- Page 1 ID-E359-003-GB AUTOMATIC FIRE EXTINGUISHING CONTROL PANEL IGNIS 2500 _________________________________________________________________________________ INSTRUCTION IO-E359-003-GB Edition I IGNIS 2500 AUTOMATIC FIRE EXTINGUISHING CONTROL PANEL...
- Page 2 ID-E359-003-GB The IGNIS 2500 fire extinguishing control panel, which is the subject of this OMM, meets the essential requirements of the European Parliament as well as the EU Council and European Union directives as the following regulations: CPR/305/2011 European Parliament and the EU Council Regulation of March 9, 2011 establishing harmonized conditions for marketing of the construction products and repealing Council Directive 89/106/EEC;...
-
Page 3: Table Of Contents
4.2. Connection terminals for input and output circuits, hard-wired installation ....... 21 Instructions for commissioning and checking the correct operation of the control panel after installation ..........................22 Packaging, storage, transportation ..................23 IGNIS 2500 AUTOMATIC FIRE EXTINGUISHING CONTROL PANEL... - Page 4 Fulfils Strength Research Fulfils Optional functions Extinguishing signal delay Fulfils 4.17 Signal indicating the effect of the extinguishing agent Fulfils 4.18 Monitoring condition of the components Fulfils 4.19 Emergency stop device Fulfils 4.20 IGNIS 2500 AUTOMATIC FIRE EXTINGUISHING CONTROL PANEL...
- Page 5 Testing status Fulfils Structural requirements Fulfils Additional structural requirements Fulfils concerning software-controlled panels Marking Fulfils Durability of operational reliability: resistance to heat Cold resistance Fulfils 15.4 Durability of operational reliability: resistance to vibration IGNIS 2500 AUTOMATIC FIRE EXTINGUISHING CONTROL PANEL...
- Page 6 Essential characteristics of the product PN-EN 54-4:2001+ properties A1:2002+A2:2007 chapter Power supply efficiency General requirements Fulfils Functionality Fulfils Materials, structure and workmanship Fulfils Operational reliability General requirements Fulfils Functionality Fulfils Materials, structure and workmanship Fulfils IGNIS 2500 AUTOMATIC FIRE EXTINGUISHING CONTROL PANEL...
- Page 7 Moist solid heat (resistance) Fulfils Moist solid heat (strength)) Fulfils 9.14 Intended use: Panels for use in gas extinguishing devices installed in buildings, forming a complete and operating installation. For technical data, see documentation: ID-E359-001-GB IGNIS 2500 AUTOMATIC FIRE EXTINGUISHING CONTROL PANEL...
- Page 8 ID-E359-003-GB This manual allows you to familiarize yourself with the principles of safe use of the IGNIS 2500 Auto- matic fire extinguishing control panel. It is essential to read the Technical and Operational Documentation No. ID E359-001-GB (IMM) of the IGNIS 2500 control panel before installation and operation of the device.
-
Page 9: Safety Conditions
ID-E359-003-GB 1. Safety conditions 1.1. Protection against electric shock The IGNIS 2500 automatic extinguishing control panels are classified as protection class I devices and can only be used with additional protection against electric shock such as neutral or protective grounding. -
Page 10: Technical Data
Max. number of buttons EXTINGUISHING START, EXTINGUISHING STOP, EXTINGUISHING BLOCK 6.2 kΩ Terminating resistor 2 x 100 Ω Line resistance max. Supervised potential outputs Number of outputs max.* Current of outputs L7, L8 max. IGNIS 2500 AUTOMATIC FIRE EXTINGUISHING CONTROL PANEL... - Page 11 Communication module with supervisory line of POLON 3000 and POLON 6000 systems Number of modules Power consumption 20 mA Cooperation with devices Interface for connection with Control panel configuration a computer Readout of events IGNIS 2500 AUTOMATIC FIRE EXTINGUISHING CONTROL PANEL...
-
Page 12: Structure Description
It also has an optional possibility of cooperation with the POLON 3000 and POLON 6000 addressable systems, after applying the MKA-25 module. In addition to the detectors, an addressable detection line may contain up to 8 pcs of IGNIS 2500 control panels (in POLON 6000 system). IGNIS 2500 AUTOMATIC FIRE EXTINGUISHING CONTROL PANEL... -
Page 13: Panel Housing
ID-E359-003-GB 3.2. Panel housing Figure 3.2/1 Dimensions of a two-zone control panel IGNIS 2500 AUTOMATIC FIRE EXTINGUISHING CONTROL PANEL... -
Page 14: User Interface
Collective fault indication of at least /yellow one circuit or function - fault state Button When pressed, the fault list is dis- played on the LCD display; button active from the first access level IGNIS 2500 AUTOMATIC FIRE EXTINGUISHING CONTROL PANEL... - Page 15 - receiving a fire alarm by the staff, switches the second stage alarm delay countdown from T1 to T2 time and mutes the acoustic sig- nalling devices; active from the first access level (without switching on the ignition). IGNIS 2500 AUTOMATIC FIRE EXTINGUISHING CONTROL PANEL...
- Page 16 (or interrupting the flow). EXTINGUISHING START Intermittent Status before activating the extinguishing /red system (alarming one detection line or alarm from the initiating line in the manual control only mode) IGNIS 2500 AUTOMATIC FIRE EXTINGUISHING CONTROL PANEL...
- Page 17 A place for inserting a paper sheet with a description of the zone switch Enabling the second access level (ignition switch) SERVICE ACCESS Continuous Second level of access /yellow Intermittent > second access level or opening the panel door IGNIS 2500 AUTOMATIC FIRE EXTINGUISHING CONTROL PANEL...
-
Page 18: Safety Conditions
MSG-25 modules. These modules are equipped with two connectors for connecting the batteries. Regardless of the number of MSG-25 modules used, the batteries should be connected to one output. When using two MSG-25 modules, the outputs should be connected in IGNIS 2500 AUTOMATIC FIRE EXTINGUISHING CONTROL PANEL... - Page 19 If the 230 V power supply is lost and a charged battery pack is connected, the control panel is started by pressing the SW3 button "ACTIVATE BAT." available on the MSG module board. IGNIS 2500 AUTOMATIC FIRE EXTINGUISHING CONTROL PANEL...
-
Page 20: Control Panel Mounting
The control panel should be mounted on the wall with three expansion bolts with a diameter of at least 8 mm. The arrangement of the control panel fastening holes is shown in Figure 4.1/1. Mounting is possible with the batteries removed. Figure 4.1/1 Mounting the control panel IGNIS 2500 AUTOMATIC FIRE EXTINGUISHING CONTROL PANEL... -
Page 21: Connection Terminals For Input And Output Circuits, Hard-Wired Installation
In the vicinity of module connectors and cable grommets coming out of the control panel, on the rear wall of the casing, there are rails intended for connecting shielding wires to the metal casing of the control panel. IGNIS 2500 AUTOMATIC FIRE EXTINGUISHING CONTROL PANEL... -
Page 22: Instructions For Commissioning And Checking The Correct Operation Of The Control Panel After Installation
- check the correctness of activation of the potential outputs that control the actuating devices by observing the control LEDs on the module PCB (printed circuit board) at each potential line connector or by measuring the voltage at the output before and after activation, IGNIS 2500 AUTOMATIC FIRE EXTINGUISHING CONTROL PANEL... -
Page 23: Packaging, Storage, Transportation
Packaged units should be transported in covered means of transport, taking into account the transport instructions given on the packaging and protected against sudden shocks and ambient temperatures exceeding the range from -25 °C to +55 °C. ID-E359-003-GB/07.2024 IGNIS 2500 AUTOMATIC FIRE EXTINGUISHING CONTROL PANEL... - Page 24 ID-E359-003-GB IGNIS 2500 AUTOMATIC FIRE EXTINGUISHING CONTROL PANEL...
