Troy-Bilt TB70SS Operator's Manual

2-Cycle Trimmer
TB70SS
Quick Instructions to
Assemble Straight
Shaft String
Trimmers
for complete instructions
see page 3.
Quick Instructions
to Start Engine
for complete instructions see page 4.
Quick Instructions to
®
Replace SplitLine
Trimmer Line
®
Replacement SplitLine
Part #49U2341K953
For single line installation,
see page 4.
For replacement spool
installation, see page 4.
Wind line tightly in direction of arrow.
Split other end of SplitLine
IMPORTANT: READ OPERATOR'S MANUAL THOROUGHLY AND FOLLOW THE SAFE OPERATION PRACTICES BEFORE OPERATING THE UNIT.
Call 1–800–828–5500 in U.S. or 1–800–668–1238 in Canada
PART NO. 769-04297 P00
Read and understand all instruction, warning and danger labels on the unit.
Place the shield onto the mount bracket.
Screw the 2 shield screws into the 2 holes
on the mount bracket and tighten.
Press primer bulb 10 times.
Move blue choke
lever to Position 2.
Push 6"-7" ends into
®
back 6"-7". 0.095" holding slots.
Need help?
DO NOT RETURN THIS PRODUCT
For Assistance please call 1-800-828-5500 (U.S.) or 1-800-668-1238 (Canada)
or visit www.troybilt.com or www.troybilt.ca
6"
Put handle on shaft. Move handle
6 inches away from shaft grip.
Insert clamp bolt and tighten
using the appropriate tool.
Put blue choke lever Crouch in starting
in Position 1. position.
Pull the rope 3 to 5 times to Move blue choke
start. Run engine for 30-60 lever to Position 3.
seconds to warm up.
Spool
Spring
Inner
Reel
Bump
Knob
Unscrew Bump Knob™ Insert 10' of 0.095"SplitLine
counterclockwise. Remove hole in top of reel. Pull most of line
through hole until 3"-4" remains.
inner reel and spring.
Insert lines through eyelets in spool.
Insert spring and reel into spool.
Operator's
Manual
40:1
1 Gallon
Mix thoroughly in a separate fuel can:
– 3.2 fl. oz. of 2-cycle engine oil
– 1 gallon of unleaded gasoline
Place the unit on a level surface. Fill fuel tank.
NOTE: Do not mix directly in the engine fuel tank.
SQUEEZE and HOLD throttle
Pull the rope
control for ALL further steps.
5 times.
DIDN'T START?
Repeat these instructions.
If engine still fails to start, refer
to page 4 of this manual
Continue squeezing the
for additional starting and
throttle control and run engine
for additional 60 seconds to
complete warm up.
3"-4"
®
through Bend short end and push it
into the other hole. Pull tight.
Hold the inner reel in place. Pull lines firmly to release
Tighten Bump Knob clockwise. from holding slots.
3.2 oz
5 X
troubleshooting
information.
