Installation Instructions
Concealed Vertical Rod Device
Determine handing of door
Right - Hand Reverse Bevel
(RHR)
Push Side
16
B
B
15
14
9
10
11
(Only available
on fire rated)
C-1
G
17
D
1-1
18
19 BOTTOM STRIKE
Surface type
2020-A
Left- Hand Reverse Bevel
Outside
Push Side
G
Square marked hole
13
B
B
F
1
C-1
B
A
4
B
Mortise type
*LHR shown*
(LHR)
3
C-1
2
1
C-1
(Only available on
fire rated)
5
(Not available
on fire rated)
PARTS LIST
ITEM
DESCRIPTION
1
CHASSIS ASSY
1-1
ACT ARM
2
PUSH BAR
3
MOUNTING RAIL
4
HEAD COVER
5
ALLEN WRENCH
6
SLIDING COVER
7
BRACKET
8
END CAP
9
MAIN CHASSIS
10
CONNECTOR GUIDE
11
CONNECTOR LIMIT PLATE
12
THRU. BOLT
13
MOUNTING PLATE
14
TOP ROD ASS'Y
15
TOP LATCH HOUSING ASS'Y
16
TOP STRIKE
17
BOTTOM ROD ASSY
18
BOTTOM LATCH HOUSING ASSY
19
BOTTOM STRIKE
A
SM4*8 FLAT HEAD SCREWS
B
10#*5/8" FLAT HEAD TEK SCREWS
C
SM5/32"*1-1/4" FLAT HEAD SCREWS
C-1
SEX BOLT (Only For Fire Rated)
D
HEX SCREWS M5X12
E
10#*1-1/4" FLAT HEAD TEK SCREWS
F
3/16"*3/8" FLAT HEAD SCREWS
G
M4*8 FLAT ROUND HEAD SCREWS
"a"
Screw Cam
"b"
Cam
"c"
Latch Activating Lever
A
8
7
E
6
C-1
QTY
1
1
1
1
1
1
1
1
1
1
2
2
0
1
1
1
1
1
1
1
6
26
0
4
2
2
3
2
1
1
(See P9)
