TURNTABLE
PLX-500-K
PLX-500-W
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model
Type
PLX-500-K, -W
LPWSYXEG
PLX-500-K, -W
FWUXEGCB
THIS SERVICE MANUAL SHOULD BE USED TOGETHER WITH THE FOLLOWING MANUAL(S).
Model
PLX-500-K, -W
6F, Yokohama i-Mark Place, 4-4-5 Minatomirai, Nishi-ku, Yokohama, Kanagawa 220-0012 JAPAN
© 2016 Pioneer DJ Corporation
Power Requirement
AC 110 V to 120 V or 220 V to 240 V
AC 110 V to 120 V or 220 V to 240 V
Order No.
RRV4665
SCHEMATIC DIAGRAM, PCB CONNECTION DIAGRAM, PCB PARTS LIST
PLX-500-K
Remarks
ORDER NO.
RRV4664
Remarks
K-ZZZ SEPT.
2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PLX-500-K and is the answer not in the manual?

Questions and answers

Summary of Contents for PIONEER DJ PLX-500-K

  • Page 1 THIS SERVICE MANUAL SHOULD BE USED TOGETHER WITH THE FOLLOWING MANUAL(S). Model Order No. Remarks PLX-500-K, -W RRV4665 SCHEMATIC DIAGRAM, PCB CONNECTION DIAGRAM, PCB PARTS LIST 6F, Yokohama i-Mark Place, 4-4-5 Minatomirai, Nishi-ku, Yokohama, Kanagawa 220-0012 JAPAN © 2016 Pioneer DJ Corporation K-ZZZ SEPT. 2016...
  • Page 2: Safety Information

    Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty. If you are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so and refer the repair to a qualified service technician. PLX-500-K...
  • Page 3: Table Of Contents

    Be sure to use lead-free solder and a soldering iron that can meet specifications for use with lead-free solders for repairs accompanied by reworking of soldering. Do NOT use a soldering iron whose tip temperature cannot be controlled. 1.2 NOTES ON SERVICING For final-check playback after repair, a commercially available record is required. The details, see "3.2 JIGS LIST". PLX-500-K...
  • Page 4: Specifications

    (Stereo pin plug (female) to stereo mini plug (male)) LINE..................150 mV/1 kHz (408-PL50-068) — The specifications and design of this product are subject to change • Warranty* without notice. (LPWSYXEG: 501-PLX-2710) *The included warranty is for the European region. • Operating instructions (LPWSYXEG: DRH1378) (FWUXEGCB: DRH1379) PLX-500-K...
  • Page 5: Basic Items For Service

    USB cable GGP1193 For checking the audio output. Lubricants and Glues List Name Part No. Remarks Adhesive GYL1007 Refer to "7. DISASSEMBLY". Grease GYA1004 Refer to "9.2 EXTERIOR SECTION". PLX-500-K...
  • Page 6: Pcb Locations

    1..33/45 RPM PCB ASSY 704-PLX500-B520 1..AC FILTER & PLAY PCB ASSY 704-PLX500-B523 2..AC FILTER PCB ASSY 704-PLX500-B521 2..PLAY PCB ASSY 704-PLX500-B522 1..AC SOCKET PCB ASSY 704-PLX500-B524 1..D.D. MOTOR PACKING ASSY 705-PLX500-1652 2..D.D. MOTOR ASSY 704-PLX500-B525 1..STROBESCOPE PCB ASSY 704-PLX500-B526 PLX-500-K...
  • Page 7: Block Diagram

    4. BLOCK DIAGRAM AC FILTER PCB ASSY (704-PLX500-B521) AC SOCKET PCB ASSY (704-PLX500-B524) POWER SELECT SW201 STROBOSCOPE PCB ASSY (704-PLX500-B526) CN201 PLAY PCB ASSY TRANS (704-PLX500-B522) CN602 CN101 JK601 D.D. MOTOR ASSY CN303 W102 (704-PLX500-B525) USB & LI/PH PCB ASSY CN601 W301 SW601...
  • Page 8: Audio System Block Diagram

    TRANSFORMER AC SOCKET AC FILTER PCB ASSY PCB ASSY AC IN FILTER FL01 CN101 3.3V IC104 IC105 CN901 NJM317 NJM78M05 IC901 IC902 IC903 NJM78M08 LP38690-5V LD1117AL-3.3V CN601 W301 3.3V IC602 CN303 W102 LD1117 MOTOR USB & LI/PH DRIVE COIL PCB ASSY IC102 LEVEL SHIFTER BA6868FM...
  • Page 9: Diagnosis

    Does the 33/45 RPM button No The LED is in failure. Replace the LED light or go dark when LED (D203, D204) or 33/45 RPM the corresponding button PCB Assy. is pressed? The motor may be in failure. Replace the D.D. MOTOR Assy. PLX-500-K...
  • Page 10 The internal wiring is disconnected. Replace the Tone Arm Assy. Is CN601 on the USB & LI/PH PCB Assy Securely connect them. securely connected? The circuit is abnormal. Replace the USB & LI/PH PCB Assy then the MAIN PCB Assy, in that order. PLX-500-K...
  • Page 11 Waveforms PHONO output during playback at 1 kHz, 0 dB. CH1: L ch OUTPUT (CN602 pin3) V: 10 mV/div. H: 1 mS/div. CH2: R ch OUTPUT (CN602 pin1) V: 10 mV/div. H: 1 mS/div. PLX-500-K...
  • Page 12: Audio Output Check Using Rekordbox

    Connect this unit to your computer via a cable. 2 Turn on the computer’ s power. Connect the power cord. 4 Switch the [POWER] switch on this unit’ s top panel to the [ON] side to turn this unit’ s power on. PLX-500-K...
  • Page 13: Service Mode

    2 Change the POWER switch on the top panel of this unit to [OFF] side, and turn off the power of this unit. 3 Unplug the USB cable from the computer. 6. SERVICE MODE There is no information to be shown in this chapter. PLX-500-K...
  • Page 14: Disassembly

    As the dust cover is not so strong, be careful not to apply a heavy load. Put a 4 cushion on the contact part of 4 corners of the Dust cover to prevent you from injuring Top panel. SPEED PUSH button Dust cover Cushion PLX-500-K...
  • Page 15 (The burr of the outer periphery) that attached to the bottom case. • Bottom view USB & LI/PH PCB ASSY AC SOCKET PCB ASSY AC FILTER PCB ASSY STROBOSCOPE PCB ASSY PLAY PCB ASSY 33/45 RPM SEARCHLIGHT ASSY PCB ASSY MAIN PCB ASSY D.D. MOTOR ASSY PLX-500-K...
  • Page 16 (3) Disconnect the connectors (CN301, CN302, CN303 and CN901). (4) Remove the 4 screws (602-DJ5500-452), and then remove the MAIN Assy. Note: When the removal of the adhesive, apply the adhesive at the time of assembly. (GYL1007) CN303 CN302 CN301 cable (red) PLX-500-K...
  • Page 17 PCB ASSY (5) Disconnect the 2 cables (black) of the AC FILTER PCB Assy. (6) Remove the 4 screws (602-DJ5500-452), and then remove the AC FILTER PCB Assy. CN201 PLAY PCB ASSY 3 x 7 33/45 RPM PCB ASSY PLX-500-K...
  • Page 18 (5) Remove the 4 screws (602-DJ5500-452). (6) Remove the screw (602-ISOF2005-686B). 5 x 4 (7) Disconnect the connector (CN602), and then CN602 remove the USB & LI/PH PCB Assy. USB & LI/PH PCB ASSY Side A PLX-500-K...
  • Page 19: Each Setting And Adjustment

    Power Transformer (5) Remove the 2 screws (602-M400-055), and then remove the TRANSFORMER LEAF SPRING. Remove the POWER TRANSFORMER. 5 x 2 TRANSFORMER LEAF SPRING 8. EACH SETTING AND ADJUSTMENT There is no information to be shown in this chapter. PLX-500-K...
  • Page 20: Exploded Views And Parts List

    For the applying amount of lubricants or glue, follow the instructions in this manual. (In the case of no amount instructions, apply as you think it appropriate.) 9.1 PACKING SECTION MODEL NAME LABEL CAUTION LABEL APPENDAGE LABEL Refer to "9.2 EXTERIOR SECTION". BAR CODE BAR CODE PLX-500-K...
  • Page 21 24 POLYBAG FOR TURNTABLE 505-LP5-001 11 DUST COVER & HINGE ASS'Y See Contrast table (2) 12 SLIPMAT See Contrast table (2) (2) CONTRAST TABLE PLX-500-K/LPWSYXEG, PLX-500-W/LPWSYXEG, PLX-500-K/FWUXEGCB and PLX-500-W/FWUXEGCB are constructed the same except for the following: Mark Symbol and Description PLX-500-K/LPWSYXEG PLX-500-W/LPWSYXEG...
  • Page 22: Exterior Section

    9.2 EXTERIOR SECTION DUST COVER & HINGE ASSY (Accessory) SLIPMAT (Accessory) ALUMINIUM PLATTER SCREW (Accessory) (Accessory) Grease (GYA1004) COUNTER WEIGHT ADJUSTOR ASSY (Accessory) HEADSHEEL & CARTRIDGE ASSY (Accessory) PLX-500-K...
  • Page 23 87 PICK-UP CRAMPER 100-PROTT2-1632 88 CARTRIDGE 402-PLX500-119 41 FIXED AXES 200-DJ1900-159A (AT3600LX, CN-6531) 42 SPOTLIGHT COVER See Contrast table (2) 89 NUT (M2.6 * P0.45 * T1.8) 601-M26P045-031 43 BOTTOM PLATE 300-DJ3000-575B 44 MOTOR FIXED PLATE 300-PLX500-687B 45 GROUND PLATE 300-DJFA-1814 PLX-500-K...
  • Page 24 93 TONE ARM PACKING ASS'Y 705-PLX500-1653 94 STYLUS PACKING ASS'Y 705-FU704-1336 95 SCREW 602-SA12-380-HA (2) CONTRAST TABLE PLX-500-K/LPWSYXEG, PLX-500-W/LPWSYXEG, PLX-500-K/FWUXEGCB and PLX-500-W/FWUXEGCB are constructed the same except for the following: Mark Symbol and Description PLX-500-K/LPWSYXEG PLX-500-W/LPWSYXEG BASE ASS'Y K 701-PLX500-5669...

This manual is also suitable for:
