Upgraded rip fence for 10” jobsite table saw
Hide thumbs Also See for TSO Products DWE7491RS:

Advertisement

UPGRADED RIP FENCE FOR
DEWALT 10" JOBSITE TABLE SAW
ASSEMBLY INSTRUCTIONS
Thanks for purchasing this genuine TSO Product.
Questions? Suggestions? Ideas? We thrive on your feedback!
Contact us toll-free at 800-727-0311 (U.S.), 239-236-5526
(international), email us at info@tsoproducts.com, or visit
www.tsoproducts.com/support
Danger indicates a hazardous situa-
DANGER
tion that, if not avoided, will result in
death or serious injury.
Warning indicates a hazardous situa-
WARNING
tion that, if not avoided, could result
in death or serious injury.
Caution indicates a hazardous situa-
CAUTION
tion that, if not avoided, may result
in minor or moderate injury
or property damage.
Notice indicates important or helpful
NOTICE
information and/or user tips.
Publication 696-107 RevA
for a copy of this guide.
©2024 TSO Products LLC
ESSENTIAL SAFETY WARNINGS
This product is intended and designed for use only in
conjunction with the DeWalt® DWE7491RS 10" Jobsite
Table Saw, Types 1, 2, 3, and 10. The DeWalt Instructional
Manual for the DWE7491RS also applies in connection with
the use of this TSO Products Upgrade Rip Fence.
The content of this assembly guide is provided solely for
the purpose of assembling the product. It is not intended
to serve as a comprehensive instruction manual or to
provide guidance on the safe operation of power tools,
including but not limited to saws. Users are expected
to have full knowledge of and adhere to the safety and
operational instructions provided by the manufacturer
of any power tools they operate.
Failure to consult the manufacturer's original instruc-
tions for safe operation and handling of power tools may
result in serious injury, damage, or death. The manu-
facturer of this product and the author of this assembly
guide assume no liability for any injuries or damages
arising from improper use of power tools or failure to
follow appropriate safety procedures. Always refer to
and follow the specific safety guidelines provided by the
manufacturer of your tools.
Woodworking involves a variety of injury risks which you
can reduce with proper use of Personal Protective Equip-
ment (PPE) and adherence to safe work practices.
CAUTION
Page 1 of 6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TSO Products DWE7491RS and is the answer not in the manual?

Questions and answers

Summary of Contents for DeWalt TSO Products DWE7491RS

  • Page 1 This product is intended and designed for use only in conjunction with the DeWalt® DWE7491RS 10” Jobsite Table Saw, Types 1, 2, 3, and 10. The DeWalt Instructional Manual for the DWE7491RS also applies in connection with the use of this TSO Products Upgrade Rip Fence.
  • Page 2: Table Of Contents

    Your box should include multiple individual bags of hard- ware. Ensure you have the following parts and quantities: Parts List Step 1B. Lift the DeWalt Rip Fence off the table and place on an flat tabletop. 1 qty. 2 qty.
  • Page 3 Step 1: Disassemble DeWalt Fence (Continued) Step 1C. Remove Phillips Head Screw holding the Stock Support Bar to the DeWalt Fence Assembly. Repeat on the Step 1F. Remove two T20 Torx Screws from the back of other side of the fence.
  • Page 4: Step 2: Install Tso Upgraded Rip Fence

    Step 2C. Using the T20 Thread Forming Screw included in Step 2A. Install the DeWalt Fence Brackets into the TSO the TSO product kit, screw through the end of the DeWalt Fence Extrusion. Ensure the fence’s T-slots are facing out- Fence Bracket and into the TSO Fence Extrusion.
  • Page 5 Step 2E. Fully tighten the T20 Thread Forming Screw at Step 2G. Re-attach the two Push Stick Mounting Tabs the front of the DeWalt Fence Bracket. Repeat for the other using the slots on the back of the TSO Fence Extrusion.
  • Page 6: Questions, Comments, Or Ideas

    239-236-5526. To send us a message, visit us at www.tsoproducts.com or email info@tsoproducts.com, and we’ll get back to you as soon as possible. DeWalt is a registered trademark of Stanley Black & Decker. Publication 696-107 RevA ©2024 TSO Products LLC Page 6 of 6...
