2.2 Description of installation parameters based on respective generator.
Installation of Dominus to respective generator
Generator
App profile name
Fam. TRIO PACK/
TRIO PACK /TRIO
TRIO HYDRO
HYDRO
Fam. Magis Pro/Com-
Magis Pro-Combo V2
bo V2
Fam. Magis
Magis
Hercules Pro
Hercules Pro.
Magis Hercules Pro
Mini.
Fam. Victrix Superior
Superior
Fam. Hercules con-
densing
Fam. Victrix Extra
Maior/Extra
Fam. Victrix Maior
Fam. Victrix Tera
Vip V2
System Manager
System manager
MAGIS-HERCULES-
Magis Pro Combo V2
ERP / TRIO
/ TRIO
In the notes: For more details on the column 'Generator configuration parameters' refer to the generator booklet.
3. WIRING DIAGRAMS
POWER SUPPLY
CONFIGURATION "A"
GENERATOR
Generator configuration parameters
On the control panel, select the item 'Sy-
stem Supervision' in the system Service/De-
finitions menu and set the option 'Domin' .
On the control panel, select the parameter
' A 30' in the Password/System menu and set
the option 'ON' .
On the control panel, select the item 'Sy-
stem Supervision' in the system Service/De-
finitions menu and set the option 'Domin' .
On the control panel, select the item 'Type'
in the Service/Modbus menu and set the
option 'Dominus' .
On the control panel, select the parameter
'P18' in the 'P' menu and set the option '1' .
On the control panel, select the item 'B04'
in the Service/Supervisor menu and set the
option 'Yes' .
Set the parameter 'BMS' in the 'ConF' menu
to the value 1.
GENERATOR
CONFIGURATION "B"
6
DIP SWITCH
configuration
5
230 Vac
7
