Vertiv™ CoolChip 1-Phase Fluid
Network (In-Rack Manifold)
Bracket for VE Racks
Quick Installation Guide
Required Tools:
• PPE defined by OSHA standards (gloves)
• T20 Torx Key
• T25 Torx Key
Components
Table 1. VE Mounting Bracket Components
Item
Description
1
VE Bracket
2
Torx Screw M4
3
Mounting Hardware Bag
PROPRIETARY AND CONFIDENTIAL ©2024 VERTIV GROUP CORP.
2
1
3
X16
Qty.
4
16
1
SL-71203_REVA_05-24 1
