Thanks for using our products
Please strictly obey all the instructions in this manual and pay attention to all the warning and operation
information. It is not advisable to install or operate the machine before reading this manual.
1. Safety instructions
●The power output voltage may still have 220V or 120V even not connect to the mains power.
●For the battery cable or power cord replacement, please contact our service station or dealer to purchase, in
order to avoid fire caused by inadequate capacity or heat ignition.
●Do not place the battery or battery pack in the fire, which will injure due to explosion.
●Please do not open the UPS case as you will, there is risk of electric shock
●Do not touch the battery connection terminals. Battery loop and input voltage loop is without isolation, which
may cause high voltage risk between the battery terminal and ground.
●Do not connect to the equipment like hair dryer or electric heater, to ensure the safety for the UPS
Attention:
UPS has high voltage inside, for personal safety, please do not repair by yourself. If any questions, please
contact local service center or dealer.
2. Installation instructions
2.1 Unpacking inspection
●Open the UPS package, please check the enclosed accessories including a user manual, communication
cable, CD-ROM. The long-back model also includes the cable for connection to battery bank.
●Check the UPS if any damage in transport. If find damaged or parts missing, do not power on, please turn to
the carrier and dealer.
●To determine whether this UPS is the model you want to buy. Check the model name showed both on the
front panel and rear panel of UPS to confirm.
Model
Type
1KVAS
1KVA Standard model
1.5 KVAS
1.5 KVA Standard model
2KVAS
2KVA Standard model
3KVAS
3KVA Standard model
6KVAS
6KVA Standard model
10KVAS
10KVA Standard model
Note:
Please save the packaging box and packaging materials for future transport use. As heavy product, please
transit the UPS with care.
USER MANUAL
(ONLINE UPS)
Model
1KVAH
1.5 KVAH
2KVAH
3KVAH
6KVAH
10KVAH
Type
1KVA Long backup model
1.5 KVA Long backup model
2KVA Long backup model
3KVA Long backup model
6KVA Long backup model
10KVA Long backup model
Advertisement
Related Manuals for Ares 1KVAS
Summary of Contents for Ares 1KVAS
- Page 1 ●To determine whether this UPS is the model you want to buy. Check the model name showed both on the front panel and rear panel of UPS to confirm. Model Type Model Type 1KVAS 1KVA Standard model 1KVAH 1KVA Long backup model 1.5 KVAS 1.5 KVA Standard model 1.5 KVAH...
- Page 2 2.2 Attention items of installation ●The UPS installation environment must be with good ventilation, away from water, flammable gases and corrosive entities. ●Do not lie down the UPS against the wall so that front and side panel air intake hole, rear panel air outtake hole will be unobstructed.
- Page 3 RS232 INTELLIGENT SLOT TEL/MODEM/FAX 计算机接口 WARNING HIGH LEAKAGE CURRENT EARTH CONNECTION ESSENTIAL INPUT BREAKER BEFORE CONNECTING SUPPLY 80A 250VAC INPUT OUTPUT ～ ～ L1 N1 L2 N2 DO NOT OPEN EXCEPT QUALIFIED TECHNICIAN + + - - d. 6KVA &10KVA Long back up e.
- Page 4 Ground Battery Over Current Protector Output Input Input Output LOAD (2) To the type of 6~10KVA witch contains isolation transformer, there are more methods of output connection. Before installing, prepare wires for terminal block of the UPS based on the following table. Wiring spec(AWG) Model Input...
- Page 5 Note: ①Make sure the wires are connected tightly with the terminals. ②There are two output terminals to meet customers’ diverse requirements for serial or parallel connection. We will introduce the methods of connection later. ③Please install the output breaker between the output terminal and the load, and the breaker should be qualified with leakage current protective function if necessary.
- Page 6 ★ Option3: L2 L1 L1 N1 L2 N2 To Load After connecting N1 and L2, it becomes one low-voltage output (208V/220V/230V/240V) at L1-N2 for 100% of UPS rating power. Connect load to L2-N1 ★ Option4: L1 N1 L2 N2 L2 L1 To Load 1 To Load 2 To Load 3...
- Page 7 1KVA 24/36 1.5KVA 2KVA 48/72 3KVA 72/96 6KVA 14/16 168/192 10KVA 14/16 168/192 ●One end of battery cable is for UPS terminals while the other end with triple cables is for battery terminals. Correct installation procedure is highly vital or else probable electric shock will arise. Users are strictly required to follow the below procedure.
- Page 8 ※ ON KEY ( Press and hold the two keys for more than half a second to turn on the UPS. ※ OFF KEY ( Press and hold the two keys for more than half a second to turn off the UPS. ※...
- Page 9 Bypass yellow LED is on: UPS is alarming. For example: Bypass mode supply power and etc. Battery yellow LED is on: UPS is alarming. For example: Battery mode supply power and etc. Inverter green LED is on: UPS is normally powered by mains or ECO mode or battery mode. PS: LED display detail in different mode is listed in 5 items.
- Page 10 i. Turn on the UPS on line mode ① Once mains power is plugged in, the UPS will charge the battery, at the moment, LCD shows that the output voltage is 0, which means UPS has no output as default condition. If it is expected to have output of bypass, you can set the BPS “ON”...
- Page 11 for a long time. The “ON” (or OFF) will flash. Press and hold the inquiring key ( ) for more than half a second (less than 2 seconds) to determine whether the ECO function is used or not. If used, the corresponding word is “ON”, if not, the word is “OFF”.
- Page 12 3.6.3 Output voltage setting ① Enter the setting interface. Press and hold the function setting key for more than 2 seconds, then come to setting interface, press and hold the inquiring key ( ) for more than half a second(less than 2 seconds), select the function setting, choose output voltage setting interface, at the moment, the letters “OPU”...
- Page 13 than 2 seconds), exit from the setting interface and return to main interface. 3.7 Parameters inquiring operation Press and hold the inquiring key for more than half a second(less than 2 seconds) to inquire about items. The inquired items include input, battery, output, load and temperature. The displayed items on LCD screen are showed as following: Output：Display the output voltage and output frequency of the UPS.
- Page 14 Input: Display the voltage and frequency of the input. As the following graphics shows: the input voltage is 220V or 120V, input frequency is 50Hz. Battery: Display the voltage and capacity of the battery (determined by type). As the following graphics shows: the battery voltage is 24V or 36V, the capacity of battery is 100% (the capacity of battery is approximately reckoned according to the battery voltage).
- Page 15 yellow LED is on, the buzzer beeps once every 4 seconds. The warning red LED will be on while beeping. When the mains power is low or unstable, UPS will turn to battery mode at once. 4.4 ECO mode LED indications on front panel in ECO mode are as following: both the inverter green LED and bypass yellow LED are on.
- Page 16 Input NTC fault 55-59 Power fault 60-64 Input FUSE fault 65-69 Other Appendix 2: Table for working status LED on Front panel S/N Working status Alarm beep Note Normal Battery Bypass Fault Inverter mode (mains power) ● Mains power voltage Mains power high/low voltage ●...
- Page 17 overload Warning for battery ● ● ★ 2 beeps / sec overload Protect operation for ● ● ● battery mode Long beep overload Warning for bypass ● ★ One beep / 2 sec mode overload ▲ ▲ ▲ ★ Fans fault(fan icon） One beep / 2 sec ●...
- Page 18 Fault LED on, audible buzzer persistently alarm, the fault code is Inverter voltage fault Please contact the supplier. 25-39 Please make sure the UPS didn’t get overload, and the fan vent was not Fault LED on, audible buzzer obstructed, as well as the indoor Over temperature persistently alarm, the fault code is temperature is not high.
- Page 19 disconnect the noncritical devices, Please change new battery, contact your Battery maturing, supplier to get the new battery and spare capacity descend parts. UPS doesn’t have any power go UPS input breaker Please reset the circuit breaker by manual. through even main power on disconnects Attention: When the output is short-circuited, the action of the protection of the UPS will show up.
- Page 20 GB9254-1998/IEC 62040-2 Class B Appendix 2: Symbol instructions: Symbols and significations Symbol Significations Symbol Significations Caution Protect grounding Danger! High Voltage! Alarm cancel Turn on Overload Turn off Battery inspection Standby or Shutdown Repeat Display screen repeat key Battery Appendix 3: Specification Sheet (1-3KVA) Rated Capacity 1KVA 1.5KVA...
- Page 21 From BAT mode to AC mode 0ms(transfer time) ≧90 % (full load) Mains mode Efficiency BAT mode ECO mode Output frequency Under Mains mode Same as input frequency Under battery mode (50/60±0.2)Hz ≤1Hz/s Phase-locked rate Total voltage harmonic Full linear load< 3%；Full nonlinear load< 5% distortion Battery Battery type...
- Page 22 Output power(Watt) 4800 5400 8000 9000 105%～125%: 10 mins; 105%～125%: 3 mins; 105%～125%: 10 mins; 105%～125%: 3 mins; Inverter overload capability 125%~150%: 30 secs; 125%~150%: 30 secs; 125%~150%: 30 secs; 125%~150%: 30 secs; ＞150%: 100ms; ＞150%: 100ms; ＞150%: 100ms; ＞150%: 100ms; Voltage accuracy ±0.2 Load crest...
- Page 23 Containing isolation transformers Long 262*514*455 262*650*735 262*514*455 262*650*735 Dimension (W*D*H) Standard 262*514*735 262*650*735 262*514*735 262*650*735 Long Weight (Kg) Standard Appendix 6: Physical (The type of 120V) Rated Capacity 1KVA 1.5KVA 2KVA 3KVA Long 144*357*215 190*452*341 Dimension (W*D*H) Standard 144*357*215 190*452*341 Long Weight (Kg) Standard...
