- Page 1 GROOVE ASSEMBLY INSTRUCTIONS Designers of acoustic and environmentally sustainable office solutions...
- Page 2 GROOVE ASSEMBLY INSTRUCTIONS COMPONENTS 90 degree junction connector 360 degree junction connector Secondary strut 180 degree junction connector Main strut...
- Page 3 GROOVE ASSEMBLY INSTRUCTIONS STEP 1 STEP 2 • Lay a group of main struts on the floor and insert secondary struts as per required design to form first wall. • Position the first wall upright and insert junction connectors. • Main struts can be spaced out as desired with gaps or no Either 90 / 180 / 360 degree depending on desired layout.
- Page 4 GROOVE ASSEMBLY INSTRUCTIONS STEP 3 STEP 4 • Create and insert a second wall to your junction connectors. • Continue to build your desired layout using additional walls and junction connectors to change direction as seen in step 4 and 5.
- Page 5 GROOVE ASSEMBLY INSTRUCTIONS STEP 5 • Build up your main structure. • You can always go back to any wall and insert or remove main and secondary struts to create more or less density or alter the lattice pattern. • You can use both main and secondary struts either horizontally or vertically to...
- Page 6 GROOVE ASSEMBLY INSTRUCTIONS Sheet Thickness 24mm Dimensions 2058mm (h) x 240mm (w) - Main strut 1156mm (h) x 240mm (w) - Secondary strut...
- Page 7 Telephone Francois: +44 7305 349443 Daniel: +27 82 331 8319 Email studio@14six8.com GROOVE Website www.14six8.com Address 71-75, Shelton Street, Covent Garden, ASSEMBLY INSTRUCTIONS London, WC2H 9JQ, United Kingdom...
