exacqVision G Series Quick Start Manual

G-Series PoE NVR Quick Start Guide
Introduction
The exacqVision G-Series Power over Ethernet (PoE) systems are part of the exacqVision series of network video recorders (NVR). Depending on
the model, the G-Series PoE has either 8 or 16 PoE camera ports. The exacqVision G-Series PoE includes the full functionality of the exacqVision
video management system (VMS), without the need to wire cameras to a power supply.
Installation
Before you turn on the exacqVision G-Series PoE server, ensure that the installation environment meets the following requirements.
Electrical requirements
CAUTION:
Danger of explosion if the battery is incorrectly replaced. Replace the battery with the same or equivalent type according to the
manufacturer's instructions. Discard used batteries according to the manufacturer's instructions.
CAUTION: Never open the equipment. For safety reasons, the equipment should be opened only by qualified service personnel.
• This equipment is not suitable for use in locations where children are likely to be present.
• This product must be supplied by a UL listed certificate power supply, with an output rated 54 VDC, 3.33 A minimum, TMA 104°F (40°C)
minimum, and a maximum altitude of 16404 ft (5000 m). If you need further assistance, contact
techsupport/.
• Connect the information technology equipment (ITE) only to PoE networks without routing to the outside plant.
• The unit uses a three-wire ground cable that is equipped with a third pin to ground the unit and prevent electric shock. Do not remove or
alter this pin in any way. If your outlet does not support this kind of plug, contact your electrician to replace your obsolete outlet.
• The PoE port supports 10/100 Mbps, 802.3 af/at in compliance with a total of 120 W for the 8 port device and 240 W for 16 port device.
Mounting and operating environment requirements
• Mount the G-Series PoE in a dust-free and climate-controlled location where the temperature is between 40°F and 95°F (4.5°C to 35°C) and
the humidity level is less than 80% non-condensing.
•
CAUTION: Dust may cause components of the server to overheat, and elevated temperatures can contribute to premature hard drive
failures.
• If the hard drives are dispatched separately to the system, insert each drive into the hard drive slots. If the drives are numbered, ensure that
you insert the correct drive into the appropriate slot.
Electrical environment requirements
• For maximum reliability, connect the G-Series PoE to a UPS power supply. An online UPS filters power surges and dips that can damage the
server.
• Connect a keyboard, a monitor, and a mouse to the server.
• Connect the G-Series PoE network interface cards (NIC) to the appropriate network switch ports.
• Use cables with a ferrite core to connect the server to the monitors. If the cable does not have a ferrite core, the unit performs as expected,
but may not meet CE safety regulation standards.
Starting the server
When you start the G-Series PoE for the first time, create a user name and password for the operating system, then create a root user name and
password for the Enterprise Manager.
1. Turn on the G-Series PoE.
2. To create an operating system user account, in the Log on dialog box, enter a user name and password.
3. Configure the operating system settings as required.
4. If prompted, log on to the operating system again with the user name and password that you created.
500-00121 Rev A
2024-07-09
