- Page 1 User Manual Robot Vacuum & Mop + Smart Auto-Empty Dock *Images may differ from actual products. ©2024 TP-Link 7106511290 REV1.0.1...
-
Page 3: Table Of Contents
Contents Safety Information Clean the Filter Clean the Main Brush Package Contents Clean the Side Brush Overview Clean the Caster Wheel Robot Vacuum Clean Main Wheels Auto-Empty Dock Clean the LiDAR and Sensors Setup and Use Clean the Charging Contacts Position the Dock Replace the Bag Remove Protective Strips... - Page 4 IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE WARNING – To reduce the risk of fire, electric shock, or injury: • Do not leave appliance when plugged in. Unplug from outlet when not in use and before servicing. •...
- Page 5 • Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid ejected from the battery may cause irritation or burns. • When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails, screws or other small metal objects, that can make a connection from one terminal to another.
-
Page 6: Safety Information I
For Robot Vacuum: TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of directives 2014/53/EU, 2009/125/EC, 2011 /65/EU and (EU) 2015/863. The original EU declaration of conformity may be found at https://www.tapo.com/en/support/ce/ TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of the Radio Equipment Regulations 2017. -
Page 7: Package Contents
Package Contents Side Brush ×1 HEPA Filter ×1 Robot Vacuum *One side brush and one HEPA Filter installed on the robot vacuum Dust Bag ×1 Cleaning Brush ×1 Auto-Empty Dock *One dust bag and one cleaning brush placed inside the dock User Manual Mopping Attachment ×1 Power Cord ×1... -
Page 8: Overview
Overview Power/Clean • Press and hold for 3 seconds: Turn on/off the robot vacuum. Robot Vacuum • Press once: Start/pause cleaning. Dock • Return to the dock to charge. • Empty the dustbin when docked. Spot Cleaning/Child Lock • Press once: Start spot cleaning. •... - Page 9 Buttons & LEDs LiDAR Recharge Sensor Cover Recharge Sensor Filter Latch Dustbin Latch Charging Bumper Contacts Water Tank Latch Rubber Plug Dustbin + Water Tank Anti-Drop Sensors Caster Wheel Side Brush Add Water Open Dustbin Battery Do NOT add any cleaning agents. Compartment Wipe the water tank dry after adding water.
-
Page 10: Auto-Empty Dock
Overview Auto-Empty Dock Top Cover Open to install/take out the dust bag. Close the cover each time you open it, especially before auto-emptying. Dust Bag Compartment Dust Bag Handle Charging Contacts Dust Bag Dust Collection Port The dust in the robot vacuum will be collected into the dust bag through the port. -
Page 11: Setup And Use
Position the Dock Important Tips 1. Position the dock on a hard, level surface against a wall, ensuring 1.5m (4.9ft) of clear space in front and 0.5m (1.6ft) to the left and right. 2. Connect the power cord to the dock and power source. -
Page 12: Remove Protective Strips
Remove Protective Strips Charge Robot Vacuum Remove the protective strips on both sides of the Place the robot vacuum on the charging dock front bumper. or tap to send it back to the dock to charge. It will return to the dock at the end of a cleaning job and whenever it needs to recharge. -
Page 13: Download Tapo App And Set Up
Download the Tapo App and Connect to Wi-Fi 1. Download the Tapo app from the App In the Tapo app, you can enjoy the following Store or Google Play, then log in. features. • Smart Maps Start quick mapping and create smart maps of your home to tell your robot vacuum where to clean. -
Page 14: Cleaning
Cleaning The robot vacuum will automatically explore and clean your home in neat rows. It will return to the charging station at the end of a cleaning job and whenever it needs to recharge. Press Once Press Once Start/pause cleaning. Start spot cleaning. -
Page 15: Mopping
Mopping 1. Take out the dustbin • Vacuum floors before starting the first mopping cycle. • To prevent wetting the carpet, add a block zone, virtual wall, or carpet area and water tank. on the Tapo app. • The ability to cross obstacles is reduced when mopping. •... -
Page 16: Care And Maintenance
Care and Maintenance To maintain optimal performance, maintain the robot vacuum according to the following guidelines. Part Maintenance Frequency Replacement Frequency* Dustbin Clean/wash as needed 3-6 months Once a week Filter 6-12 months Main Brush Every 2 weeks Main Brush Cover 6-12 months Every 2 weeks Side Brush... -
Page 17: Empty The Dustbin
Empty the Dustbin Clean the Filter Option 1: Auto-Empty 1. Remove the dustbin and open the lid. It automatically empties the dustbin after cleaning. You can also press on the robot vacuum when docked or tap the Empty button in the Tapo app to suck up dust and debris in the dustbin to the dust bag. -
Page 18: Clean The Main Brush
Clean the Main Brush Clean the Side Brush 1. Turn the robot vacuum 1. Use a screwdriver to unscrew the side brush clockwise, over, then unlatch and remove debris, and wipe with a damp cloth if necessary. remove the main brush 2. -
Page 19: Clean The Caster Wheel
Clean the Caster Wheel Clean the Main Wheels 1. Pull firmly to remove the caster wheel and remove hair or dirt. Wipe the main wheels with a clean, dry cloth. 2. Reinstall the caster wheel and press it firmly into place. Main Wheels... -
Page 20: Clean The Lidar And Sensors
Clean the LiDAR and Sensors Clean the Charging Contacts Wipe the LiDAR and sensors with a clean, dry cloth. Wipe the charging contacts with a clean, dry cloth. Using a wet cloth may cause damage. Using a wet cloth may cause damage. Recharge Sensor LiDAR... -
Page 21: Replace The Bag
Replace the Bag Clean Up the Dust Channel 1. Open the top cover and pull up If the dust channel is blocked, use a screwdriver to remove the handle of the dust bag to its dust cover at the bottom and clear any foreign objects. remove. -
Page 22: Troubleshooting
Troubleshooting Scan for more Issue Solution 1. Check if the robot vacuum is turned on. If not, press and hold for 3 seconds to turn it on. Setup failure 2. The battery level is low. Please place the robot vacuum on the dock to charge, and the robot vacuum will turn on automatically when it is ready. - Page 23 5 seconds to force shutdown, then press and hold for 3 seconds to turn it on and check. If the corresponding issues cannot be solved by referring to the above methods, please contact our Technical Support at https://www.tp-link.com/support/contact-technical-support/. Scan for Support...
-
Page 24: Frequently Asked Questions
Tapo app. If the corresponding issues cannot be solved by referring to the above methods, please contact our Technical Support at https://www.tp-link.com/support/contact-technical-support/. Scan for Support... -
Page 25: Voice Prompts For Issues
Please check whether there are foreign objects in the LiDAR sensor, and restart the robot vacuum after cleaning. to the manual or app. If the corresponding issues cannot be solved by referring to the above methods, please contact our Technical Support at https://www.tp-link.com/support/contact-technical-support/. Scan for Support... -
Page 26: Energy Saving Mode
Energy Saving Mode Energy Saving Mode When the robot vacuum is docked, press and hold the Power button and the Dock button for more than 15 seconds until the LED turns off. It will then enter the Energy Saving mode. In this mode, only the charging feature will be active. -
Page 28: Need Some Help
Need some help? Visit www.tapo.com/support/ for technical support, user guides, FAQs, warranty & more...
