ReliOn insight 48V030-GC2 User And Installation Manual
Hide thumbs
Also See for insight 48V030-GC2:
- Quick installation manual (3 pages) ,
- Installation instructions (3 pages)
Table of Contents
Advertisement
Quick Links
Advertisement
Table of Contents
Related Manuals for ReliOn insight 48V030-GC2
Summary of Contents for ReliOn insight 48V030-GC2
-
Page 2: Table Of Contents
BASE MODELS LOW TEMPERATURE (LT) MODELS 48V030-GC2 48V030-GC2-LT 24V060-GC2 24V060-GC2-LT 12V120-GC2 12V120-GC2-LT Scan the QR code to access the latest version of this manual or accessory manuals with instructions on how to wire them to the RELiON InSight batteries. RELIONBATTERY.COM... -
Page 3: Safety Instructions
CAUTION! refers to special information, commands and prohibitions in order to prevent damage. WARNING! refers to possible injury to the user or installer or significant material damage to the RELiON InSight batteries if the installer / user does not (carefully) follow the stated procedures. -
Page 4: Safety Guidelines
Furthermore, the manufacturer must agree to indemnify and not hold NAVICO GROUP responsible for any claims arising from the use of the RELiON parts in the life support equipment. -
Page 5: General Information
2.2. Warranty The RELiON product warranty covers the RELiON InSight batteries as per the terms in the warranty conditions, on the condition that the product is installed and used according to the instructions in this manual. Installation or use that does not comply with these instructions may result in under performance, damage or failure of the product and may void this warranty. -
Page 6: Disclaimer
2.4. Disclaimer Our products are subject to continual development and improvement. Therefore, additions or modifications to the products may cause changes to the technical data and functional specifications. No rights can be derived from this document. Please consult our online Terms & Conditions of Sale. 2.5. -
Page 7: Product Description
. PRODUCT DESCRIPTION 3.1. Main parts Figure 1 Overview of the RELiON InSight batteries 1 a. M8 negative terminals b. M8 positive terminals (insert and stud connections have the same function) 2. CANbus IN connector 3. CANbus OUT connector 4. Power Button 5. -
Page 8: Leds
3.2. LEDs Two tri-colored LEDs on the cover are used to show the battery status and the SOC. LED 1 LED 2 Figure 2: status LEDs • Battery Status MODE Flashing green (every 5 sec.) Charging Flashing green (every 2 sec.) Undervoltage protection Flashing red (every 5 sec.) Over discharge current protection... -
Page 9: Power Button
Power Button. 3.5. Battery Management System (BMS) RELiON InSight batteries have a built-in Battery Management System (BMS). The BMS protects the battery by automatically disconnecting when thresholds are met. See chapter “SPECIFICATIONS” for the protection thresholds, and chapter TROUBLESHOOTING for details. -
Page 10: Charging Guidelines
• Battery LED indicators: The proper LED sequence be displayed: LED1 – O , LED2 – flashing green (every 2 seconds). • RELiON Battery Display Indicator (BDI): Check the accessory gauge to see that charge current is flowing and the SOC is increasing. -
Page 11: Installation
- Keep the RELiON InSight batteries away from heat sources. See specifications for allowed operating temperatures. - The RELiON InSight batteries can be installed in upright position, or on the long side of the case with the plus side up. Upright mounting is recommended. -
Page 12: Installation Procedure For A Single Unit
For optimal use, parallel connected InSight batteries can communicate with each other via CANbus cables. For details on how to interface to the CANbus and interpret the messages, consult the RELiON CANbus Specification document. For details on how to connect RELiON InSight batteries in parallel, consult the RELiON Building a Battery Bank document. -
Page 13: Storage And Care
. STORAGE AND CARE If necessary, use a soft, clean cloth to clean the RELiON InSight batteries. Never use any liquids or acids. The battery should be stored in a dry and well-ventilated environment. The rate of self-discharge is less than 3% per month. -
Page 14: Troubleshooting
. TROUBLESHOOTING If you cannot solve a problem using the fault-finding table, contact your RELiON dealer. Make sure you have the serial number at hand. FAILURE LED POSSIBLE CAUSE WHAT TO DO Battery is The battery switched o Switch it on: press and hold the Power Button for 6 automatically after 72 seconds. -
Page 15: Specifications
Overvoltage Protection (58.4V) (29.2V) (14.6V) Overvoltage Reconnect 3.4V/cell (54.4V) 3.4V/cell (27.2V) 3.4V/cell (13.6V) Temperature Compensation Required None None None Visit the required product page on the RELiON website and go to Specifications for charge voltage characteristics at various rates. RELIONBATTERY.COM... -
Page 16: Discharging Specifications
If this condition is met, contact Technical Support. See the back of the manual for contact information. Visit the required product page on the RELiON website and go to Specifications for discharge voltage characteristics at various temperatures or rates. -
Page 17: Mechanical Specifications
Ingress Protection Marking IP67 Figure 3 Dimensions shown in mm [in] RELION AND NAVICO GROUP TECHNICAL SUPPORT If you have any technical questions, please contact at USA and AMERICAs +1 803-547-7288 • TOLL FREE: (855) 931-2466 | N85W12545 Westbrook Crossing - Menomonee Falls,...
