- Page 1 Quick Installation Guide TEG-160WS TEG-240WS...
-
Page 2: Table Of Contents
Table of Contents English 1. Before You Start 2. Hardware Installtion 3. Web Management Utility Troubleshooting Version 02.02.2010... -
Page 3: English
Multi-Language Quick Installation Guide 2 Mounting Brackets with Screws Power Cord System Requirements Web Browser: Internet Explorer (5.0 or above), Netscape (6.0 or above) Computer with Network adapter installed Mini-GBIC module (e.g. TEG-MGBSX, TEG-MGBS10, TEG-MGBS40, TEG-MGBS80, TEG-MGBS10D35, TEG-MGBS40D35) for Mini-GBIC slots... -
Page 4: Hardware Installtion
"admin". Make sure your computer and the TEG-160WS/TEG-240WS are configured to the same network segment. 2. The Mini-GBIC slots are shared with Port 15 and 16 (TEG-160WS) and port 23 and 24 (TEG-240WS) Gigabit Ethernet ports. When the Mini-GBIC slots are in use, port 15 and 16 (TEG-160WS) and port 23 and 24 (TEG-240WS) Gigabit Ethernet ports are disabled. -
Page 5: Web Management Utility
3. Web Management Utility Note: If you would like to easily discover all the Web Management Switches on the network, assign IP Address, change the password, and upgrade to new firmware, then install the Web Management Utility. Follow the steps below. - Page 6 4. Click Discovery, and then double-click the Switch that appears in the Discovery List. 5. Click the Switch in the Monitor List and then click Configuration setting. 6. Configure the IP Address, Subnet mask, Gateway, and Password. Click Set. 7. Click OK.
-
Page 7: Register Your Product
Troubleshooting section, User's Guide on the Utility CD-ROM, or TRENDnet's website at http://www.trendnet.com. Register Your Product To ensure the highest level of customer service and support, please take a moment to www.trendnet.com/register register your product Online at:... -
Page 8: Troubleshooting
“only one user can login”. What should I do? Another computer is configuring the TEG-160WS/TEG-240WS. Please wait until the user logs off. If the other user has already logged off and you still get the same screen, then disconnect the power cord from the TEG-160WS/TEG-240WS, wait... - Page 10 Copyright ©2010. All Rights Reserved. TRENDnet.
