Beghelli CURVA 2 Installation Instructions

Read & Follow All Safety Instructions
When using electrical equipment, basic safety precautions should always be followed including:
1. Before starting the installation, disconnect the power by turning off the circuit breaker or by removing the
appropriate fuse at the fuse box. Using the light switch to turn off the power is not sufficient to prevent electrical
shock.
2. Do not use outdoors
3. Do not mount near gas or electric heaters
4. Use caution when servicing batteries. Battery acid can cause burns to skin and eyes. if acid is spilled on skin or
eyes, flush acid with fresh water and contact a physician immediately
5. Equipment should be mounted in locations and at heights where it will not be subjected to tampering by
unauthorized personnel
6. The use of accessory equipment not recommended by Beghelli Inc., may cause an unsafe condition, and will void
the unit's warranty
7. Do not use this equipment for other than its intended purpose
8. Servicing of this equipment should be performed by a qualified service personnel
9. Allow battery to charge for 24 hours before first use
SAVE THESE INSTRUCTIONS
ELECTRICAL CONNECTIONS
• Make the proper connections
with the supply wire
• If using 120VAC, connect the
black and white wires to the
building utility
• If using 277VAC, connect the
orange and white wires to the
building utility
• Cap off unused wires - In all
cases, use standard wir4e nuts
to connect to wires
INSTALLATION INSTRUCTIONS
IMPORTANT SAFEGUARDS
Beghelli U.S.A., 3810 Executive Way, Miramar, Florida, Tel: (954) 442-6600
DETERMINE DIRECTION
• If indicator is
needed, keep
indicator and
remove instruction
film
• If indicator is not
needed, remove
both indictor and
instruction film
UNIVERSAL COLOR
• The product's default
setting is red
• Slide the knob of the
slider switch to the
opposite side to change
the color to green
Page 2 of 2
CURVA 2
CRV2
Slider Switch
04/29/24
