options can increase the programme duration depending on the load programme duration. size and the degree of soiling. When you set a washing programme, the 8.6 Permanent Rinçage Plus display shows the default duration and With this option you can add a few rinses dashes.

  • Page 16: Programmes

    9. PROGRAMMES 9.1 Programme Chart Programme Reference Maxi‐ Programme description Temperature spin speed (Type of load and level of soiling) range Spin speed load range Eco 40-60 1400 rpm 9 kg White cotton and fast-coloured cotton. Normally soiled (1400- 800) items.
  • Page 17 Programme Reference Maxi‐ Programme description Temperature spin speed (Type of load and level of soiling) range Spin speed load range Lavage tambour 1200 rpm Maintenance cycle with hot water to clean and freshen the 60 °C (1200 - 800) drum and to remove residue that may cause odour. For the best result use this cycle once a month.
  • Page 18 Programme Reference Maxi‐ Programme description Temperature spin speed (Type of load and level of soiling) range Spin speed load range 1200 rpm 2,5 kg Outdoor (1200- 800) 30 °C 1 kg Do not use fabric softener and make sure that 40 °C - Cold there is no softener residue in the detergent dispenser.
  • Page 19 Programme options compatibility Eco 40-60 ■ ■ ■ ■ ■ ■ ■ ■ Coton ■ ■ ■ ■ ■ ■ ■ ■ ■ Synthétiques ■ ■ ■ ■ ■ ■ ■ ■ ■ Délicats ■ ■ ■ ■ ■ ■ ■...

  • Page 20: Settings

    Universal Liquid Uni‐ Liquid for Delicates Special Programme versal coloureds woollens powder 1) ▲ ▲ ▲ Sport ▲ ▲ Outdoor ▲ ▲ ▲ Denim At temperature higher than 60 °C the use of powder detergent is recommended. ▲ = Recommended -- = Not recommended 9.2 Woolmark Wool Care - Blue The wool wash cycle of this machine has been approved...

  • Page 21: Before First Use

    10.3 Operating Hours Counter 10.4 Factory Reset It is possible to visualise the total operating This function allows to restore the factory time of the appliance in hours, starting from default options. To activate this option follow the first switching on. This value will count steps below: operating time of the cycles (does not include 1.

  • Page 22: Loading The Laundry

    3. Press the Marche/Arrêt button for a few seconds to activate the appliance. Compartment for prewash phase, soak A short tune sounds. programme or stain remover. 12.2 Loading the laundry Compartment for washing phase. 1. Open the appliance door. Compartment for liquid additives (fabric 2.

  • Page 23: Setting A Programme

    12.5 Setting a programme 1. Turn the programme dial to select the desired washing programme. The indicator of the Départ/Pause button flashes. The display shows an indicative programme duration. 2. To change the temperature and/or the spin speed, touch the related buttons. 3.

  • Page 24: The Sensicare System Load Detection

    Cancelling the delay start after the countdown has started About 20 minutes after the programme To cancel the delay start: start, the programme duration could be adjusted again depending on the 1. Touch the Départ/Pause button to capacity of water absorption of the pause the appliance.

  • Page 25: End Of The Programme

    12.12 End of the programme When the programme has finished, the If the SensiCare System has completed appliance stops automatically. The acoustic and the water filling has already started, signals operate (if they are active). The the new programme starts without repeating the SensiCare System.

  • Page 26: Stand-By Option

    • 5 minutes after the end of the washing • If you have set Night the appliance programme only drains the water Press the Marche/Arrêt button to activate The option indicator Rinse Hold the appliance again. disappears. The display shows the end of the last 3.

  • Page 27: Stubborn Stains

    – there is large amounts of foam during washing. • When using detergent tabs or pods, always put them inside the drum, not in the detergent dispenser. Insufficient detergent may cause: • unsatisfactory washing results, • the wash load to turn grey, •...

  • Page 28: Care And Cleaning

    Use the correct quantity of water softener. Follow the instructions that you find on the packaging of the product. 14. CARE AND CLEANING the drum", "Cleaning the drain pump" and WARNING! "Cleaning the inlet hose and the valve filter" paragraphs. If necessary, please contact the Refer to Safety chapters.

  • Page 29: Door Seal With Double Lip Trap

    could generate bad odours and mildew. To Clean the drum with special products for eliminate these deposits and clean the inner stainless steel. part of the appliance, run a maintenance wash regularly (at least once a month). Always follow the instructions that you find on the packaging of the product.

  • Page 30: Cleaning The Drain Pump

    any traces of accumulated detergent. 4. Insert the detergent drawer into the guide After cleaning, put the top part back into rails and close it. Run the rinsing position. programme without any clothes in the drum. 3. Make sure that all detergent residue is removed from the upper and lower part of the recess.
  • Page 31 Proceed as follows to clean the pump: 180˚ ENGLISH...

  • Page 32: Cleaning The Inlet Hose And The Valve Filter

    WARNING! Make sure that the impeller of the pump can rotate. If it does not rotate, contact the Authorised Service Centre. Make sure also that you tighten the filter correctly to prevent leakages. 14.10 Cleaning the inlet hose and the valve filter 45°...

  • Page 33: Troubleshooting

    15. TROUBLESHOOTING WARNING! Refer to Safety chapters. 15.1 Alarm Codes and Possible failures The appliance does not start or it stops during operation. First try to find a solution to the problem (refer to the tables). WARNING! Deactivate the appliance before carrying out any check. With some problems, the display shows an alarm code and the Départ/ Pause button may flash continuously:...
  • Page 34 If the display shows other alarm codes, deactivate and activate the appliance. If the problem continues, contact the Authorised Service Centre. In case of different problem with the washing machine check the table below for possible solutions. Problem Possible solution •...

  • Page 35: Consumption Values

    Problem Possible solution Too much foam in the drum • Reduce the quantity of detergent. during the washing cycle. • Make sure that the flap is in the correct position (UP for powder detergent - After the washing cycle, DOWN for liquid detergent). there are some detergent residues in the dispenser •...
  • Page 36 16.3 According to Commission Regulation Eu 2019/2023 Eco 40-60 pro‐ rpm 1) Litres hh:mm °C gramme Full load 0.760 64.0 3:40 53.00 1351 Half load 0.440 47.0 2:45 53.00 1351 Quarter load 0.300 39.0 2:35 54.00 1351 Maximum spin speed. Power consumption in different modes Off (W) Stand-by (W)

  • Page 37: Quick Guide

    17. QUICK GUIDE 17.1 Daily use Connect the mains plug to the mains socket. 2. Set the desired options (1) by means of the corresponding touch buttons. To start Open the water tap. the programme, touch the Départ/Pause Load the laundry. (2) button.

  • Page 38: Environmental Concerns

    Programmes Load Product description Délicats 2 kg Delicate fabrics such as acrylics, viscose, polyester items. Rapide 14 min. 1,5 kg Cotton and synthetic lightly soiled items or once worn items. All fabrics, except woollens and very delicate fabrics. Pro‐ Rinçage 9 kg gramme for rinsing and spinning.
  • Page 40 135964750-A-372023...
