- Page 1 IK-E337-001GB FIRE ALARM SYSTEM POLON 6000 CONTROL ELEMENT TYPE EKS-6000 Installation and Maintenance Manual IK-E337-001GB Issue ID...
- Page 2 IK-E337-001GB EKS-6000 control elements, the subject of this manual, meet the essential requirements of the following regulations of the European Parliament and Council (EU) as well as European Union directives: CPR/305/2011 Regulation (EU) no. 305/2011 of the European Parliament and of the...
- Page 3 IK-E337-001GB Polon-Alfa S.A. 85-861 Bydgoszcz, ul. Glinki 155 1438 1438-CPR-0375 Control element, typeEKS-6000 versions: EKS-6044, EKS-6022, EKS-6040, EKS-6004, EKS-6202, EKS-6400 EN 54-18, EN 54-17 Declaration of Performance no. 1/E337/2014/PL Harmonised technical Product essential characteristic Performance specification EN 54-18:2005 Chapter Reaction delay...
- Page 4 IK-E337-001GB Harmonised technical Product essential characteristic Performance specification EN 54-18:2005 Chapter Durability and operation reliability: electrical stability Properties and resistance to Compliant power supply parameter change Resistance to electromagnetic interference Compliant 5.12 Harmonised technical specification Product essential characteristic Performance EN 54-17:2005 Chapter Efficiency in fire conditions Reproducibility...
-
Page 5: Table Of Contents
Figure 2 Dimensions of EKS-6004, EKS-6202, EKS-6400 ................9 Figure 3 Dimensions of EKS-6022 ......................9 Figure 4 Dimensions of EKS-6044 ......................10 Figure 5 Wiring diagram of EKS-6044 ...................... 15 Figure 6 Wiring diagram of EKS-6202 ...................... 16 Figure 7 Enclosure cover with EKS-6000 terminal functions..............17... -
Page 6: Intended Use
EKS-6000 low-voltage inputs (IN) are designed for independent, volt-free contacts that are normally closed or normally open. EKS-6000 high-voltage inputs (IN HV) are designed for independent contacts at 6-220 VDC or 230 VAC. EKS-6000 inputs allow the connection of devices if current consumption does not exceed 2 A. -
Page 7: Technical Data
IK-E337-001GB 2. Technical data Control element type EKS-6040 EKS-6004 EKS-6022 EKS-6044 EKS-6202 EKS-6400 Detection line supply voltage 16.5 - 24.6 V Current consumption from detection line < 210 µA < 240 µA < 220 µA < 240 µA < 250 µA <... -
Page 8: Description Of The Design
IK-E337-001GB 3. Description of the design EKS-6000 control element is designed in the form of a printed circuit board with electronic components and a connector set, that has been put inside an enclosure. The enclosure has wall mounting holes in the corners. - Page 9 IK-E337-001GB Figure 2 Dimensions of EKS-6004, EKS-6202, EKS-6400 Figure 3 Dimensions of EKS-6022...
-
Page 10: Description Of The Operation
Figure 4 Dimensions of EKS-6044 4. Description of the operation The communication between POLON 6000 control panel and EKS-6000 control element is carried out via an addressable two-wire detection line. Unique, fully digital communication protocol enables transferring any information from the control panel to the element and from the element to the control panel. - Page 11 IK-E337-001GB Location: reporting using a button Non-volatile memory corruption: erroneous data stored in non-volatile memory The way the control element is supposed to operate is determined by the operation mode of this element. The mode of operation of a control element is defined by several data bytes, which indicate the mode of operation and behavior of this element.
-
Page 12: Operating Modes Of The Control Element
IK-E337-001GB powered with e.g. 48 VDC, the jumper should be set to LO1, which corresponds to a low state of about 3 V. The same rules apply to IN HV inputs. If the IN HV outputs or inputs are not used, the position of corresponding jumpers is not relevant. 5. - Page 13 IK-E337-001GB The following table shows the configuration of the control element based on the operation mode of the control output: Control input operation mode Parameters to be defined Profile Profile Continuous Group number Trigger delay time Reset delay time – T T ow T ok Profile...
-
Page 14: Operating Conditions
258 (available for purchase at Polon-Alfa). Connect the cables as described at the connectors. There is a sticker on the enclosure cover that shows the functions of EKS-6000 terminals, depending on the element type, as shown in the drawing: Figure 7. Connect the shields of detection line cables to the fields marked as SHLD. - Page 15 IK-E337-001GB It is recommended that EKS-6000 control elements to be installed outside should be equipped with a "Pressure compensation element". To do this, drill a 12 mm dia. hole at any point on the side wall of the enclosure base (e.g. near the nameplate) and fix the "Pressure compensation element" with a lock nut.
- Page 16 IK-E337-001GB Detection line L1– TEST + – ROP-4001 – – L2– SHLD SHLD EKS-6202 TUN-4046 OFF1 – – Controlled Power device – supply 1A (NO1) Detection 12 VDC 1B (COM1) line loop – 1C (NC1) Controlled Power device supply 2A (NO2) 230 VAC 2B (COM2) 2C (NC2)
- Page 17 IK-E337-001GB Figure 7 Enclosure cover with EKS-6000 terminal functions...
-
Page 18: Safety Conditions
9. Storage and transport 9.1. Storage EKS-6000 control elements should be stored in closed rooms, with no corrosive fumes or gases, at the temperature range from 0°C to +40°C, with relative humidity not exceeding 80% at the temperature of +35°C.
