Page 11: Chapter 1 Introduction
In case any modifications of this documentation occur, the updated version will be available on ASRock Industrial’s website without further notice. If you require technical support related to this product, please visit our website for specific information about the model you are using.
Page 12 • 1 x Displayport, 1 x HDMI 2.0b, 1 x VGA • Powerful Edge AI acceleration enabled by the most flexible mechanical, thermal, and power design, with support for 275mm x 138 mm x 60 mm (L x H x D) max. and up to 600W graphic cards iEPF-9032S-EW4 •...
Page 13 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E iEP-9032E • Intel® 14th Gen Core™ Processors with H610 Chipset • 2 x 262-pin DDR5 SO-DIMM up to 96GB (48GB per DIMM) • 1 x M.2 Key M, 2 x M.2 Key B, 1 x M.2 Key E •...
Page 14: Package List
1.2 Package List iEP-9030E Series No. Accessories Q'ty Picture Description Protect the device from Rubber Foot damage while moving it. #6-32 x 8 Screw for To fix the rubber foot. rubber foot To attach the device to any Desk Mount horizontal surface.
Page 15 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E No. Accessories Q'ty Picture Description Terminal For Digital Input and Block 1x10P 12G082000103AI Digital Output. ST 3.5m M3x4 Screw 13G020570000AI To fix the SSD/HDD. for SSD/HDD M2 Nut (w/ To fix NUT.
Page 16 iEP(F)-9030S Series No. Accessories Q'ty Picture Description Protect the device from Rubber Foot damage while moving it. #6-32 x 8 Screw for To fix the rubber foot. rubber foot To attach the device to any Desk Mount horizontal surface. M4x10 Screw To fix the desk mount to for desk chassis and fix to desk...
Page 17 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E No. Accessories Q'ty Picture Description Terminal Be used to safely connect two Block 1x3P ST 12G082000033AI or more wires together. 5.0m Terminal For Digital Input and Digital Block 1x10P 12G082000103AI Output.
Page 18 1. If any items are missing or appear damaged, contact your authorized dealer. 2. Based on different configuration, package list may be different. Note: Please refer to the following for more information about the adapters: 330W Power adapter - Input voltage: 100-240V AC - Input frequency: 47-63 Hz (±1Hz) - Rating output current: 13.75A - Rating output voltage: 24.0 V ±5%...
Page 19: Order Information
iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 1.3 Order Information Model Name Description Intel®14th Gen Core™ Processors with R680E iEP-9030E 90PXGCA0-70000000 chipset, W/O CPU, RAM, SSD, ADAPTER Intel®14th Gen Core™ Processors with H610 iEP-9032E 90PXGCY0-70000000 chipset, W/O CPU, RAM, SSD, ADAPTER Intel®14th Gen Core™...
Page 20: Serial Number Label
1.5 Serial Number Label The serial number is printed below or above the bar code and can be found on the rear side of the chassis. 1.5.1 Serial Number Label Location iEPF-9030S Series iEP-9030E Series 1.5.2 Serial Number Label Illustration...
Page 21: Specifications
iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 1.6 Specifications iEPF-9030S-EW4 Intel® 14 Gen Core™ Processors Processor Chipset Intel® R680E System Socket LGA 1700 Dual Channel DDR5 5600MHz Technology (ECC memory supported by R680E + Selected CPU) Memory Capacity 96 GB (48GB per DIMM)
Page 22 DisplayPort HDMI Ethernet 5 x Intel 2.5G LAN 6 x USB 3.2 Gen2x1, 1 x USB 2.0 internal connector w/ Front I/O lock function Audio 1 x Mic-in, 1 x Line-out 4 x RS232/422/485 (COM1, COM2-optional Card w/ Isolation Protection, COM5-Isolation Protection, COM6) 2 x RS232 (COM3, COM4) 8 DIs/8DOs Output...
Page 23 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E iEPF-9032S-EW4 Intel® 14 Gen Core™ Processors Processor Chipset Intel® H610 System Socket LGA 1700 Technology Dual Channel DDR5 5600MHz Memory Capacity 96 GB (48GB per DIMM) Socket 2 x 262-pin SO-DIMM Controller Intel®...
Page 24 DisplayPort HDMI Ethernet 4 x Intel 2.5G LAN 4 x USB 3.2 Gen2x1, 2 x USB 2.0, 1 x USB 2.0 internal Front I/O connector w/ lock function Audio 1 x Mic-in, 1 x Line-out 4 x RS232/422/485 (COM1, COM2-optional Card w/ Isolation Protection, COM5-Isolation Protection, COM6) 2 x RS232 (COM3, COM4) 8 DIs/8DOs...
Page 25 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E iEP-9030E Intel® 14 Gen Core™ Processors Processor Chipset Intel® R680E System Socket LGA 1700 Dual Channel DDR5 5600MHz Technology (ECC memory supported by R680E + Selected CPU) Memory Capacity 96 GB (48 GB per DIMM) Socket 2 x 262-pin SO-DIMM...
Page 26 DisplayPort HDMI Ethernet 5 x Intel 2.5G LAN 6 x USB 3.2 Gen2 x1, 1 x USB 2.0 internal connector w/ Front I/O lock function Audio 1 x Mic-in, 1 x Line-out 4 x RS232/422/485 (COM1, COM2-optional Card w/ Isolation Protection, COM5-Isolation Protection, COM6) 2 x RS232 (COM3, COM4) 8 DIs/8DOs Output...
Page 27 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E iEP- 9032E Intel® 14 Gen Core™ Processors Processor Chipset Intel® H610 System Socket LGA 1700 Technology Dual Channel DDR5 5600MHz Memory Capacity 96 GB (48 GB per DIMM) Socket 2 x 262-pin SO-DIMM Controller Intel®...
Page 28 Output From Super I/O to drag RESETCON# Watchdog Timer Interval 256 Segments, 0, 1, 2, ...255sec 9V~36V VDC with Ignition control and remote power on/off switch. Power Input PWR 80V Surge Protection, OVP, UVP, OCP and reverse Requirements protection Ignition Power Input w/ 13-mode condition 35W CPU: -40°C~70°C (-40°F~158°F) Operating 46W~65W CPU: -40°C~50°C (-40°F~122°F) (w/ air flow...
Page 29: Cpu Support List
iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 1.7 CPU Support List iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEP-9030E iEPF-9030S-EW4 CPU Support List The Performance of CPUs over 80W will be limited due to power design. *The Performance of CPUs over 80W will be limited due to power design. Socket Family Number...
Page 30 iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9032E iEPF-9032S-EW4 CPU Support List The Performance of CPUs over 80W will be limited due to power design. *The Performance of CPUs over 80W will be limited due to power design. Socket Family Number Core Frequency Cache Power Since BIOS...
Page 31: Dimensions And Size
iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 1.8 Dimensions and Size iEPF-9030S-EW4 /iEPF-9030S-EY4/ iEPF-9032S-EW4/iEPF-9032S-EY4 Front View 201.7 mm iEPF-9030S-EW4 /iEPF-9030S-EY4 201.7 mm 209 mm iEPF-9032S-EW4/iEPF-9032S-EY4...
Page 32 Top View 290.8 mm 201.7 mm 290.8 mm 209 mm 209 mm Right-Side View...
Page 33 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E Left-Side View Rear-Side View 90.8 mm...
Page 34: Bottom View
Bottom View Desk Mounting Bracket 237 mm 162 mm...
Page 35 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E iEP-9030E / iEP-9032E Front View 201.7 mm iEP-9030E 201.7 mm iEP-9032E...
Page 36 Top View 244.8 mm 244.8 mm Right-Side View 109.5 mm 109.5 mm...
Page 37 244.8 mm iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E Left-Side View Rear-Side View 109.5 mm Bottom View...
Page 38 Desk Mounting Bracket 237 mm 162 mm...
Page 39: Block Diagram
iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 1.9 Block Diagram iEP(F)-9030 Series DSB-1220-WT SO-DIMM Channel A DDR5 Display port Intel (A1) 5600MHz Connector Alder Lake-S & SO-DIMM Channel B DDR5 Raptor Lake-S 5600MHz (B1) HDMI SN65DP159 HDMI Raptor Lake-S refresh PCIe x16 or...
Page 40 iEP(F)-9032 Series DSB-1222-WT SO-DIMM Channel A DDR5 Display port Intel (A1) 5600MHz Connector Alder Lake-S & SO-DIMM Channel B DDR5 Raptor Lake-S 5600MHz (B1) HDMI SN65DP159 HDMI Raptor Lake-S refresh PCIe x16 Gen5 PCIe x16 Processor DSC-SLOT005-WT CH7517A- LGA-1700 Connector Intel MDI 2.5G PCIe x1...
Page 41: Chapter 2 Product Overview
iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E Chapter 2 Product Overview This chapter provides diagrams that display the location of important components of the system. 2.1 System Front Panel 10 11 Item Description 1, 9, 10, 32, Antenna Port 1~4 Connect the antenna cable to these connectors.
Page 42 Item Description M.2 Slot (Key M) Status If M.2 slot is populated with M.2 module and working, it will show a blinking green. The Mic-in audio connector on the I/O panel supports 5.1 channel HD audio and fully complies Audio Mic-in & Line- 14, 15 with Intel®...
Page 43: System Front Panel I/O Functions
iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 2.1.1 System Front Panel I/O Functions Serial Ports (COM1~COM6) No. 3 : COM1 No. 2 : COM2 No. 5 : COM3 No. 4 : COM4 No. 29 : COM5 No.
Page 44 Digital Input/Output No. 6 : Digital Input No. 7 : Digital Output (2) System front panel location (3) Icon / Pin definition: Signal Signal DIO0(SIO_GP70) DIO8(SIO_GP80) DIO1(SIO_GP71) DIO9(SIO_GP81) DIO2(SIO_GP72) DIO10(SIO_GP82) DIO3(SIO_GP73) DIO11(SIO_GP83) DIO4(SIO_GP74) DIO12(SIO_GP84) DIO5(SIO_GP75) DIO13(SIO_GP85) DIO6(SIO_GP76) DIO14(SIO_GP86) DIO7(SIO_GP77) DIO15(SIO_GP87)
Page 45 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E HDMI2.0b Port No. 12 : HDMI2.0b Port (2) System front panel location (3) Icon / Pin definition: Signal Signal TMDS Data2+ TMDS Clock Shield TMDS Data2 Shield TMDS Clock- TMDS Data2- TMDS Data1+ Reserved...
Page 46 M.2 Slot (Key M) Status LED No. 13 : M.2 Key-M (2) System front panel location (3) Description: Status Description M.2 Slot (Key M) on the motherboard is populated with a M.2 Blinking Green module. Empty M.2 Slot (Key M)
Page 47 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E Display Ports 1.4a No. 17 : Display Port (2) System front panel location (3) Icon / Pin definition: Signal Signal ML_Lane 0(p) ML_Lane 3(n) ML_Lane 0(n) ML_Lane 1(p) AUX_CH(p) ML_Lane 1(n) ML_Lane 2(p) AUX_CH(n)
Page 48 IGN Status LED No. 18 : IGN Status LED (2) System front panel location (3) Description: Status Description Solid Green The IGN connector is connected and working normally. No connection...
Page 49 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E USB 3.2 Gen2/USB 2.0 Ports No. 19 : USB 3.2 Gen2x1 Ports (R680E SKU) USB 2.0 Ports (H610 SKU) (2) System front panel location (3) Icon / Pin definition: USB 3.2 Gen2x1 Signal Signal...
Page 50 VGA Port No. 20 : VGA Port (2) System front panel location (3) Icon / Pin definition: Signal Signal DATA- DATA+ HSync RED_RTN VSync GREEN_RTN BLUE_RTN...
Page 51 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E PoE Ports Status LED No. 21 : PoE1 Port Status LED (PoE1) No. 22 : PoE2 Port Status LED (PoE2) (2) System front panel location (3) Description: PoE Port Status Description Solid Green...
Page 52 Ethernet Ports LED No. 23 : LAN RJ-45 PoE Port (PoE 2) No. 24 : LAN RJ-45 Port (LAN3)(R680E SKU only) No. 25 : LAN RJ-45 PoE Port (PoE 1) No. 26 : LAN RJ-45 Port (LAN 2) No. 27 : LAN RJ-45 Port (LAN 1, supports vPro) (2) System front panel location (3) Icon / Pin definition: LAN Port...
Page 53 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E USB 3.2 Gen1/Gen2 Ports No. 28 : 4 x USB3.2 Gen2 x1 Ports (R680E & H610 SKU) (2) System front panel location (3) Icon / Pin definition: USB 3.2 Gen2x1 Signal Signal +5V_USB_PWR...
Page 54: Hdd Panel
2.2 HDD Panel iEP(F)-9030 Series Description 2.5" HDD/SSD Tray (HDD0) 2.5" HDD/SSD Tray (HDD1) 2.5" HDD/SSD Tray (HDD3) 2.5" HDD/SSD Tray (HDD2) Side Vent (iEPF-9030S Series only) 2 x SIM Card Slots (SIM1 & SIM2 are for M.2 B key slot) System Heatsink...
Page 55: Drive Tray Leds
iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 2.3 Drive Tray LEDs Description HDD Power LED HDD Activity LED Status LED Definitions HDD LED Type Status Description Blue HDD powered-on HDD Power LED No power to HDD Solid Green HDD active HDD Activity LED...
Page 56: Motherboard
2.4 Motherboard 2.4.1 Motherboard Layout for iEP(F)-9030 Series Top Side 1 2 3 PWR_BAT1 CLRMOS1 VGA_PWR1 VGA_PWR6W1 DC_IN1 ESPI1 M2_ 1 M2_M1 BUZZ1 PCIE1 PCIE2 USB 3.2 Gen2 SATA_PWR1 Top: Middle: USB3_1 LAN1 Bottom: USB3_2 PCIE12V_CON1 USB2_10_11 PANEL1 CMOS SATA_CON1 SATA_CON2 Battery USB 3.2 Gen2...
Page 57 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E Bottom Side COMDIO_CON1 DIO9_15 SIM1 DDR5_B1 DDR5_A1...
Page 58 1 : 4-Pin 12V ATX Power Connector (VGA_PWR1) USB3_RX- USB3_RX+ UIM_RESET UIM_CLK Signal Name USB3_TX- UIM_DATA USB3_TX+ UIM_PWR PERn0 DC Input PERP0 DC Input Pl e as e c on ne c t a D C +9V ~ +36V PETn0 power supply to this connector.
Page 59 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 7 : SATA Connector (SATA_CON1) 9 : PCIE1 Signal Name Signal Name Signal Name +12V +12V +12V SATA_TXP4 +12V +12V SATA_TXN4 X16_ CLKREQ#_ SATA_RXP4 SATA_RXN4 PCH_ SMB_CLK_ ECLK_X8 MAIN SMB_ SATA_TXP5 PCH_...
Page 60 PEG_TXP5_ A73 PEG_RXN13 PEG_ PEG_ TXP14_R TXN5_R PEG_ PEG_RXP5 TXN14_R PEG_RXN5 PEG_RXP14 PEG_TXP6_ A77 PEG_RXN14 PEG_ PEG_ TXP15_R TXN6_R PEG_ PEG_RXP6 TXN15_R PEG_RXN6 PEG_RXP15 PEG_TXP7_ PEG_RXN15 +5VSB +5VSB PEG_ TXN7_R 10 : PCIE2 PEG_RXP7 Signal Name Signal Name PEG_RXN7 +12V CLKREQ# +12V +12V...
Page 61 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E PCH_PE_ +3.3V RXP3 PERn2 +3.3V PCH_PE_ PERp2 RXN3 PCH_PE_ PETn2 TXP4_C PETp2 PCH_PE_ TXN4_C PERn1 PCH_PE_ PERp1 RXP4 PCH_PE_ PETn1 RESERVED RXN4 PETp1 SMB_CLK PRSENT#_1 PERn0 SMB_DATA RESERVED PERp0 PCIE_4_ RESERVED TXP21_C...
Page 62 16 : Top : RJ45 LAN Port (LAN3) SPDIF header, providing SPDIF audio output to HDMI VGA card, allows the Middle/Bottom : USB 3.2 Gen2 Ports system to connect HDMI Digital TV/ projector/LCD devices. Please connect (USB_7_8) the SPDIF connector of HDMI VGA card to this header.
Page 63 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E RESERVED PCH_POE1_ RESERVED PCH_POE1_ RESERVED RESERVED PCH_POE1_ +3.3V RESERVED +3.3V PCH_POE1_ +3.3V RESERVED RESERVED 26 : M.2 Key-E Socket (M2_E1) PCH_POE2_ POE1_ Signal Name Signal Name DISABLE_N +3.3V PCH_POE2_ POE2_ USB_D+ +3.3V...
Page 64 CNV_WT_ Signal Name +MCU_VDD CNV_WT_ ICE_DATA ICE_CLK MCU_RESET# CNV_WT_ +3.3V CLK- CNV_WT_ +3.3V CLK+ 29 : HEADER1 1-2 : Clear CMOS2* 3-4 : SI AT Mode 27 : M.2 Key-M Socket (M2_M2) 5-6 : CI1 Signal Name Signal Name Open : Normal +3.3V Short : Active Case +3.3V...
Page 65 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E COM5, 6 Ports Pin Definition 34 : System Panel Header (PANEL1) RS232 RS422 RS485 RTX- RTX+ Signal Name Signal Name HDLED+ PLED+ HDLED- PLED- PWRBTN# 32 : Chassis FAN Connector (+12V) RESET# (CHA_FAN1) This header accommodates several...
Page 66 The front panel design may differ by C_ESPI_IO1 chassis. A front panel module mainly C_ESPI_IO2 consists of power switch, reset switch, C_ESPI_IO3 power LED, hard drive activity LED, speaker and etc. When connecting your +3VSB chassis front panel module to this header, make sure the wire assignments and the pin assignments are matched correctly.
Page 67 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E RI#2 GPP_I10_3V DSR#2 GPP_I0_3V DCD#2 GPP_E4 CTS#2 GPP_E2 GPP_B20 RTS#3 DTR#3 TXD3 RXD3 RI#3 TERM_1 DSR#3 SLEW_1 RS422_ DCD#3 FIX_1 CTS#3 MODE1_1 RTS#4 MODE0_1 DTR#4 TERM_2 TXD4 SLEW_2 RS422_ RXD4 FIX_2 RI#4...
Page 68: Motherboard Layout For Iep(F)-9032 Series
2.4.2 Motherboard Layout for iEP(F)-9032 Series Top Side 1 2 3 PWR_BAT1 CLRMOS1 VGA_PWR1 VGA_PWR6W1 DC_IN1 ESPI1 M2_ 1 M2_E1 BUZZ1 PCIE1 PCIE2 USB 3.2 Gen2 Top: Middle: USB3_1 LAN1 PCIE12V_CON1 Bottom: USB3_2 SATA_CON1 PANEL1 CMOS Battery USB 3.2 Gen2 Top: Middle: USB3_3 PCIE_ISOLATION...
Page 69 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E Bottom Side COMDIO_CON1 SIM1 DDR5_B1 DDR5_A1...
Page 70 1 : 4-Pin 12V ATX Power Connector (VGA_PWR1) USB3_RX- USB3_RX+ UIM_RESET UIM_CLK Signal Name USB3_TX- UIM_DATA USB3_TX+ UIM_PWR PERn0 DC Input PERP0 DC Input Pl e as e c on ne c t a D C +9V ~ +36V PETn0 power supply to this connector.
Page 71 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E PCH_ SMB_ PCH_ SATA4_ RESERVED MAIN_ ECLK_X8# RXN_C MAIN SMB_CLK PCH_ SMB_DATA SATA_SEL2 SATA5_TXP_ RESERVED +3VSB PCH_ BUF_PLT_ WAKE# SATA5_ RST# TXN_C RESERVED PCH_ PCH_ SATA5_ ECLK_X16_ RXP_C PCH_ PCH_ PEG_TXP0_ SATA5_...
Page 72 PEG_RXN6 PEG_RXN15 +5VSB PEG_TXP7_ +5VSB 7 : PCIE2 PEG_ TXN7_R Signal Name Signal Name PEG_RXP7 +12V PEG_RXN7 +12V +12V CLKREQ# +12V +12V PEG_TXP8_ SLOT_SEL3 PCH_ SMB_CLK_ ECLK_X4_2 MAIN PEG_ PCH_ TXN8_R SMB_DATA_ ECLK_ PEG_RXP8 MAIN X4_2# PEG_RXN8 RESERVED PEG_TXP9_ RESERVED SIO_PME# PEG_ +3VSB...
Page 73 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E PRSENT#_1 CNV_BGI_ RESERVED PCIE_4_ CNV_RGI_ RESERVED TXP21_C PCIE_4_ CNV_BRI_ PETp TXN21_C PCIE_4_ PETn RXP21 PCIE_4_ PERp RXN21 PERn PCIE_4_ TXP22_C PEFCLKp PCIE_4_ PEFCLKn SUSCLK TXN22_C PERST0# PCIE_4_ CLKREQ# RXP22 DISABLE1# PCIE_4_ WAKE#...
Page 74 12 : Top : RJ45 LAN Port (LAN2) Signal Name Middle/Bottom : USB 3.2 Gen2 Ports (USB3_3_4) SPDIF OUT 13 : USB 2.0 Ports SPDIF header, providing SPDIF audio output to HDMI VGA card, allows the Top : USB3_7 system to connect HDMI Digital TV/ Bottom : USB3_8 projector/LCD devices.
Page 75 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E PETP0 PERST# RESERVED PEFCLKn CLKREQ# POE1_ RESERVED CLKP_R PEFCLKp WAKE# POE1_ RESERVED CLKN_R RESERVED PCH_POE1_ RESERVED PCH_POE1_ RESERVED RESERVED +3.3V PCH_POE1_ +3.3V RESERVED +3.3V PCH_POE1_ RESERVED 23 : M.2 Key-M Socket (M2_M2) RESERVED Signal Name Signal Name...
Page 76 24 : MCU_CON1 table for the pin definition. In addition, COM5, 6 port (RS232/422/485) can be adjusted in BIOS setup utility > Advanced Screen > Super IO Configuration. You may refer to our user manual for details. COM5, 6 Ports Pin Definition RS232 RS422 RS485...
Page 77 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 30 : System Panel Header (PANEL1) The front panel design may differ by chassis. A front panel module mainly consists of power switch, reset switch, power LED, hard drive activity LED, speaker and etc.
Page 78 DSR#4 MODE0_2 C_ESPI_IO2 DCD#4 SIO_PSIN# C_ESPI_IO3 CTS#4 RTCRST# COMDIO_ +3VSB SEL0 COMDIO_ SEL1 C_ESPI_ALERT# DELAY_ PLED- PWR_CTRL COMDIO_ Backside PLED+ SEL2 +5VSB 34 : COMDIO_CON1 +5VSB Supported by DSC-COMDIO Card. Signal Name Signal Name USB2_COM_ RTS#1 DIO_EN DTR#1 GPP_F23 TXD1 GPP_F22 RXD1 GPP_F18...
Page 79: Ignition Control
iEPF-9030S-EW4 / iEPF-9030S-EY4 / VGA_PWR6W1 iEPF-9032S-EW4 / iEPF-9032S-EY4 / DC_IN1 iEP-9030E / iEP-9032E M2_E1 2.4.3 Ignition Control PCIE2 How to Disassemble Motherboard USB 3.2 Gen2 Top: Middle: USB3_1 LAN1 Bottom: USB3_2 For more information, refer to 3.1. CMOS Battery USB 3.2 Gen2 Ignition Control Top: Middle: USB3_3...
Page 80 Ignition Control Modes iEP(F)-9030 Series provides 13 modes of different power on/off and hard off delay time adjustable with rotary switch. The default switch position is set to 0 in ATX Mode. The modes are listed as follows: Switch Power On Power Off Hard Off Binary...
Page 81 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E The Policy of Ignition Power Control The process of the ignition power control module is shown in the diagram below. Mode select DC-IN Ignition work (12) Standby Power Power Button (10) (11) Sy em work...
Page 82: Other Boards
2.5 Other Boards 2.5.1 DSC-SATA003-WT Layout and I/O Connectors DSC- SATA00 3-WT Industrial SATA3_4 SATA3_3 LED7 LED0 LED5 LED6 SATA3_2 SATA3_1 LED1 LED2 LED3 LED4 SATA_PWR1 SATA_CON1 SATA_CON2 1 : PRSNT LEDS (LED7, LED3) (Device installed: Blue. No Device: N/A) 2 : ACT LEDS (LED0, LED4) (Idle: On.
Page 83 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E Signal Name SATA_TXP_0 SATA_TXN_0 SATA_RXP_0 SATA_RXN_0 SATA_TXP_1 SATA_TXN_1 SATA_RXP_1 SATA_RXN_1 SATA_SEL1 SATA_SEL2 CFAST_SEL1 10 : SATA_CON2 Signal Name SATA_TXP_2 SATA_TXN_2 SATA_RXP_2 SATA_RXN_2 SATA_TXP_3 SATA_TXN_3 SATA_RXP_3 SATA_RXN_3...
Page 84: Dsc-Pse002-Wt Layout And I/O Connectors
11 : SATA_PWR1 Signal Name 2.5.2 DSC-PSE002-WT Layout and I/O Connectors LAN1 LAN2 CON1 PWRCON1 1 : LAN1 (I226IT with PSE function) 2 : LAN2 (I226IT with PSE function) 3 : CON1 (FPC Connector) 4 : PWRCON1 (Power connector)
Page 85: Dsc-Pse004-Wt Layout And I/O Connectors (Optional)
iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 2.5.3 DSC-PSE004-WT Layout and I/O Connectors (Optional) LAN1 LAN2 LAN3 CON1 PWRCON1 1 : LAN1 (I226IT with PSE function) 2 : LAN2 (I226IT with PSE function) 3 : LAN3 (I226IT) 4 : CON1 (FPC connector) Signal Name LAN_PWR_GOOD3...
Page 86 POE_SEL0 UPE_CLKREQN1 UPE_CLKREQN0 UPE_CLKN1 UPE_CLKP1 UPE_RXN1 UPE_RXP1 UPE_TXN1 UPE_TXP1 UPE_TXN0 UPE_TXP0 UPE_RXN0 UPE_RXP0 UPE_CLKN0 UPE_CLKP0 SMB_DATA SMB_CLK WAKE# BUF_PLT_RST# 5. PWRCON1 (Power connector) Signal Name +12V +12V +3VSB...
Page 87: Dsc-Comdio002-Wt Layout And I/O Connectors
iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 2.5.4 DSC-COMDIO002-WT Layout and I/O Connectors 1 : USB2_7 (USB2.0 Port) 2 : PWRBTN1 (Power button) 3 : CLRCMSBTN1 (Clear CMOS button) 4 : JGPIO_SET1 (Digital Input / Output default value setting) 5 : Top : DIO [9:16] →...
Page 88 7 : COM1_2 (COM port headers, RS232/422/485) RS232 RS422 RS485 RTX- RTX+ DI (SIO GPI) 1. Input Channel: 8 2. Input Voltage: Low: 0.8Vdc max. (0Vdc min.) High: 2Vdc min. (3Vdc max.) 3. Current: 12mA max. per channel DO (SIO GPO) 1.
Page 89: Dsc-Comdio003-Wt Layout And I/O Connectors (Optional)
iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 2.5.5 DSC-COMDIO003-WT Layout and I/O Connectors (Optional) 1 : Top : COM Port (COM1) (RS232/422/485) Bottom : COM Port (COM2_ISO) (ISO RS232/422/485) 2 : Top : COM Port (COM3) (RS232) Bottom : COM Port (COM4) (RS232) 3 : Top : DIO [9:16]→...
Page 90 Digital I/O: Sink and Source DI (Sink/Source): Setting Description Input Channel Low: 3Vdc max. (0Vdc min) Input Voltage High: 10Vdc min. (30Vdc max.) Isolation Protection 3000 V ， DSC-COMDIO003-WT / DSC-COMDIO004SO-WT  DI Sink topology: ， DSC-COMDIO003-WT / DSC-COMDIO004SO-WT SIO_GPI VCOM SIO_GPI ...
Page 91 iEPF-9030S-EW4 / iEPF-9030S-EY4 / SIO_GPI iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E VCOM DO (Sink)(N-MOSFET type) Specification: Setting Description SIO_GPI Output Channel Output Voltage +5Vdc ~ +30 Vdc VCOM Sink Current 350mA max./per channel Isolation Protection 3000 V  DO Sink topology: ，...
Page 92: Dsc-Comdio004So-Wt Layout And I/O Connectors (Optional)
2.5.6 DSC-COMDIO004SO-WT Layout and I/O Connectors (Optional) Top: COM1 Bottom: COM2_ISO Top: COM3 Bottom: COM4 Top: DO [8:1] Bottom: DI [8:1] CLRMOS1 PWRBTN1 USB2_7 1 : Top: COM Port (COM1) (RS232/422/485) Bottom: Isolation 3 in 1 COM Port (COM2) (ISO RS232/422/485) RS232 RS422 RS485...
Page 93 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 3 : Top: DIO [9:16]→DO Bottom: DIO [1:8]→DI GND_ EXT_ Signal DIO9 DIO10 DIO11 DIO12 DIO13 DIO14 DIO15 DIO16 ISO_ Name GND_ Signal DIO1 DIO2 DIO3 DIO4 DIO5 DIO6 DIO7 DIO8 VCOM...
Page 94 DO (Source) (P-MOSFET type) Specification: Setting Description Output Channel Output Voltage +5Vdc ~ +24 Vdc Sink Current 1A max./per channel Isolation Protection 3000 V ， DSC-COMDIO004SO-WT D O(Source)  DO Source topology: +EXT_DCIN +EXT_DCIN SIO_GPO +EXT_DCIN Load +EXT_DOSO1 GND_ISO_DIO...
Page 95: Dsc-Comdio005-Wt Layout And I/O Connectors (Optional)
iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 2.5.7 DSC-COMDIO005-WT Layout and I/O Connectors (Optional) Top: COM1 Bottom: COM2_ISO Top: COM3 Bottom: COM4 Top: DO [8:1] Bottom: DI [8:1] CLRMOS1 PWRBTN1 USB2_7 1 : Top: COM Port (COM1) (RS232/422/485) Bottom: Isolation 3 in 1 COM Port (COM2) (ISO RS232/422/485) RS232 RS422...
Page 96 3 : Top: DIO [9:16]→DO Bottom: DIO [1:8]→DI GND_ Signal EXT_ DIO9 DIO10 DIO11 DIO12 DIO13 DIO14 DIO15 DIO16 ISO_ Name GND_ Signal DIO1 DIO2 DIO3 DIO4 DIO5 DIO6 DIO7 DIO8 VCOM ISO_ Name 4 : Clear CMOS Button (CLRMOS1) 5 : Power Button (PWRBTN1) 6 : USB 2.0 Port (USB2_7) (Upper Port Only) Digital I/O: Sink and Source...
Page 97 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E DO (Source) (P-MOSFET type) Specification: Setting Description Output Channel Output Voltage +5Vdc ~ +24 Vdc Sink Current 1A max./per channel Isolation Protection 3000 V ， DSC-COMDIO004SO-WT D O(Source)  DO Source topology: +EXT_DCIN +EXT_DCIN SIO_GPO...
Page 98: Dsc-Comdio006-Wt Layout And I/O Connectors (Optional)
2.5.8 DSC-COMDIO006-WT Layout and I/O Connectors (Optional) Top: COM1 Bottom: COM2_ISO Top: DO [16:9] Bottom: DI [16:9] Top: DO [8:1] Bottom: DI [8:1] CLRMOS1 PWRBTN1 USB2_7 1 : Top: COM Port (COM1) (RS232/422/485) Bottom: Isolation 3 in 1 COM Port (COM2) (ISO RS232/422/485) RS232 RS422 RS485...
Page 99 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 3 : Top: DIO [9:16]→DO Bottom: DIO [1:8]→DI GND_ EXT_ Signal DIO9 DIO10 DIO11 DIO12 DIO13 DIO14 DIO15 DIO16 ISO_ Name GND_ Signal DIO1 DIO2 DIO3 DIO4 DIO5 DIO6 DIO7 DIO8 VCOM...
Page 100 VCOM DO (Source) (P-MOSFET type) Specification: Setting Description Output Channel VCOM Output Voltage +5Vdc ~ +24 Vdc Sink Current 1A max./per channel Isolation Protection 3000 V ， DSC-COMDIO004SO-WT D O(Source)  DO Source topology: +EXT_DCIN +EXT_DCIN SIO_GPO +EXT_DCIN Load +EXT_DOSO1 GND_ISO_DIO...
Page 101: Dsc-Slot003-Wt Layout And I/O Connectors (Support Pcie Gen4, 9030S/9032S Only)
iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 2.5.9 DSC-SLOT003-WT Layout and I/O Connectors (Support PCIe Gen4, 9030S/9032S Only) PCIEX4_1 PCIEX4_2 PCIEX16 PCIEX8 DSC-SLOT003-WT RoHS Industrial 1 : PCIEX4_1 (PCIe Gen4 x4 slot) 2 : PCIEX4_2 (PCIe Gen4 x4 slot, share with MB Key M) 3 : PCIEX16 (PCIe Gen4 x16 slot, switch with x8) Signal Signal...
Page 102 Signal Signal PEG_RXP3 PEG_RXN3 CFG_X8 RESERVED P-12 P+12 PEG_TXP4_R PEG_TXN4_R PEG_RXP4 PEG_RXN4 PEG_TXP5_R PEG_TXN5_R PEG_RXP5 PEG_RXN5 PEG_TXP6_R PEG_TXN6_R PEG_RXP6 PEG_RXN6 PEG_TXP7_R PEG_TXN7_R PEG_RXP7 PEG_RXN7 X8_CLKREQ# USB2_13_14_EN1 PEG_TXP8_R PEG_TXN8_R PEG_RXP8 PEG_RXN8 PEG_TXP9_R PEG_TXN9_R PEG_RXP9 PEG_RXN9 PEG_TXP10_R PEG_TXN10_R PEG_RXP10 PEG_RXN10 PEG_TXP11_R PEG_TXN11_R PEG_RXP11 PEG_RXN11 PEG_TXP12_R...
Page 103 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E Signal Signal PEG_TXN14_R PEG_RXP14 PEG_RXN14 PEG_TXP15_R PEG_TXN15_R PEG_RXP15 PEG_RXN15 +5VSB +5VSB 4 : PCIEX8 (PCIe Gen4 x8 slot) Signal Signal +12V +12V +12V +12V +12V PCH_ECLK_X4_2 SMB_CLK_MAIN PCH_ECLK_X4_2# SMB_DATA_MAIN RESERVED RESERVED SIO_PME#...
Page 104 Signal Signal PCH_PE_RXN4 PCIE_4_TXP21_C RESERVED PCIE_4_TXN21_C RESERVED PCIE_4_RXP21 PCIE_4_TXP22_C PCIE_4_RXN21 PCIE_4_TXN22_C PCIE_4_RXP22 PCIE_4_TXP23_C PCIE_4_RXN22 PCIE_4_TXN23_C PCIE_4_RXP23 PCIE_4_TXP24_C PCIE_4_RXN23 PCIE_4_TXN24_C X4_PRSENT#_2 PCIE_4_RXP24 PCIE_4_RXN24 X4_PRSENT#_2...
Page 105: Dsc-Slot005-Wt Layout And I/O Connectors (Support Pcie Gen5, 9030S/9032S Only)(Optional)
iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 2.5.10 DSC-SLOT005-WT Layout and I/O Connectors (Support PCIe Gen5, 9030S/9032S Only) (Optional) PCIEX4_1 PCIEX16 PCIEX4_2 PCIEX8 DSC-SLOT005-WT Industrial 1 : PCIEX4_1 (PCIe x4 slot) 2 : PCIEX16 (PCIe x16 slot, switch with x8) 3 : PCIEX4_2 (PCIe x4 slot, share with MB Key M) 4 : PCIEX8 (PCIe x8 slot) 2.5.11 VGA-PWR Layout and I/O Connectors (Optional)
Page 106: Specification
Specification TI LM5176PWPR • Controller/Major IC Intersil ISL8117AFRZ-T • 1 x 4-pin DC-IN Power connector (+12V~36V) • Input Interface/Power 1 x PS_ON# Header • 1 x 8-pin VGA Power connector , support 12V • 1 x 4-pin VGA Power connector, support 12V •...
Page 107 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 3 : Option 2 PS_ON# Header (PCIE_ISOLATION_1) Signal Name PSON# 4 : SATA Power Connector (SATA_PWR2) Signal Name +12V 5 : SATA Power Connector (SATA_PWR1) Signal Name +12V 6 : VGA Power Connector (VGA_PWR1) Signal Name 1, 2, 3 +12V...
Page 108: Vga-Pwr600W Layout And I/O Connectors (Optional)
7 : 4-pin VGA Power Connector (VGA_PWR2) Signal Name 1, 2 3. 4 +12V 8 : 4-pin FAN Power Connector (CHA_FAN1) Signal Name +12V 3, 4, 5 2.5.12 VGA-PWR600W Layout and I/O Connectors (Optional) Industrial DC-INPUT1 VGA-PWR600W RoHS...
Page 109 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E Specification Power controller: TI LM5176PWPR • Controller/Major IC FAN Speed controller: MP1475DJ-LF-Z • 1 x 8-pin DC_IN Power connector (+12V~36V) • Input Interface/Power 1 x PS_ON# Header • 2 x 8-pin VGA Power connector •...
Page 110 4 : FAN Power Connector (CHA_FAN1) Signal Name +12V_FAN 5 : DC-IN Power Connector (DC_INPUT1) Signal Name +36VA (9V~36V)
Page 111: Chapter 3 Hardware Installation And Maintenance
iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E Chapter 3 Hardware Installation and Maintenance This chapter helps you disassemble the system and install components. Before You Begin Before you work with the system, pay close attention to the “Important Safety Instructions” at the beginning of this manual.
Page 112: How To Disassemble The System
3.1 How to Disassemble the System 1. Remove all screws securing the heatsink. 2. Remove the heatsink. 3. Remove the screws securing the small panel. 4. Remove the small panel from the I/O side of the system.
Page 113 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 5. Release the screws and remove the middle panel from the I/O side of the system. 6. Remove the screws securing the big panel. 7. Remove the big panel from the I/O side of the system.
Page 114 8. Remove the screw securing the cover. 9. Push the cover toward the I/O side of the chassis to remove the cover from the locked position. Remove the cover. 10. Remove the four screws from the outside of the chassis.
Page 115 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 11. Remove the screws from the inside of the chassis. 11 11...
Page 116 12. Pull out the motherboard tray from the system. 13. Ensure that the HDD trays or HDD tray covers are removed. Then remove the five screws marked with a triangle. 14. Then remove the HDD case.
Page 117 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E...
Page 118: How To Install The Cpu
3.2 How to Install the CPU 1. Before you insert the 1700-Pin CPU into the socket, please check if the CPU surface is unclean, or if there are any bent pins in the socket. Do not force to insert the CPU into the socket if any of the situations above is found.
Page 119 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 3. Align the triangle marks on both CPU and socket (marked in the below illustration), and install the CPU onto the socket. The CPU can only fit in one way. CPU mislaignment will damge the motherboard. 4.
Page 120 5. Tighten the screws to secure the CPU.
Page 121: How To Install The Hard Disk Drive
iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 3.3 How to Install the Hard Disk Drive Installing a Hard Disk Drive into 2.5" Hard Drive Tray The system supports hot-swappable 2.5” hard drives. Removing 2.5” Hard Drive Trays from the Chassis 1.
Page 122 Installing a 2.5” Hard Drive to the Hard Drive Tray (Default Qty is one piece.) 1. Place a 2.5" HDD into the tray with the printed circuit board side facing down. Carefully align the mounting holes in the hard drive and the tray. 2.
Page 123: How To Install The Sim Card
iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 3.4 How to Install the SIM Card Installing a SIM Card into a SIM Card Slot 1. Remove the screw securing the SIM card slot cover. 2. Remove the SIM card slot cover.
Page 124 3. Insert a SIM card to the SIM car slot. SIM1 (Upper Slot): When inserting the SIM Card to the upper slot, make sure the notch on the SIM card is oriented with the gold contacts face down. SIM2 (Lower Slot): When inserting the SIM Card to the lower slot, make sure the notch on the SIM card is oriented with the gold contacts face up.
Page 125: How To Install The Desk Mount Bracket
iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 3.5 How to Install the Desk Mount Bracket 1. Attach the two desk mount brackets to the iEPF-9030S Series or iEP-9030E Series. Then secure them with four screws. iEPF-9030S Series iEP-9030E Series 2.
Page 126: How To Install The Rubber Foot
3.6 How to Install the Rubber Foot 1. Attach four rubber foots to the iEPF-9030S Series or iEP-9030E Series. Then secure them with four screws. iEPF-9030S Series iEP-9030E Series 2. Place the iEPF-9030S Series or iEP-9030E Series to any horizontal surface. iEPF-9030S Series iEP-9030E Series...
Page 127: How To Install The Memory Module
iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 3.7 How to Install the Memory Module For dual channel configuration, you always need to install identical (the same brand, speed, size and chip-type) DDR5 SO-DIMM pairs. The SO-DIMM only fits in one correct orientation. It will cause permanent damage to the motherboard and the DIMM if you force the DIMM into the slot at incorrect orientation.
Page 128: How To Install The M.2 Ssd With Heatsink And Thermal Pad
3.8 How to Install the M.2 SSD with Heatsink and Thermal Installing the M.2 SSD 1. Locate the M.2 slot on the motherboard. 2. Carefully insert the M.2 SSD into the the slot at a 30-degree angle. 3. Tighten the screw to secure the M.2 SSD to the motherboard.
Page 129 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E Installing the M.2 Pad and Heatsink 1. Remove protective films on both sides of the three thermal pads, and apply the pads onto each of the three chokes. 2. Align the M.2 heatsink to the three screw holes on the right panel, and secure it with three screws (#6-32 x 5 countersunk screws * 3pcs) from the outside of the chassis.
Page 130: How To Install The Vga-Pwr Card
3.9 How to Install the VGA-PWR Card 1. Remove the rear cover. a. Remove the three screws on the chassis by the screwdriver. (Countersunk Head Screw #63-2x5 *3) b. Remove the five screws of the rear cover by the screwdriver. (Countersunk Head Screw #63-2x5 *5)
Page 131 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E c. Remove the rear cover. 2. Assemble the VGA power board. a. Attach the VGA Power Board to the rear cover, and secure it with four screws. VGA Power Board *1 piece; Flat Head Screw #63-2x5 *4 pieces. Note: Screwdriver Torque = 3.0 +/- 0.5 kgf-cm Flat Head Screw VGA Power Board...
Page 132 3. Assemble the VGA power board cables. a. Connect 2-, 4-, and 8-pin cables to the correspinding ports. Pin Cable*1 piece; 4 Pin Cable*1 piece ; 8 Pin Cable*1 piece. 4-pin Cable 8-pin Cable 2-pin Cable 2-pin Cable 8-pin Cable 4-pin Cable 4.
Page 133 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E b. Secure the rear cover with the five screws. Countersunk Head Screws (#6-32x5) Note: Screwdriver Torque = 3.0 +/- 0.5 kgf-cm Countersunk Head Screw #6-32x5 5. Connect the 2-, 4-pin and fan cables to the corresponding ports. 4-pin Cable 2-pin Cable Fan Cable...
Page 134: How To Install The Riser Card
3.10 How to Install the Riser Card There are four PCI Express slots on the board. Before installing an expansion card, please make sure that the power supply is switched off or the power cord is unplugged. Please read the documentation of the expansion card and ensure necessary hardware settings for the card before you start the installation.
Page 135 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E Description PCIe Gen4 x4 slot is used for PCIe x4 lane width cards. PCIe Gen4 x4 slot is used for PCIe x4 lane width cards. PCIe Gen5 x16 slot is used for PCIe x16 lane width graphic cards or x8 lane width cards.
Page 136 4. The VGA Card Assembly. a. Remove the corresponding screws based on the position of the VGA card. b. Remove the covers. c. Insert the VGA card.
Page 137 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E d. Re-secure the screws. 1. In the case of graphic cards exceeding 300W, the system fan must operate at full speed. 2. Dimensions should not exceed 275mm x 138mm x 60mm (L x H x D), which means the total length of the graphic card and power cable should not exceed 275mm.
Page 138: How To Install The Wifi Module (M.2 Key E Socket (2230))
3.11 How to Install the WiFi Module (M.2 Key E Socket (2230)) 1. Locate the WiFi Module slot on the motherboard. 2. Carefully insert the WiFi Module into the slot at a 30-degree angle. 3. Tighten the screw to secure the WiFi Module to the motherboard.
Page 139: How To Install The 4G/5G Module
iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 3.12 How to Install the 4G/5G module (M.2 Key B1 2280/3042/3052; M.2 Key B2 3042/3052) 1. Locate the 4G / 5G module slot on the motherboard. 2. Carefully insert the 4G / 5G module into the slot at a 30-degree angle. 3.
Page 140: How To Install The Wifi/4G/5G Antennas And Cables
3.13 How to Install the WiFi/4G/5G Antennas and Cables 3.13.1 Antennas 1. Prepare the WiFi or 4G/5G antennas. WiFi antennas 4G/5G antennas 2. Connect the WiFi or 4G/5G antennas to the antenna connectors. Then turn the antennas clockwise until they are properly tightened. You may need to adjust the direction of the antennas for a stronger signal.
Page 141: How To Assemble Sma Cables
iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 3.13.2 How to Assemble SMA Cables 1. Assemble the washer and nut into the antenna connector hole of the chassis as shown in the following illustration. When installing the SMA cable, ensure that the flat surface of the cable and the antenna hole are properly aligned.
Page 142 2. Turn the nut clockwise to tighten.
Page 143: How To Assemble Card Holder
iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 3.14 How to Assemble Card Holder 1. Attach the M4*20, the nut and the spring washer in order onto a screw hole of the card holder. 2. Turn back the card holder, and attach the press block to the other side of the screw. 3.
Page 144 4. Choose either the left, the middle or the right of the chassis according to your expansion card to secure the card holder . Left Middle Right 5. Secure the card holder using four #6-32 countersunk head screws.
Page 145 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 6. Tighten the M4*20 screw against the expansion card underneath. 7. Screw on the nut to secure the card holder...
Page 146: Chapter 4 Uefi Setup Utility
Chapter 4 UEFI Setup Utility 4.1 Introduction ASRock Industrial UEFI (Unified Extensible Firmware Interface) is a BIOS utility which offers tweak-friendly options in an advanced viewing interface. The UEFI system works with a USB mouse and offers users a faster and sleeker experience.
Page 147: Uefi Menu Bar
iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 4.1.2 UEFI Menu Bar The top of the screen has a menu bar with the following selections: Main For setting system time/date information Advanced For advanced system configurations H/W Monitor Displays current hardware status Security For security settings...
Page 148: Navigation Keys
4.1.3 Navigation Keys Use < > key or < > key to choose among the selections on the menu bar, and use < > key or < > key to move the cursor up or down to select items, then press <Enter> to get into the sub screen.
Page 149: Main Screen
iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 4.2 Main Screen When you enter the UEFI SETUP UTILITY, the main screen will appear and display the system overview. Because the UEFI software is constantly being updated, the following UEFI setup screens and descriptions are for reference purpose only, and they may not exactly match what you see on your screen.
Page 150: Advanced Screen
4.3 Advanced Screen In this section, you may set the configurations for the following items: CPU Configuration, Chipset Configuration, Intel(R) Time Coordinated Computing, Storage Configuration, Super IO Configuration, AMT Configuration, ACPI Configuration, USB Configuration and Trusted Computing. Setting wrong values in this section may cause the system to malfunction. Instant Flash Instant Flash is a UEFI flash utility embedded in Flash ROM.
Page 151: Cpu Configuration
iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 4.3.1 CPU Configuration Intel Hyper Threading Technology Intel Hyper Threading Technology allows multiple threads to run on each core, so that the overall performace on threaded software is improved. Active Processor P-Cores Select the number of cores to enable in each processor package.
Page 152 Package C State Support Allows you to enable CPU, PCIe, Memory, Graphics C State Support for power saving. Configuration options: [Auto] [Enabled] [Disabled] CFG Lock The option allows you to enable or disable the CFG Lock. Configuration options: [Enabled] [Disabled] Intel Virtualization Technology Intel Virtualization Technology allows a platform to run multiple operating systems and applications in independent partitions, so that one computer system can function as...
Page 153: Chipset Configuration
iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 4.3.2 Chipset Configuration Primary Graphics Adapter Select a primary VGA. Above 4G Decoding Enable or disable 64bit capable Devices to be decoded in Above 4G Address Space (only if the system supports 64 bit PCI decoding).
Page 154 Share Memory Configure the size of memory that is allocated to the integrated graphics processor when the system boots up. IGPU Multi-Monitor This allows you to enable or disable IGPU Multi-Monitor. The default value is [Disabled]. Render Standby Power down the render unit when the GPU is idle for lower power consumption. Maximum Memory Frequency The maximum operating frequency of the memory controller, adjustable within the BIOS settings.
Page 155: Intel(R) Time Coordinated Computing
iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 4.3.3 Intel(R) Time Coordinated Computing #AC Split Lock Enable or Disable Alignment Check Exception (#AC). When enabled, this will assert an #AC when any atomic operation has an operand that crisses two cache lines. #GP Fault UC Lock Enable or Disable GP Fault Exception (GP#).
Page 156 IO Fabric Low Latency Enable or Disable IO Fabric Low Latency. This will turn off some power management in the PCH IO fabrics. This option provides the most aggressive IO Fabric performance set- ting. S3 state is NOT supported. GT CLOS Enable or Disable Graphics Technology(GT) Class of Service.
Page 157: Storage Configuration
iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 4.3.4 Storage Configuration VMD Configuration This item allows you to enable or disable the Intel VMD support function. SATA Controller(s) The option allows you to enable or disable the SATA controllers. Configuration options: [Enabled] [Disabled] SATA Mode Selection AHCI supports new features that improve performance.
Page 158 Hard Disk S.M.A.R.T S.M.A.R.T stands for Self-Monitoring, Analysis, and Reporting Technology. It is a monitoring system for computer hard disk drives to detect and report on various indicators of reliability. Configuration options: [Enabled] [Disabled]...
Page 159: Super Io Configuration
iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 4.3.5 Super IO Configuration...
Page 160 COM1 Use this to set parameters of COM1. Type Select Use this to select COM1 port type: [RS232], [RS422] or [RS485]. COM2 Use this to set parameters of COM2. Type Select Use this to select COM2 port type: [RS232], [RS422] or [RS485]. COM3 Use this to set parameters of COM3.
Page 161 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E DI07 Type Select Use this to set DIO Type: [Input]. DI08 Type Select Use this to set DIO Type: [Input]. DI011 Type Select Use this to set DIO Type: [Output Low] or [Output High]. DI012 Type Select Use this to set DIO Type: [Output Low] or [Output High].
Page 162: Acpi Configuration
4.3.6 ACPI Configuration Suspend to RAM Suspend to RAM allows you to select [Disabled] for ACPI suspend type S1. It is recom- mended to select [Auto] for ACPI S3 power saving. Configuration options: [Auto] [Disabled] PCIE Devices Power On Use this item to enable or disable PCIE devices to turn on the system from the power- soft-off mode.
Page 163: Usb Configuration
iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 4.3.7 USB Configuration USB Power Control Use this option to control USB power. M.2 Key_B1 USB Function Use this option to enable or disable M.2 Key_B1 USB Function. M.2 Key_B2 USB Function Use this option to enable or disable M.2 Key_B2 USB Function.
Page 164: Usb Provisioning Of Amt
4.3.8 USB Provisioning of AMT USB Provisioning of AMT Enable/Disable of AMT USB Provisioning. MAC Pass Through Enable/Disable MAC Pass Through function. Dynamic Lan Switch Allow switching AMT support from Integrated LAN to Discrete LAN. Activate Remote Assistance Process Trigger CIRA boot. Unconfigure ME Unconfigure ME with resetting MEBx password to default on next boot.
Page 165 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E Remote Platform Erase Configuration Remote Platform Erase configuration menu. MEBx This Formset contains forms for configuring MEBx.
Page 166: Trusted Computing
4.3.9 Trusted Computing Security Device Support Security Device Support allows you to enable or disable BIOS support for security device. O.S. will not show Security Device. TCG EFI protocol and INT1A interface will not be available. Configuration options: [Enabled] [Disabled] Active PCR banks This item displays active PCR Banks.
Page 167 iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E Platform Hierarchy This item allows you to enable or disable Platform Hierarchy. Configuration options: [Enabled] [Disabled] Storage Hierarchy This item allows you to enable or disable Storage Hierarchy. Configuration options: [Enabled] [Disabled] Endorsement Hierarchy This item allows you to enable or disable Endorsement Hierarchy.
Page 168: Hardware Health Event Monitoring Screen
4.4 Hardware Health Event Monitoring Screen In this section, it allows you to monitor the status of the hardware on your system, including the parameters of the CPU temperature, motherboard temperature, CPU fan speed, chassis fan speed, and the critical voltage. CHA_FAN1 Setting Select a fan mode for Chassis Fan 1, or choose Customize to set 5 CPU temperatures and assign a respective fan speed for each temperature.
Page 169: Security Screen
iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 4.5 Security Screen Supervisor Password Set or change the password for the administrator account. Only the administrator has au- thority to change the settings in the UEFI Setup Utility. Leave it blank and press enter to remove the password.
Page 170: Boot Screen
4.6 Boot Screen In this section, it will display the available devices on your system for you to configure the boot settings and the boot priority. Boot From Onboard LAN The item allows the system to be waked up by the onboard LAN. Configuration options: [Enabled] [Disabled] Setup Prompt Timeout The item allows you to configure the number of seconds to wait for the UEFI setup utility.
Page 171: Exit Screen
iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E 4.7 Exit Screen Save Changes and Exit When you select this option, the following message “Save configuration changes and exit setup?” will pop out. Select [Yes] to save the changes and exit the UEFI SETUP UTILITY. Discard Changes and Exit When you select this option, the following message “Discard changes and exit setup?”...
Page 172: Chapter 5 Appendix
Chapter 5 Appendix Appendix 1 Power Consumption The power consumption (W)= voltage (V) x current (A) The system’s full loading means it is populated with such as DRAM, M.2 Module, and so on. The iEPF-9030S Series also includes riser cards. The following information is for reference only.
Page 173: Appendix 2 Link To The Api Library
iEPF-9030S-EW4 / iEPF-9030S-EY4 / iEPF-9032S-EW4 / iEPF-9032S-EY4 / iEP-9030E / iEP-9032E Appendix 2 Link to the API Library If you need the link to the API library, feel free to contact us at IPC_TSD@asrockind.com Appendix 3 How to Install Power Supply or Power Adapter The V+ and V- pins provide DC power input and the chassis ground pin allows connection of the chassis to ground for better EMC compatibility.
Page 174 DC Power Side:  V- V- V- V- 3.2 330W Power Adapter (FSP330-AAAN3) V- V- V- V-...

This manual is also suitable for:

Iepf-9030 series Iepf-9030s-ew4 Iepf-9030s-ey4 Iepf-9032s-ew4 Iepf9032s-ey4 Iep-9030e ... Show all

ASROCK iEP-9030 Series User Manual

Quick Links

Need help?

Questions and answers

Related Manuals for ASROCK iEP-9030 Series

Summary of Contents for ASROCK iEP-9030 Series

This manual is also suitable for:
