- Page 1 STEAM GENERATOR HYDROVAP PRO MAINTENANCE AND INSTRUCTION MANUAL...
- Page 2 Cabinets to accomplish specific cleaning and sanitising operation and to remove impurities. HYDROVAP PRO is fitted with a flexible hose for easy handling - gun can be suitably pointed to take full advantage of the powerful steam or “hydrated steam” (Wet&Dry feature). The steam pressure (5.5 BAR) is related to the water temperature inside the boiler (155 °C).
-
Page 3: Safety Precautions
2. SAFETY PRECAUTIONS ATTENTION: when using electrical appliances, in order to prevent electrocutions, wounding and risks of fire, the following safety precautions must be strictly followed. Do not use the unit improperly and for purposes differing from the one described in the present manual Keep your working place in order –... -
Page 4: Installation
(B). HYDROVAP PRO has been developed to work with a water softener. Connect the water inlet on the back of the machine with the mains water outlet with the use of a pipe (rilsan diam. 8x6). For safety reason we recommend to mount a faucet on the inlet and to close it when the machine is not in use. - Page 5 5. INSTRUCTIONS FOR THE REGULAR MAINTENANCE Any maintenance operation has to be carried out under cold unit, in idle mode and unplugged from mains. Cleaning For external cleaning, wipe any moist residues from the unit housing, using liquids free from chemical abrasive or corrosive agents.
-
Page 6: Technical Features
7. TECHNICAL REFERENCE REGULATIONS AND TEST PROCEDURES HYDROVAP is mass-manufactured by DENTALFARM Srl in compliance with technical and safety rules in force, as provided for by the 2006/42/EEC Community Directive on Machinery. Careful inspection and full routine testing are carried out singularly on each machine, which is furtherly tested by an automatic test installation assuring compliance with the fixed limits. -
Page 7: Wiring Diagram
10. WIRING DIAGRAM DESCRIPTION Main switch 10Amp. Network Fuse Heating control light Heating switch Warning light Acoustic signal Heating resistance Safety thermostat Pressure switch WATER LEVEL BOARD Level control board Level indicator RELAIS BOARD Push button control board Solenoid valve for handpiece steam jet Boiler water feeding solenoid valve EVH2 Water hydrated steam solenoid valve... -
Page 8: Hydraulic Circuit
11. HYDRAULIC CIRCUIT DESCRIPTION Water inlet pipe-fitting Water filter Boiler water feeding solenoid valve Boiler water inlet pump Level indicator Water hydrated steam pump Pressure switch Pressure gauge Safety valve Solenoid valve for handpiece steam jet Handpiece BOILER Boiler... - Page 9 12. EXPLODED VIEW AND SPARE-PART LIST: HYDROVAP PRO (A2104P) CODE DESCRIPTION 2104012 HANDPIECE SUPPORT 2104007 REAR PANEL 2103045 WIRE LOCKING SYSTEM WITH TERMINAL BOARD 2103030 FUSEHOLDER 2104020 PUSH BUTTON CONTROL BOARD BOILER UNIT 2103037 LEVEL CONTROL BOARD 2103028 BIPOLAR LIGHT SWITCH...
- Page 11 DENTALFARM Srl Via Susa, 9A - 10138 Turin - ITALY TECHNICAL-COMMERCIAL SERVICE : +39 011 4346588 AFTER-SALE SERVICE: +39 011 4346632 Email: info@dentalfarm.it – sales@dentalfarm.it Website: www.dentalfarm.it...
