Ares AR900II Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
AR900II SERIES
1KVA ~ 3KVA
(110V / 120V / 220V)
www.arestech.vn

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AR900II Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ares AR900II Series

Summary of Contents for Ares AR900II Series

  • Page 1 User Manual AR900II SERIES 1KVA ~ 3KVA (110V / 120V / 220V) www.arestech.vn...

  • Page 2: Table Of Contents

    Table of Contents 1 Safety Information ..........................- 1 - 1.1 UPS safety information ........................- 1 - 1.2 Battery safety information ........................- 1 - 2 Product Overview ........................... - 2 - 2.1 Front panel features ........................... - 2 - 2.2 Rear panel features ...........................

  • Page 3: Safety Information

    1 Safety Information 1.1 UPS safety information ●Read all safety information and operating instructions carefully before attempting to install, service or maintain the UPS. Save this manual properly for reuse. ●This UPS is intended for indoor use only. ●Do not operate this UPS in direct sunlight, in contact with fluids, or where there is excessive dust or humidity.

  • Page 4: Product Overview

    2 Product Overview 2.1 Front panel features 2.2 Rear panel features 2.2.1 The type of 220V (output voltage is 208V/220V/230V/240V) RS232 RS232 TEL/MODEM/FAX TEL/MODEM/FAX RS232 TEL/MODEM/FAX OUTPUT SOCKET OUTPUT SOCKET OUTPUT FUSE 250VAC RESET FUSE 250VAC RESET RESET FUSE 250VAC INPUT 36VDC 30A 72VDC 30A...

  • Page 5: Installation

    ① Input power terminal ⑦ Intelligent slot ② Overcurrent protector ⑧ Surge ③ Fan ⑨ Battery ④ USB ⑩ Output sockets ⑤ EPO (Emergency Power Off) ○ Terminal ⑥ RS232 port Note: The figure is for reference only. Due to the technology upgrading and development, the real unit might be different from the figure.

  • Page 6: Installation And Output Connection

    ●For all standard type UPS, it is advised to charge the battery over 8 hours before used. Once the AC mains power energizes the UPS, it will automatically charge the battery. Without prior charging, UPS output remains as usual but with shorter back-up time than normal. ●When connected to motor, display equipment, laser printer etc, UPS power selection should be based on the startup power of the load which is usually twice as rated power.

  • Page 7: Network Functions

    Battery Quantity Battery Voltage Type (unit) (volt) 1KVA 24/36 1.5KVA 2KVA 48/72 3KVA 72/96 ●One end of battery cable is for UPS terminals while the other end with triple cables is for battery terminals. Correct installation procedure is highly vital or else probable electric shock will arise. Users are strictly required to follow the below procedure.
  • Page 8 Foot Explanation date+ date- Note: RS232 interface is set as below: ●Bit rate: 2400bps ●Byte: 8bit ●Completion code: 1bit ●Bit pattern: None 3.5.2 EPO port (optional) EPO is the short for Emergency Power Off. EPO port is on the rear panel of the UPS. It’s green. Users can cut off the output of UPS immediately by operating EPO port in case of emergency.

  • Page 9: Panel Function And Operation

    UPS status and input power, and even possible to control UPS via net management system. > Dry contact card (optional) Insert the dry contact card into the intelligent slot. It’s another type function of intelligent monitoring. Foot Definition PIN1 ON：UPS is malfunctioning PIN2 ON：Alarm（system failure）...

  • Page 10: Led Function

    the self-test function. Press and hold the two keys for more than 1 second in battery mode: UPS runs the mute function. ※ INQUIRING KEY ( Non-function setting mode: Press and hold for more than half a second (less than 2 seconds): display the items orderly. Press and hold for more than 2 seconds: Circularly and orderly display the items every 2 seconds, when press and hold the key for some time again, it will turn to output status.

  • Page 11: Lcd Display Function

    4.3 LCD display function LCD displays as following figure. Icon display area Digital display area Working mode display area ※ Icon display area: A. The top diagram is for load and battery capacity indication, each grid of which represents 25%. When UPS is over load, the load light will blink the same as the battery light blink when the capacity of battery get low or battery disconnected.

  • Page 12: Single Ups Self-Test/Mute Operation

    ② Press and hold the ON key for more than half a second to start the UPS, then it will start the inverter. ③Once started, the UPS will perform a self-test function, and LED will light and go off circularly and orderly. When self-test finishes, it will come to online mode, the corresponding LED lights, UPS is working in line mode.
  • Page 13 and the “ON” or “OFF” will light without flash. ④ Exit from the setting interface. Press and hold function setting key for more than 2 seconds, exit from the setting interface and return to main interface. 4.6.2 Bypass mode setting ①...
  • Page 14 than 2 seconds), select the function setting, choose output voltage setting interface, at the moment, the letters “OPU” will flash. ② Enter the output voltage setting interface. Press and hold the function setting key for more than half a second(less than 2 seconds), then come to setting interface of output voltage OPU, at this time, the letters “OPU”...
  • Page 15 achieve the voltage you chose. ③ Confirm the battery voltage selecting interface. After selecting numerical value, press and hold the function setting , for more than half a second (less than 2 seconds). Now, the battery setting function is completed and the numerical value will light without flash. ④...

  • Page 16: Parameters Inquiring Operation

    4.6.7 EPO setting Set this function by the UPS’s serial interface(RS232). Use computer to send one of these three commands(EPO0, EPO1, EPO2) you need by RS232 communication. If it is altered Successfully, the computer will receive ‘ACK’. If it is not, it will receive ‘NACK’. EPO is Emergency Power Off.

  • Page 17: Operation Mode

    Input: Display the voltage and frequency of the input. As the following graphics shows: the input voltage is 220V, input frequency is 50Hz. Battery: Display the voltage and capacity of the battery (determined by type). As the following graphics shows: the battery voltage is 192V, the capacity of battery is 100% (the capacity of battery is approximately reckoned according to the battery voltage).

  • Page 18: Line Mode

    Note: When UPS is working in bypass mode, it has no back up function. 5.2 Line mode LED indications on front panel in line mode or CUCF mode are as following: The inverter green LED is on. When input AC mains correspond to the working conditions, UPS will work in line mode. 5.3 Battery mode LED indications on front panel in battery mode are as following: both the inverter green LED and battery yellow LED is on, the buzzer beeps once every 4 seconds.

  • Page 19: Fault Messages And Alarm

    6 Fault Messages and Alarm Table 1: Fault code messages Fault code Fault type Bypass output Note 0、1、2、3、4 Bus high 5、6、7、8、9 Bus low 10、11、12、13、14 Bus unbalance 15、16、17、18、19 Bus soft start fail 20、21、22、23、24 Inverter soft start fail 25、26、27、28、29 Inverter high 30、31、32、33、34 Inverter low 35、36、37、38、39 Bus discharge fail...

  • Page 20: Troubleshooting

    voltage warning (under Bypass) Mains power – low ★ voltage warning (under ● One beep / 4 sec Bypass) Warning for battery disconnected ★ Bypass mode ● One beep / 4 sec ★ Inverter mode ● One beep / 4 sec Power on / Switch on 6 beeps Output overload protection...
  • Page 21 Problem Possible Cause Solution Fault LED on, audible buzzer Please test the bus bar voltage or contact Persistently alarm, the fault code Bus bar voltage fault the supplier. is 00-14 Fault LED on, audible buzzer Please check the soft start up circuit, persistently alarm, the fault code Soft start fault especially the soft start resistance or...

  • Page 22: Appendix 1: Emc Level

    The input connection is Please connect the input well, if the battery not ready or voltage is too low, please disconnect the UPS internal battery input and start the UPS with no-load. disconnect UPS internal system Please contact the supplier. fault Please keep the UPS battery recharging Battery undercharge...

  • Page 23: Appendix 3: Specifications

    Appendix 3: Specifications Rated Capacity 1KVA 1.5KVA 2KVA 3KVA Input Rated input voltage 220V or 120V Rated input frequency 50Hz/60Hz auto-adaptive Input voltage range (115～295)±5VAC (half load) (the type of 220V) (145～295)±5VAC(full load) Input voltage range (55～145)±5VAC (linear derating between 50% and 100% (the type of 120V) load);...

  • Page 24: Appendix 4: Physical (The Type Of 220V)

    Standard model:1A Charge current Long time model: 6A System Control and Communication Function Silence; cold start; AC restart; Auto restart. Over-temp protection; Fan testing protection; Protection AC L and N reversely connecting protection; Output short circuit protection Communication port RS232; SNMP card; USB Graphics analyze;...

This manual is also suitable for:

Ar900ii 1kva ar900ii 1.5kva ar900ii 2kva ar900ii 3kva
