Arch Basket Swings 5"
1 Seat, 1 Seat Add-A-Bay
IMPORTANT!
Prior to installation of any components, refer to the "Owner/Operator Manual". This
manual will provide important information pertaining to site preparation, footings, system stabilization and
other necessary information vital to the success of your installation.
MODEL
MR0939
MR0939BD
MR0941
MR0941BD
Note: An (*) by a part number (Code) indicates: Color Code Required.
1. Concrete for footings, wheelbarrow or mixer, 5 gallon bucket, water supply
2. Digging equipment for footings (spade shovel, post hole digger, auger)
3. Bracing materials (2x4s, wood pieces, concrete blocks, bricks, jackstands, sawhorses, etc.)
4. Tape measure and level
5. Open end wrench set, Allen and 6-lobe wrenches or bits, socket set, screwdrivers
6. Drill, bits, extension cords, power supply
7. Rubber mallet
8. Step ladder
9. Adult installers - 2 minimum
Installation Guide
(inground and bolt down)
DESCRIPTION
5" Multi-User Arch Swing
5" Multi-User Arch Swing - BD
5" Multi-User Arch Swing Add-A-Bay
5" Multi-User Arch Swing Add-A-Bay BD
TOOLS AND EQUIPMENT REQUIRED
Also see "Installations 101"
18APR23
Rev. A
PAGE
2
2
3
3
Page 1 of 16
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Miracle MR0939
Summary of Contents for Miracle MR0939
- Page 1 MODEL DESCRIPTION PAGE MR0939 5" Multi-User Arch Swing MR0939BD 5" Multi-User Arch Swing - BD MR0941 5" Multi-User Arch Swing Add-A-Bay MR0941BD 5"...
- Page 2 18APR23 Rev. A Arch Basket Swings 5" (inground and bolt down) 1 Seat, 1 Seat Add-A-Bay MR0939 & MR0939BD 5" Multi-User Arch Swing Protective Area: 24' x 32' Top View - Inground Inground Model Shown Top View - Bolt Down 11' 3"...
- Page 3 18APR23 Rev. A Arch Basket Swings 5" (inground and bolt down) 1 Seat, 1 Seat Add-A-Bay MR0941 & MR0941BD 5" Multi-User Arch Swing Add-A-Bay Protective Area: 24' x 32' Top View - Inground Inground Model Shown Top View - Bolt Down Each Add-A-Bay for 11' 3"...
- Page 4 18APR23 Rev. A Arch Basket Swings 5" (inground and bolt down) 1 Seat, 1 Seat Add-A-Bay PARTS IDENTIFICATION MR0938 PN 929414* FRAME - 5.00" STEEL ARCH SWING PN 929422* TOP RAIL - 3.50" OD X 126.58" (BASKET) TITLE: DIMENSIONS ARE IN MM UNLESS STATED OTHERWISE MAT'L: THE INFORMATION CONTAINED IN AS INDEXED...
- Page 5 18APR23 Rev. A Arch Basket Swings 5" (inground and bolt down) 1 Seat, 1 Seat Add-A-Bay PARTS IDENTIFICATION PN 929426* FRAME-5.00" STEEL ARCH SWING (SM) PN 929427* FRAME-5.00" STEEL ARCH SWING (ADD BAY)SM Page 5 of 16...
- Page 6 18APR23 Rev. A Arch Basket Swings 5" (inground and bolt down) 1 Seat, 1 Seat Add-A-Bay PARTS IDENTIFICATION PN 929994* SWING PURCHASED PARTS (shown assembled) Page 6 of 16...
- Page 7 18APR23 Rev. A Arch Basket Swings 5" (inground and bolt down) 1 Seat, 1 Seat Add-A-Bay PARTS IDENTIFICATION BOLT WASHER HANGER SWING ROPE HANGER BOTTOM D-SHACKLE D-SHACKLE BOLT ROPE CHAIN LINK BASKET CLEVIS SET SCREW CLEVIS BOLT CLEVIS CONNECTOR D-SHACKLE D-SHACKLE BOLT PN 929994* SWING PURCHASED PARTS (exploded view)
- Page 8 18APR23 Rev. A Arch Basket Swings 5" (inground and bolt down) 1 Seat, 1 Seat Add-A-Bay STEP 1 DIG FOOTINGS (IF APPLICABLE) 1a. Refer to Footing Layout and Construction Drawings for inground and bolt down footing criteria for installation. Bolt down model can be placed on either a 4" concrete slab or a concrete footing.
- Page 9 18APR23 Rev. A Arch Basket Swings 5" (inground and bolt down) 1 Seat, 1 Seat Add-A-Bay STEP 4 ATTACH SWING HANGERS TO TOP RAIL 4a. Attach the two swing hangers to the top rail, using the pre-drilled holes in the top rail. Apply a drop of thread locking adhesive to the bolt threads before installing bolt.
- Page 10 18APR23 Rev. A Arch Basket Swings 5" (inground and bolt down) 1 Seat, 1 Seat Add-A-Bay STEP 5 POUR CONCRETE (IF APPLICABLE) 5a. Rope off area to prevent access and pour concrete; allow to cure for 72 hours. For bolt down models, see illustration below.
- Page 11 18APR23 Rev. A Arch Basket Swings 5" (inground and bolt down) 1 Seat, 1 Seat Add-A-Bay STEP 6 FASTEN SWING ROPES TO ROPE BASKET 6a. Attach d-shackles on end of ropes to the rope basket in four places as shown below. ROPE ROPE BASKET D-SHACKLE...
- Page 12 18APR23 Rev. A Arch Basket Swings 5" (inground and bolt down) 1 Seat, 1 Seat Add-A-Bay STEP 7 ATTACH ROPES TO SWING HANGERS 7a. Attach the swing ropes to the two swing hangers with hardware as shown below. Attach chain link to clevis connector (on the end of the rope) and to the d-shackle. Screw in clevis bolt, align holes in bolt and clevis, and install clevis set screw.
- Page 13 18APR23 Rev. A Arch Basket Swings 5" (inground and bolt down) 1 Seat, 1 Seat Add-A-Bay STEP 8 INSTALL LABELS 8a. Install age appropriate labels per "Placement of Age Appropriate Labels" located in Installations 101 in Installation Manual. FINAL STEP Tighten all hardware.
- Page 14 18APR23 Rev. A Arch Basket Swings 5" (inground and bolt down) 1 Seat, 1 Seat Add-A-Bay 5" MULTI-USER ARCH SWING MR0939 CODE DESCRIPTION 929414* FRAME - 5.00" STEEL ARCH SWING 929422* TOP RAIL - 3.50" OD X 126.58" (BASKET) 929994*...
- Page 15 18APR23 Rev. A Arch Basket Swings 5" (inground and bolt down) 1 Seat, 1 Seat Add-A-Bay 5" MULTI-USER ARCH SWING ADD-A-BAY MR0941 CODE DESCRIPTION 929415* FRAME - 5.00" STEEL ARCH SWING (ADD BAY) 929422* TOP RAIL - 3.50" OD X 126.58" (BASKET) 929994* SWING PURCHASED PARTS 928468...
- Page 16 200001776 ANCHOR CONCRETE WEDGE M10 X 1.50 X 100MM PARTS CARTON-GENERIC AND WARNING LABELS 986348 CODE DESCRIPTION 116021 LABEL MIRACLE ID - GENERIC 116022 LABEL WARNING - PLAYGROUND - ENGLISH 713550 STICKER TOP OF SURFACING 116099 LABEL, PLAY SMART RULES...
