- Page 1 STEAM GENERATOR HYDROVAP SEMI-AUTOMATIC MAINTENANCE AND INSTRUCTION MANUAL...
- Page 2 1.0 DESCRIPTION The HYDROVAP steam cleaner has been designed for professional use in Dental Laboratories TO fulfill different requirements. It allows to degrease the instruments, to clean and neutralize metal frameworks, to eliminate film residues such as dust particles, wax, polishing residues, fatty layers, insulating agents, etc. Quite often, it is also successfully used in Dental Cabinets to accomplish specific cleaning and sanitizing operation and to remove impurities.
-
Page 3: Safety Precautions
2.0 SAFETY PRECAUTIONS ATTENTION: when using electrical appliances, in order to prevent electrocutions, wounding and risks of fire, the following safety precautions must be strictly followed. 1. Do not use the unit improperly and for purposes differing from the ones described in the present manual 2. -
Page 4: Installation
3.0 INSTALLATION Please take care to unpack the unit and remove it from inside the carton, dispose of any packaging material and keep the special accessory set. Find a suitable position in your Laboratory, on a safe and stable work surface, preferably near the sink to collect the steam residues. - Page 5 5.0 INSTRUCTIONS FOR THE REGULAR MAINTENANCE Any maintenance operation has to be carried out when the unit is cold, in idle mode and unplugged from power sources. Cleaning For external cleaning, wipe any moist residue from the unit case and clean with detergents free from chemical abrasive or corrosive agents.
-
Page 6: Technical Features
13.5 / 15.0 8.0 TECHNICAL REFERENCE REGULATIONS AND TEST PROCEDURES Hydrovap is mass-manufactured by DENTALFARM in compliance with technical and safety rules in force, as provided for by the 2006/42/EEC Community Directive on Machinery. Careful inspection and full routine testing are carried out singularly on each machine, which is furtherly... -
Page 7: Wiring Diagram
9.0 DEMOLITION AND WASTE DISPOSAL According to International regulations, this unit has been classified as AEE (electric and electronic device, whose correct operation depends on electric currents and electromagnetic fields) and as a consequence, at the end of its lifetime, it cannot be treated as normal waste material but it must be disposed separately, complying with the Directive 2002/96/EEC. -
Page 8: Hydraulic Circuit
11.0 HYDRAULIC CIRCUIT REF. DESCRIPTION Boiler Filling cap with safety valve Pressure switch Pressure gauge Solenoid valve for handpiece steam jet Handpiece Level control kit... -
Page 9: Exploded View And Spare-Part List
12.0 EXPLODED VIEW AND SPARE-PART LIST CODE DESCRIPTION 2103017 JOINT ON CASE 2103016 FILLING CAP WITH SAFETY VALVE NEA111 FAIR-LEAD D.=15.5 2103052 HANDPIECE SUPPORT 2103007 ENAMELED UPPER HOUSING 2103022 PRESSURE SWITCH 2103009 BOILER INSULATION 2103011 LEVEL CONTROL KIT 2103012T CLOSING PLATE 2103013 STEAM NOZZLE 2103043... - Page 11 DENTALFARM s.r.l. Via Susa, 9/a - 10138 TORINO – ITALY SERVIZIO TECNICO COMMERCIALE (+39) 011/4346588 SERVIZIO ASSISTENZA TECNICA 011/4346632 E-mail: info@dentalfarm.it– sales@dentalfarm.it Website: www.dentalfarm.it...
